Excel Life Safety Honeywell XLS 80 e 2

Excel Life Safety Honeywell XLS 80 e 2 to 8 Loop Intelligent Control Panel

Excel Life Safety XLS 80 e 2 to 8 Loop Intelligent Control Panel

Excel Life Safety XLS 80 e Intelligent Repeater Panel

Excel Life Safety XLS 80 e - Network • Peer-to-peer network – Arc. Net based – Re-transmission and isolation between nodes (1 km btw. nodes) – Error checking and correction at each node – Message routing – Up to 100 network nodes – Up to 158, 400 devices – Up to 25, 500 zones – Up to 700 A PSU – Network alarm response less than 10 seconds 4

Excel Life Safety Master/Slave or “Peer to Peer” IONISATION SENSOR BREAK GLASS MCP CONTROL RELAY MODULE MCP PRESS HERE THERMAL SENSOR ISOLATOR MODULE DOOR HOLDER CONTROL MODULE ISOLATOR MODULE EXTERNALLY POWERED SOUNDER CONVENTIONAL DEVICES BREAK GLASS PHOTO SENSOR PRESS HERE CONVENTIONAL DETECTOR INTERFACE MODULE BEAM DETECTOR DUCT HOUSING AND SENSOR THERMAL SENSOR LOOP-POWERED BASE SOUNDER CONVENTIONAL ZONE LOOP-POWERED SOUNDER 5

Excel Life Safety System Goals • Greater fire detection accuracy with elimination of nuisance alarms • Faster response • Greater flexibility in alarm system design and application • Lower installed cost • Lower operating and maintenance cost 6

Excel Life Safety Global Market Offering • Compliant with EN 54 • • • Large graphic LCD Multi-lingual capability Modular design Site configurable Application software flexibility 7

Excel Life Safety XLS 80 e Applications (1) An advanced life safety system designed for large single site and multi-site applications • • • Office towers Airports Hospitals Universities Manufacturing complexes • Military bases • Government buildings 8

Excel Life Safety XLS 80 e Applications (2) • Retrofit and new construction • Medium to large multiple building systems • Standalone systems • Networked systems 9

Excel Life Safety • • ID 3000 Technical Advances Modular design Surface mount technology Fully automated test equipment User friendly interface Peripheral options Advanced software features Easy programming Multiple language options 10

Excel Traditional Fire Alarm Functions Life Safety • • • Smoke and fire detection Sprinkler system supervision Automatic and manual system operation Added Value Options • Advanced detection products – Filtrex™, Multi-criteria, loop powered sounders and beam detectors • Enhanced loop interface board (E-LIB) • Active and passive repeaters • Graphic annunciator driver 11

Excel Life Safety • • • Key Terms Basic Equipment Kit Extension Chassis Kit LIB - Loop Interface Board E-LIB - Enhanced Loop I/F Board DTP - Dual Transmission Path Booster I/F Kit PSU - Power Supply Unit Node - A system panel in a network LCD - Liquid Crystal Display CBE - Control by Event Matrix Mimic (Graphic Annuciator) Driver Kit 12

Excel Life Safety Hardware Overview

Excel Modular Design Life Safety Basic Configuration Installation/Commissioning Kit Basic Equipment Kit Cover(s) Extension Chassis (if required) Optional Expansion Modules (if required) Backbox(es) Power Supply 14

Excel Life Safety Backbox ID 3000 Key Components Power Supply & Batteries Basic Equipment Kit & Extension Chassis Covers 15

Excel Life Safety Modular Design • Modular design offers: – flexibility – ease of expansion – lower service cost 16

Excel Basic Equipment Kit Life Safety Expansion Cards Processor PCB Main Chassis Base Card Display PCB 17

Excel Life Safety Basic Equipment Kit • Can be extended with: – Up to 3 Standard Loop Cards (LIB) – Up to 3 Enhanced Loop Cards (E-LIB) – One RS-232 Card – One RS-485 Card – One ID-Net Card (*) – Panel Printer 18

Excel Basic Equipment Kit Life Safety 19

Excel Life Safety BEK - Inputs & Outputs • Outputs: – A/B/C/D - Sounder or Relay programmable • Sounder - rated @ 1 A/30 V each • Dry contact relay - rated @ 1 A/30 V • Two can be programmed for German UE interface – Fault and Fire Relays • rated @ 1 A/30 V each – Auxiliary 26 -28 Vdc outputs 1 and 2 • both rated @ 1 A – Battery charger max. 8. 6 A (130 Ah batteries) 20

