Free Your Data Techniques for Getting Data In

Free Your Data! Techniques for Getting Data In and Out of Lotus Notes Julian Robichaux, SNAPPS © 2009 by the individual speaker

Iam. LUG 2009

Iam. LUG 2009

What do you mean by “Data”? Iam. LUG 2009

What do you mean by “Data”? • Mainly “view-type” data in a Notes database • Stored in Notes documents (natch) • For external data sources, it could be: s Text files s Relational databases s File System s Data objects s Spreadsheets s Maps s Tag clouds s Punch cards Iam. LUG 2009

Import/Export Versus Synchronization • We’re talking about importing or exporting data here • Synchronizing with an external source is trickier s Deal with updates and diffs s Deletion policies s Conflict winners and losers • NB: there are tools for this too s LEI s Casahl s Notrix Iam. LUG 2009

Enough of this talk! Let’s get started Iam. LUG 2009

CSV Files • CSV = Comma Separated Values • Comma-delimited text files • Old skool data format, very simple • Some flexibility (variations) in format: s Values can be enclosed in double-quotes or not s Sometimes text will be enclosed in quotes and numbers will not s Embedded double-quotes need to be double-doublequoted s Linefeeds end the data record, unless they’re inside a quoted string s If a value has commas, you must quote the whole value Iam. LUG 2009

CSV Files: Export • From a Notes View, File > Export…, then choose “Comma Separated Value” as the format • Custom Lotus. Script/Java agent to walk a View s Custom selections s Special groupings and collations of data s Calculations not easily done in views s Server-side CSV generation Iam. LUG 2009

CSV Files: Import • From a Notes View, File > Import…, then choose “Tabular Text” as the format Iam. LUG 2009

CSV Files: Import (cont. ) • That’s right, I said TABULAR Text for the format • You must create a. COL file (“format file”) to define rules for the import process s Format information is in the Domino Designer Help data. csv one, two, three four, five, six seven, eight, nine Iam. LUG 2009 data. col Field 1: UNTIL ", "; Field 2: UNTIL ", "; Field 3: UNTIL "";

CSV Files: Import (cont. ) • View Import limitations and gotchas s Each line must be less than 1, 536 characters s Quoted fields in data records keep their quotes s No embedded commas allowed in any text fields s Errors if a record line has fewer fields than expected s Formulas can be used for data transformations (see Designer Help), but can be perilous • Unless your CSV data is very controlled and consistent, you probably don’t want to use the native View import s But hey, it’s always fun to play! Iam. LUG 2009

CSV Files: Import (cont. ) • Lotus. Script CSVReader class s http: //nsftools. com/tips/Notes. Tips. htm#csvtoxml s Something I wrote to easily parse a CSV file s Deals well with quotes or lack of quotes, commas in value fields, etc. Dim reader As New CSVReader("c: data. csv") header. Array = reader. get. Next. Line Do Until reader. is. EOF data. Array = reader. get. Next. Line If Not Isnull(data. Array) Then Print header. Array(0) & " = " & data. Array(0) End If Loop Iam. LUG 2009

CSV Files: Import (cont. ) • ODBC s Will discuss a bit later s Windows has a native driver you can use s Usually overkill for CSV, but might be desirable s Must create a schema. ini file to define the fields in the CSV file, sort of like the. COL file we saw earlier s http: //msdn. microsoft. com/enus/library/ms 709353. aspx Iam. LUG 2009

XML Files Iam. LUG 2009

XML Files • Yeah, the ones with angle brackets everywhere s No, not HTML dummy • Pros s Multi-lingual s Can be used with most systems or programming languages s Parsers handle the dirty work for you • Cons s Get big fast (lots of text) s Parsers are strict – and PLEASE don’t write your own parser s Large files can eat up a lot of memory as they’re Iam. LUG 2009

XML Files: Export • http: //server/db. nsf/view? Read. View. Entries&Co unt=5000 Iam. LUG 2009

XML Files: Export (cont. ) • Custom Lotus. Script options • You CAN write out raw XML as text s Watch out for encodings and special characters s Make sure ALL tags are matched and closed • For complex XML (or unknown data), it might be better to use a parser s See Notes. DOMDocument. Node and Append. Child method for starters s Kind of a lot of work, but you’ll be sure to have valid XML Iam. LUG 2009

