CHEST TRAUMA Dr. mohammadzadeh Thorasic surgeon

CHEST TRAUMA Dr. mohammadzadeh Thorasic surgeon

Incidence • Trauma kills 150, 000 Americans every year. • It is the most

Incidence • Trauma kills 150, 000 Americans every year. • It is the most common cause of death in the population <40 years of age. • One-fourth of deaths are specifically related to chest trauma, many of them occurring in the prehospital setting.

Specific Physical Findings in Chest Trauma

Specific Physical Findings in Chest Trauma

Subcutaneous emphysema

Subcutaneous emphysema

Traumatic Asphyxia

Traumatic Asphyxia

Theory of mechanism

Theory of mechanism

Thoracic cage injuries

Thoracic cage injuries

Sternal Fracture

Sternal Fracture

Sternal Fracture

Sternal Fracture

Intercostal nerve block

Intercostal nerve block

Intercostal nerve block

Intercostal nerve block

Intercostal nerve block

Intercostal nerve block

Flail chest

Flail chest

Complete sternochondral separation

Complete sternochondral separation

Flail chest

Flail chest

Penetrating chest injuries 1. Pneumothorax simple p. tension p. open p. 2. Hemothorax 3.

Penetrating chest injuries 1. Pneumothorax simple p. tension p. open p. 2. Hemothorax 3. Pulmonary hematoma 4. Major pulmonary paranchymal inj. 5. Air embolism 6. Traumatic lung herniation 7. Diaphragmatic injury

Simple Pneumothorax • may not come to the attention of the clinician during the

Simple Pneumothorax • may not come to the attention of the clinician during the initial assessment of critically injured victims. • A chest radiograph should always be obtained as early as possible during the secondary survey. , • chest tube drainage is recommended, even for small collections of air, especially in patients who require positive-pressure ventilation.

 • When a large air leak is present or reexpansion of the lung

• When a large air leak is present or reexpansion of the lung is incomplete, a tracheobronchial injury should be suspected and prompt flexible bronchoscopy performed

Pneumothorax

Pneumothorax

Tension Pneumothorax • Physical examination is more dramatic and may demonstrate severe respiratory distress,

Tension Pneumothorax • Physical examination is more dramatic and may demonstrate severe respiratory distress, distended neck veins, deviated trachea, absent breath sounds, or tympany to percussion on the affected side

Signs and Symptoms of Tension Pneumothorax • Anxiety, agitation, and apprehension • Diminished or

Signs and Symptoms of Tension Pneumothorax • Anxiety, agitation, and apprehension • Diminished or absent breath sounds • Cyanosis • Rapid shallow breathing • Distended neck veins

Tension Pneumothorax

Tension Pneumothorax

Tension Pneumothorax

Tension Pneumothorax

Tension Pneumothorax

Tension Pneumothorax

NEEDLE CHEST DECOMPRESSION

NEEDLE CHEST DECOMPRESSION

NEEDLE CHEST DECOMPRESSION

NEEDLE CHEST DECOMPRESSION

NEEDLE CHEST DECOMPRESSION

NEEDLE CHEST DECOMPRESSION

Open Pneumothorax ( sucking chest wounds) • Result of full-thickness loss of a portion

Open Pneumothorax ( sucking chest wounds) • Result of full-thickness loss of a portion of the chest wall, usually from a gunshot wound • A life-threatening emergency. • Air can flow freely in and out of the pleural space

Open Pneumothorax

Open Pneumothorax

Open Pneumothorax

Open Pneumothorax

Open(Sucking) Pneumothorax

Open(Sucking) Pneumothorax

Open Pneumothorax

Open Pneumothorax

Flutter-Valve Seal

Flutter-Valve Seal

Impaled Object

Impaled Object

Impaled Object

Impaled Object

Asherman chest seal

Asherman chest seal

Treatment Asherman chest seal – convert sucking chest wounds to simple pneumo/hemothorax •

Treatment Asherman chest seal – convert sucking chest wounds to simple pneumo/hemothorax •

Hemothorax • Often associated with penetrating chest injury or chest wall blunt trauma with

Hemothorax • Often associated with penetrating chest injury or chest wall blunt trauma with bony injury. • Ultrasound can be rapidly performed by the surgeon carrying out the initial evaluation of the injured patient. • A slight reverse Trendelenburg position of the patient is helpful in identifying smaller hemothoraces • More commonly, a hemothorax is recognized on chest radiography

Sources of Hemothorax

Sources of Hemothorax

Degree of Hemothorax

Degree of Hemothorax

Hemothorax

Hemothorax

Management • Complete evacuation of the blood collection. • Intrathoracic bleeding recognized in the

Management • Complete evacuation of the blood collection. • Intrathoracic bleeding recognized in the emergency department requires a closedtube thoracostomy. • Most commonly, a 24 - or 28 -Fr thoracostomy tube is sufficient to accomplish this goal.