Excel Life Safety BEK - Inputs & Outputs • Inputs: – Mains - 230 Vac ± 15% 50/60 Hz – Two addressable loops - 500 m. A – Tamper switch input (VF dry contact) • Serial Ports: – RS 232 Port 1 • PC Programming, internal printer option – RS 232 Port 2 (optional module) – RS 485 Port (optional module) 21

Excel Modular Design Life Safety Extension Chassis Options Extension Chassis with 64 Zone Display Module Kit (with or without Printer) Double Extension Chassis with 255 Zone Display Module Kit Extension Chassis with PRN 2000 Printer Module Kit Extension Cover Blanking Plate 22

Excel Life Safety Extended Backbox Extension Options 64/128 Zone LED’s and Panel Printer 255 Zone LED’s External Printer Support 23

Excel Modular Design Life Safety Optional Expansion Modules Printer Module Kit ID-Net Network Card Isolated RS 232 Module Kit Isolated RS 485 Module Kit Dual Loop Module Kit Enhanced Dual Loop Module Kit 24

Excel Standard LIB v’s. E-LIB Life Safety • E-LIB • LIB – Handles communication only – System CPU scans loops • In case of main CPU failure all detection is lost – CPU always busy – Max. 512 devices per panel – Powerful microprocessor – Degrade mode • In case of main CPU failure the E-LIB will still activate sounder circuits 1 -4 and the Fire Relay when an alarm is received from the loop – CPU available for other tasks – Full device count on the panel 25

Excel Life Safety Serial Communication • RS 232 Option – Isolated port – Third party interface – External printer – Uni. Net (NION) connection – Pager interface – VDU for terminal emulation • RS 485 Option – Isolated – Master/Slave network – Multi-drop – Repeaters – Graphic annunciators 26

Excel Expansion Modules Life Safety 27

Excel Modular Design Life Safety Power Supply Selection Power Supply Unit Kit 2. 5 Amp Remote Battery/Charger Enclosure Kit Universal PSU Kit 4. 5 A or 7. 0 A (External enclosure or deep boxes only) PSU DTP Booster Kit (4. 5 or 7. 0 A PSU only) 28

Excel Power Supply Options Life Safety 2. 5 A PSU mounts on the side of the BEK DTP Booster mounts on the side of the BEK 4. 5 A PSU mounts into the deep (extended) back box 7 A PSU mounts into the external charger/ battery enclosure 29

Excel Life Safety PSU with Dual Transmission Path Booster Kit • • • Temperature compensated battery charger DTP required by EN 54 -4 for external PSU application Maintains constant loop voltage over a wide range of mains and battery voltages • Fault monitoring on the power supply, mains and the batteries • Inhibits charger in case of an alarm 30

Excel Life Safety Power Supply Options • 7 A PSU Status Indication LEDs (for use in the Remote Enclosure) 31

Excel Modular Design Life Safety Backbox Options Flush Mounting Bezels Standard Back Box Kit Backbox Extension Kit (available in ‘standard’ and ‘deep’) Extended Back Box Kit (available in ‘standard’ and ‘deep’) Double Extended Backbox Kit (available in ‘standard’ and ‘deep’) 32

Excel Back-box Options Life Safety 12 Ah Deep Boxes Standard 17 Ah 38 Ah Extended 17 Ah Standard depth 38 Ah 78 Ah Double Extended External Box 33

Excel Life Safety Modular Design Cover/Door Kits Security Door Kits (available for main & extension covers) Main Cover Kit (High Security option) Extension Cover Blanking Plate Extension Cover Kit (High Security option) Double Extension Cover Kit 34

Excel Life Safety Cover Options • All covers are available in: – Black/Grey (standard) matching backbox and bezel – Red matching backbox and bezel – NEXTEL Grey - matching bezel – Stainless Steel- matching bezel 35

Excel 19” Rack Mounting Option Life Safety 36

Excel 19” Rack Mounting Option Life Safety • • • 19” Rack Mounting Assembly for Basic Equipment Kit 6 U x 19” Rack Mounting Assembly for 7 A PSU 6 U x 19” Rack Mounting Assembly for 64 Zone LED Extension Chassis & Printer Kit 6 U x 19” Rack Mounting Assembly for 256 Zone LED Extension Chassis Kit 6 U x 19” Rack Mounting Assembly for Printer 3 U x 19” Rack Blank Cover with Mains Termination Kit 6 U x 19” Rack Blank Cover with Mains Termination Kit 3 U x 19” Rack Mounting Assembly for Mimic Driver Kit 6 U x 19” Rack Blank Cover 3 U x 19” Rack Blank Cover All available in the standard black/grey colour 37