XML Files: Export (cont. ) • Custom Java options • Similar to Lotus. Script options s Raw text s Use built-in parsers (additional native Java classes available) • Third-party libraries might be easier s Apache Jakarta Element Construction Kit (ECS) s JDOM s XStream Iam. LUG 2009

XML Files: Export (cont. ) • DXL? Iam. LUG 2009

XML Files: Export (cont. ) • DXL? • DXL is probably more suited for exporting design rather than data (my opinion) • You don’t export view data, you export entire documents s LOTS of data for each doc s You can ignore extraneous data or use XSLT s Usually easier to export data from a view Iam. LUG 2009

XML Files: Import • Native Notes classes (Lotus. Script and Java) s Notes. DOMParser creates a tree structure Somewhat easy to step through Reads the whole file into memory (be careful of large files) s Notes. SAXParser processes the file sequentially Have to code various events (SAX_Start. Element, etc. ) Can only go forwards through XML, not backwards Uses less memory for large files s Notes. XSLTransformer Apply an XSL style sheet to an XML doc to Iam. LUG 2009 reformat it

XML Files: Import (cont. ) • Interesting related technique s Use XSLT to convert XML to DXL format s Pipeline XML through XSL transformer, directly to DXL Importer s XML > Notes. XSLTransformer > Notes. DXLImporter > new docs s Used by the Lotus Connections Plugin (ilc 4 ln. ntf) to convert ATOM feeds directly to Notes docs Iam. LUG 2009

XML Files: Import (cont. ) • Java also has native XPath support s Sometimes easier than walking a DOM tree import org. w 3 c. dom. *; import javax. xml. parsers. *; import java. io. *; import org. apache. xpath. *; Document. Builder. Factory factory = Document. Builder. Factory. new. Instance(); factory. set. Validating(false); org. w 3 c. dom. Document dom. Doc = factory. new. Document. Builder(). parse( new Byte. Array. Input. Stream(xml. String. get. Bytes())); Node n = XPath. API. select. Single. Node(dom. Doc, "//temp[@type='max']/value"); Iam. LUG 2009

XML Files: Import (cont. ) • You can use MSXML OLE object for XPath in Lotus. Script s Windows-only, of course (but nothing extra to install) Dim url As String, x. Path As String Dim dom. Doc As Variant, node As Variant url = "c: KFFC. xml" x. Path = "/current_observation/temperature_string" Set dom. Doc = Create. Object("MSXML. DOMDocument") dom. Doc. async = False Call dom. Doc. load(url) Set node = dom. Doc. select. Single. Node(x. Path) Print "Temperature is " & node. text Iam. LUG 2009

XML Files: Import (cont. ) • XMLNode. Reader: easy wrapper around Notes. DOMParser s http: //nsftools. com/tips/Xml. Node. Reader s Simple node syntax, also easy to get collections of nodes Dim reader As New Xml. Node. Reader Call reader. Read. File( "c: booklist. xml" ) Print reader. get( "bookshelf. book. title" ) books = reader. get. Node. Readers("bookshelf. book") Forall book In books Print book. get("title") End Forall Iam. LUG 2009

ODBC Iam. LUG 2009

ODBC • Old and standard way to connect to (and run SQL queries against) a relational database • Provides a consistent interface, but you still need drivers • No longer Windows-only Iam. LUG 2009

ODBC: Export • Lotus Notes is NOT a relational database s You knew that, right? • IBM has a “Notes. SQL” driver s Free download, easy install s Treats Notes Views like SQL tables s Has been updated for Notes 8 Iam. LUG 2009

ODBC: Export (cont. ) • Notes. SQL Issues s After install, Notes. SQL directory and Notes Program directory MUST be in your Windows PATH Vague error messages if they’re not s Known issues with Excel 2003 (but not Excel 2007) Often hangs when accessing or saving data s Known issues with Open. Office 2. x View columns with text values are blank s Notes. SQL driver (and related DSN) must be manually installed and configured on every client machine (or server) that needs to use it s Make sure you read the Help docs on performance Iam. LUG 2009

ODBC: Export (cont. ) • So, what is Notes. SQL good for? s Users who are already familiar with ODBC reporting s Environments where ODBC-based reporting tools (like Crystal Reports) are in regular use Crystal also has its own native Notes driver s Power users who use MS Access to write reports Oddly, even though there are issues with Excel 2003, Access works just fine s Nice “self-service” option for users • Very little work involved on the Notes side s Maybe a few custom views, maybe not s No custom exports to deal with Iam. LUG 2009