ATLS criteria Chest drainage >1, 500 m. L initial or >250 m. L/hr for

ATLS criteria Chest drainage >1, 500 m. L initial or >250 m. L/hr for the next 4 hours

Residual Hemothorax • Must be evacuated as soon as the patient is stable to

Residual Hemothorax • Must be evacuated as soon as the patient is stable to reduce the risk for empyema or prevent the formation of a fibrous peel (resulting in lung entrapment). • It is not an emergency situation if bleeding has stopped. • Thoracoscopic drainage is best performed within 1 to 3 days after injury

Rupure of trachea or bronchi

Rupure of trachea or bronchi

Small tear of membranous portion of r. main bronchus

Small tear of membranous portion of r. main bronchus

Almost complete rupture of thoracic trachea

Almost complete rupture of thoracic trachea

Complete rupture of cervical trachea

Complete rupture of cervical trachea

Diaphragmatic injury

Diaphragmatic injury

Diaphragmatic injury • Thoracoabdominal stab wounds : anterior : 4 th intercostal space laterally

Diaphragmatic injury • Thoracoabdominal stab wounds : anterior : 4 th intercostal space laterally : 6 th intercostal space posteriorly : 8 th intercostal space DPL : an RBC count > 10000 an RBC count > 1000 THORACOSCOPY laparatomy thoracoscopy

Diaphragmatic injury

Diaphragmatic injury

Pulmonary contusion

Pulmonary contusion

Symptoms & Signs

Symptoms & Signs

Ill-defined patchy densities scattered throughout the lung

Ill-defined patchy densities scattered throughout the lung

Pulmonary contusion

Pulmonary contusion

Pathology

Pathology

Pulmonary Hematoma • Difficult to differentiate from pulmonary contusion because of the surrounding intraparenchymal

Pulmonary Hematoma • Difficult to differentiate from pulmonary contusion because of the surrounding intraparenchymal hemorrhage. • 24 to 48 hours after the injury, a hematoma typically develops into a discrete mass with distinct margins. • CT scans can be helpful in distinguishing between contusion and hematoma.

 • In most cases, the hematoma itself does not interfere with gas exchange

• In most cases, the hematoma itself does not interfere with gas exchange and is reabsorbed in time. • Rarely such a hematoma become secondarily infected and present as an abscess requiring drainage

Major Pulmonary Parenchymal Injury • Most pulmonary parenchymal injuries are treated with chest tube

Major Pulmonary Parenchymal Injury • Most pulmonary parenchymal injuries are treated with chest tube drainage. • Indication for thoracotomy : Radiographic assessment Bronchoscopy Patient's hemodynamic status, Adequacy of lung expansion, Size of air leak, Chest tube output

Surgery • The most effective method is the nonanatomic stapled resection. • More proximal

Surgery • The most effective method is the nonanatomic stapled resection. • More proximal lesions require extensive resection, including lobectomy or pneumonectomy. • Anatomic resections are rarely indicated • Tractotomy was first described by Wall in 1994

Tractotomy

Tractotomy

Pulmonary tractotomy

Pulmonary tractotomy

Air Embolism • Air embolism was first reported in 1974 by Thomas and Stevens

Air Embolism • Air embolism was first reported in 1974 by Thomas and Stevens in patients with penetrating lung injury. • It is typically seen in patients with penetrating injuries to the hilum of the lung, where the veins are not surrounded by lung or other structures. • Even small amounts of air can be catastrophic, resulting in hemodynamic instability with ventricular fibrillation and seizure activity.

 • Air embolism is difficult to recognize. • It may present as sudden

• Air embolism is difficult to recognize. • It may present as sudden cardiovascular collapse and sudden death in the conscious patient and must be suspected in patients who present with pulseless electrical activity. • When endotracheal pressure is >60 mm Hg, gas will easily pass from the pulmonary venous system into the systemic circulation and embolize in the coronary arteries.

The hallmark of an air emblus is hemoptisis and bloody , frothy air leak

The hallmark of an air emblus is hemoptisis and bloody , frothy air leak from a lung injury

Management • Immediate thoracotomy • Clamping of hilum • Head down position • De-airing

Management • Immediate thoracotomy • Clamping of hilum • Head down position • De-airing of left ventricular apex with a large –gauge needle

Traumatic Lung Herniation • Historically, noncongenital lung herniations resulted from penetrating traumatic injuries, including

Traumatic Lung Herniation • Historically, noncongenital lung herniations resulted from penetrating traumatic injuries, including postsurgical incisional herniations. • Today, the most common cause of lung herniation is motor vehicle collisions, particularly in restrained passengers. • • Other reported herniation sites include the site of internal mammary artery harvest, port sites after minimally invasive coronary bypass procedures, thoracoscopy port sites, through tube thoracostomy drainage sites. • Symptoms may be minimal despite a localized bulge that paradoxically changes shape with the respiratory cycle.

Lung Herniation

Lung Herniation

Lung Herniation

Lung Herniation

Treatment • Treatment involves hernia reduction and defect closure with a prosthetic patch (such

Treatment • Treatment involves hernia reduction and defect closure with a prosthetic patch (such as polytetrafluoroethylene). • The results are frequently excellent.

QUESTIONS?

QUESTIONS?