Excel Life Safety Take Your Pick! 38

Excel Life Safety User Interface

Excel Life Safety 6 Line x 40 Character Graphic LCD Main Control Switches System Status Indicators Main User Interface • Numeric Data Entry & Enter/Cancel • Navigation Keypad • Key switch Access Level 2 40

Excel Life Safety Main User Interface • Fully EN 54 compliant • Simple tabbed menu navigation • Prioritised event display (Automatically displays highest priority event) • User in control/has choice of what is displayed • Simple lights and switches for common controls • Top level info displayed 41

Excel Life Safety Graphic Display • Large 240 x 64 pixel LCD 6 lines x 40 characters • Short-cuts for test & disablement • Selection by direct addressing • Displays: – Time and Date – Active Point Count for each event – Event type, index and actions – Panel, Zone and Device descriptors 42

Excel Life Safety Graphic Display System Information on Windows Style Tabbed Screens 43

Excel Graphic Display Life Safety Highest Priority FIRE PRE-A EVENT TYPES AND TAB DISPLAY PRIORITIES FAULT DISAB TEST EVAC Lowest Priority AUX USER If there is insufficient room to display all 8 tabs, then the lowest (on the right) are omitted. 44

Excel Life Safety Virtual Keyboard Panel and Zone Text up to 32 Characters via Keyboard to Navigate and to Select 45

Excel Life Safety Example - 3 Zones in Alarm: Fire Alarm Display 2 Devices Alarmed in Zone 2 1 Device Alarmed in Zone 1 1 other zone in Alarm - Press “Zones in Alarm” to view others Use Navigation keys 46 to scroll through zones and display other devices, date/time of event and device % value, etc. Short-cut key selects either device or zone disablement. 46

Excel Life Safety Pre-Alarm Display PRE-ALM DISPLAY REQUIRED? ? ? FROM P 21 OF OPERATING MANUAL 3 Zones are in Pre-Alarm with 4 events in the system 2 Pre-Alarms are currently in Zone 8. Use to scroll through zones & for device selection. 47

Excel Life Safety Fault Display 3 Zones are in FAULT with 4 events in the system. Use to scroll through zones and to display device, type, value, etc. 48

Excel Life Safety Disablement Display Life Safety Excel 142 Devices Disabled in 3 input zones. 12 devices are disabled in Zone 2 (all input devices). No outputs are disabled. Use to scroll through zone list and to see device details. 49

Excel Life Safety Main Control Switches Activate 2 nd Silence & Stage Delay Re-start (if in Day Mode) Sounders Silence Panel Override Delays Panel Reset & Buzzer Operate Sounders Show User Menu Toggle User Menus Toggle between Day Accept Non-Fire and Night Modes Alarm Disable Fire Relay (German Vd. S and Fire Output Mode) (if Configured) Show Fire Info & Scroll through Zones in Fire Accept Fire Alarm 50

Excel Life Safety System Status Indicators Fire condition exists Fault condition exists Pre-Alarm condition exists System/CPU failure Sounder O/P fault or disabled Fire relay disabled, or fire O/P disabled/in fault Fire relay or fire O/P is active 51

Excel Life Safety System Status Indicators - 2 One or more devices disabled Test mode active (Walk-Test, etc. ) Mains or battery power OK Day mode active (pushbutton operated) Programmed delays enabled A Non-Fire (AUX) device activated Spare for future features 52

Excel Life Safety Navigation & Numeric Keys Text Edit Short-Cuts Disable/Enable Menu Select Up (Next) Left (Back) Down (Previous) Numeric Data Entry Right (Forward) Accept/ Accept Enter Cancel/Escape 53

Excel Life Safety Zone Status Indicators • FIRE and FAULT/DISABLED/TEST Indication 64 Zone LED Display Module (Single Extension Chassis) Two Variants: Zones 1 to 64 or Zones 65 to 128 255 Zone LED Display Module (Double Extension Chassis) 54

Excel Life Safety Language Options Easy translation/customisation using “Slide-In” type text labels 55

Excel Life Safety Main Features • Approved to EN 54 Parts 2 and 4 • Degraded mode of operation – Enhanced LIB (parallel CPUs) • Support for: – Advanced detection devices (VIEW™, HARSH™, MULTI) – Loop powered sounders (ABS 4, IBS 3, ANS 4, AWS 3) – Loop powered beam detectors (LPB-500, LPB 620) • Menu driven point/data access • Multi-level operator password control • Multiple language options – English, German, Spanish, Icelandic, Dutch/French (*) 56