ODBC: Import • Much more useful when getting data from other sources Iam. LUG 2009

ODBC: Import (cont. ) • LS: DO (Lotus. Script Data Object) s “Old” way of making ODBC connections with Lotus. Script s Use an existing DSN to connect and get data Uselsx "*LSXODBC“ Dim con As New ODBCConnection Dim qry As New ODBCQuery Dim result As New ODBCResult. Set qry. Connection = con Set result. Query = qry con. Connect. To("My. DSN") Iam. LUG 2009 qry. SQL = "SELECT * FROM Some. Table" result. Execute Do result. Next. Row Print result. Get. Value("COLUMN 1") Loop Until result. Is. End. Of. Data result. Close(DB_CLOSE) con. Disconnect

ODBC: Import (cont. ) • LEI (Lotus Enterprise Integrator) s Can use ODBC connections or direct connections with special provided drivers • Administrator Database user interface s Set up connections, virtual documents, direct transfers, synchronization, etc. using a simple UI s Costs extra $$$ (or £££, or whatever) • LSXLC s Lotus. Script alternative to LS: DO using LEI code s Potentially more robust, and generally handles Unicode better s More dynamic than the UI option s Included with your standard Notes/Domino license Iam. LUG 2009

ODBC: Import (cont. ) • LSXLC s ODBC example below, direct driver connections (no DSN required) are essentially the same Uselsx "*lsxlc“ Dim LCses As New LCSession Dim con As New LCConnection ("odbc 2") con. Server = "Some. System. DSN" con. Metadata = "My. Table" con. Userid = "My. User. Name" con. Password = "My. Password" Iam. LUG 2009 con. Connect Dim field. List As New LCField. List sql = "SELECT * from My. Table" Call con. Execute(sql, field. List) Do While (con. Fetch(field. List) > 0) Print field. List. Some. Field. Name(0) Loop con. Disconnect

ODBC: Import (cont. ) • ADO (Microsoft COM object, called from Lotus. Script) s Another way to use either DSNs or DSN-less connections s Allows you to properly use the option in SQL Server that will return results as XML instead of a resultset http: //www 10. lotus. com/ldd/eiforum. nsf/0/bd 63 aeea 8 bb 94 f 0785256 f 41000 d 6 e 3 c? Open. Docume nt s Lots of examples on the web (easy to convert VBScript examples to Lotus. Script) • JDBC, if you’re using Java s Can use ODBC or special drivers s Again, lots of examples out there Iam. LUG 2009

ODBC: Export (cont. ) • Bill Buchan did a nice presentation on comparison of many of these techniques s Good information and useful sample code s “Leveraging Lotus. Script for Database Connectivity” s http: //www. hadsl. com – under “The View” tab Iam. LUG 2009

Spreadsheets Iam. LUG 2009

Spreadsheets • Spreadsheets are where much of the world’s data lives (or ends up, at least) • Easy to enter data, easy to manipulate data s And you don’t have to be a programmer to create one • In fairness, we’ll discuss both Excel and Symphony Iam. LUG 2009

Getting Data Into Spreadsheets • All of the methods we’ve discussed already s CSV files open natively s XML files open natively (keep it simple though) s ODBC connection via Notes. SQL • Notes COM objects called from a macro • Edit > Copy As Table from any Notes View s There is a limit to how many rows will copy though • Excel can use a URL to a Domino view as a “Web Query” data source Iam. LUG 2009

Spreadsheet Export Agents • Basic Excel technique Set xl. App=create. Object("Excel. Application") xl. App. Visible = False xl. App. Workbooks. Add Set xl. Workbook = xl. App. Active. Workbook Set xl. Sheet = xl. Workbook. Active. Sheet Set view. Nav=view. Create. View. Nav Set entry=view. Nav. Get. First Iam. LUG 2009 While Not entry Is Nothing col=1 row=row+1 Forall v In entry. Column. Values col=col+1 xl. Sheet. Cells(row, col). Value = v End Forall Set entry=view. Nav. Get. Next(entry) Wend xl. App. visible=True

Spreadsheet Export Agents • Basic Symphony technique Dim args() As Variant Set xsm = Create. Object ("com. sun. star. Service. Manager") Set xd = xsm. create. Instance ("com. sun. star. frame. Desktop") Set xbook = xd. load. Component. From. URL ("private: factory/scalc", "_blank", 0, args) Set xsheet = xbook. Sheets. get. By. Index(0) Set view. Nav=view. Create. View. Nav Set entry=view. Nav. Get. First Iam. LUG 2009 While Not entry Is Nothing col=0 row=row+1 Forall v In entry. Column. Values Set xcell = xsheet. get. Cell. By. Position(col, row) Call xcell. set. String(Cstr(v)) col=col+1 End Forall Set entry=view. Nav. Get. Next(entry) Wend

Getting Data Out of Spreadsheets • Again, methods we’ve already discussed s Save as CSV or XML, import into Notes s Use native Windows ODBC driver (for Excel) • Use COM/OLE like the export, only backwards s A little trickier to import than to export, because the data might have slight formatting variations s Often better to save to an intermediate format first Iam. LUG 2009

JSON Iam. LUG 2009

JSON • JSON = Java. Script Object Notation • Extremely easy way to store, retrieve, and interchange data in Java. Script s Native to Java. Script, so no external libraries required • See json. org for details on syntax and var my. JSONObject = {"meals": [ {“type": "breakfast", "food": "cookies"}, {“type": "lunch", "food": "Pringles"}, {“type": "dinner", "food": "Guinness"} ] }; semantics Iam. LUG 2009 alert(“For breakfast I ate “ + my. JSONObject. meals[0]. food);

JSON • Also very easy to construct a JSON object from a String s Format the string according to syntax rules, and use eval() var my. JSONObject = eval( ‘( {“food”: “coconut”, “texture”: “furry”} )’ ); • To go from JSON to a string is not native s Use the JSON class from json. org s Firefox 3. 5 has a JSON object built-in • Interesting use case: libraries can convert XML to JSON Iam. LUG 2009 s Makes it very easy to work with XML in Java. Script

JSON Iam. LUG 2009

JSON: Export • http: //server/db. nsf/view? Read. View. Entries&Output. Format=JSON&C ount=5000 Iam. LUG 2009

JSON: Export (cont. ) • Lotus. Script JSONWriter class s http: //download. snapps. com s By Troy Reimer, Apache licensed s Converts the following Notes objects to JSON strings Array List Notes. Document. Collection Notes. View. Entry Iam. LUG 2009

JSON: Import • Lotus. Script JSONReader class s http: //download. snapps. com s By Troy Reimer, Apache licensed s Convert JSON into objects and arrays, and do what you like Iam. LUG 2009

JSON: Import (cont. ) • Java can use the classes on json. org s Interestingly, these classes can also convert XML to JSON Iam. LUG 2009

Web Services Iam. LUG 2009

Web Services • This is NOT some sort of magic wand s Still manual coding involved s You have to create or consume the formatted data i. e. – you can’t just send/receive a raw Notes. Document • However, it’s a common way for apps to transfer data • No time to get into the nitty-gritty of “what is a web service” right now Iam. LUG 2009

Web Services Iam. LUG 2009

Web Services: Export • Some Domino-specific articles on IBM developer. Works s http: //www. ibm. com/developerworks/lotus/library/web- services 1 s http: //www. ibm. com/developerworks/lotus/library/webservices 2 s http: //www. ibm. com/developerworks/lotus/library/webservices 3 • Bottom line is that if you make data available via a web service, it will [often] be easy for other applications to consume the data s Platform independent, language independent, etc. s Microsoft. NET apps love web services Iam. LUG 2009

Web Services: Export (cont. ) • Lotus. Script or Java s Pass around scalar values, arrays, and objects Iam. LUG 2009

Web Services: Import • Notes (and Domino) 8. 0 and higher can natively call external web services s Import the WSDL file into a script library, wrapper code is written for you s Use the script library in agents or actions to call web services s No drivers to worry about, just an HTTP connection • In earlier versions, you can use Java or COM objects to call external web services Iam. LUG 2009

Web Services: Import (cont. ) • Anywhere you can write Lotus. Script or Java, you can call the web service Iam. LUG 2009

Mashing Up Your Data Iam. LUG 2009

Mash Up Smash Up • These techniques aren’t just for importing or exporting entire databases full of information • Very useful for: s Reporting s Graphing s Dashboards s Presenting statistics to your boss right before a performance review Iam. LUG 2009

And… We’re Done THANK YOU! Julian Robichaux nsftools. com SNAPPS jrobichaux@snapps. com Iam. LUG 2009