Excel Life Safety • • Key Functions 10 sensitivity levels for Fire & Pre-alarm Adjustable alarm & fault verification delay Two-stage alarm operation Alarm silence/re-sound Sound general alarm (Evacuate) Day and Night modes Fire output(s) inhibit Internal and external printer options 57

Excel Life Safety • • Key Functions (continued) Powerful Control-by-Event (CBE) Auto-Learn or PC programming Duplicate address detection One-man Walk Test with counter Output device test Daily high test 2 pulse rates for outputs Time of day functions 58

System Capacity Stand-Alone Excel Life Safety • • Up to 8 loops 198 (99+99) devices per loop Up to 99 VIEW™ per loop Up to 1584 devices Up to 255 zones Up to 7 A PSU Up to 31 repeaters Graphic annunciators (Mimic) – Up to 512 LEDs per controller • 600 event history log 59

Excel Life Safety System Capacity Stand-Alone (continued) • Four sounder circuits (NACs) – rated @ 1 A each – Two programmable as VF relays rated @ 30 Vdc/1 A • Two 24 Vdc auxiliary outputs – rated at 1 A each • Two programmable inputs • SPDT Fault and Fire relays – rated @ 30 Vdc/1 A • Two loops as standard • One isolated RS 232 port (optional) • One isolated RS 485 port (optional) 60

Excel Life Safety System Capacity Networked - I • Master/Slave network – Up to 32 network nodes – Maximum 8 panels – Remainder repeaters and graphic annunciators – Up to 64 loops – Up to 12, 672 devices – Up to 2040 zones – Up to 56 A PSU – Max. RS 485 bus length of 3000 m 61

Excel Life Safety Master/Slave Network • Functionality supported across the network: – – – – Reset Silence/Re-sound Mute Evacuate Point/Zone Isolate Walk Test Zone Event Broadcast Control by Event (CBE) 62

Excel Life Safety Bldg. 2 Bldg. 1 Bldg. 3 System Capacity Networked - II • Peer-to-peer network – Arc. Net based – Re-transmission and isolation between nodes (1 km btw. nodes) – Error checking and correction at each node – Message routing – Up to 100 network nodes – Up to 158, 400 devices – Up to 25, 500 zones – Up to 700 A PSU – Network alarm response less than 10 seconds Bldg. 4 63

Excel Life Safety Off-Line Configuration Tool • Stand-alone and Master/Slave network – DOS based – Individual panel programming – Manual software authentication – Same format as ID 1000 and ID 2000 – Minimum training required – No special hardware requirement – Windows based Loop & Battery Calculator tool • Peer-to-peer network – Windows based – System-wide programming 64

Excel Life Safety Off-Line Configuration Tool Windows version • • • Windows 95/98/ME/NT 4/2000 Operating Systems Windows XP under consideration Standard Windows editing features (cut, copy, paste, etc) • On-line error checking • Easy report printouts • On-Line Help menu 65

Excel Life Safety On-Site Configuration • Multi-level password/key-switch access – Level 2: Code 1/Keyswitch - Panel controls & menus – Level 3: Code 2 - Level 2 + Configuration menus – Level 3 A: Code 3 - Level 3 + Advanced Configuration • Panel settings • Auto-learn facility • Loop/Device configuration • Text Editor (Virtual keyboard) • Control matrix editor (512 lines) • Network configuration 66

Excel Life Safety User Menu C o n f i g u r a t i o n (E n t e r L e v e l 3 P a s s c o d e) 67

Excel Life Safety Easy-to-use Test Mode FIRE BREAK GLASS PRESS HERE 1 sec ON or follow me LED ON for 5 sec Use to scroll through inputs currently under walk-test. Either Tested or Not Tested is highlighted for that device. Use to scroll through device descriptions. 68

Excel Life Safety User Menu - Examples Lamp Test checks all panel LED’s, Buzzer, L. C. D. & Contrast adjustment 69

Excel User Menu - Examples Life Safety Lamp Test also displays Panel & LIB software versions 70

Excel Life Safety Configuration Menu Level 3 Access Configuration: 1: Loop Device Configuration (auto-learn) 2: Zone Text Editor 3: Panel Text Editor 4: Control Matrix Configuration (512 lines) 5: Network Configuration 6: Panel Settings 71

Excel Life Safety Configuration Menu - 2 Loop Device Configuration 72

Excel Life Safety Configuration Menu - 3 73

Excel Life Safety Configuration Menu - 4 Network Configuration 74
