Electronics in High Energy Physic Introduction to Electronics

Electronics in High Energy Physic Introduction to Electronics in HEP Field Programmable Gate Arrays Part 2 based on the lecture of S. Haas

Outline Part 1 • Programmable Logic • CPLD • FPGA – – Architecture Examples Features Vendors and Devices coffee break Part 2 • VHDL – Introduction – Examples • Design Flow – – Entry Methods Simulation Synthesis Place & Route • IP Cores • CERN Tools & Support 2

Introduction to VHDL

VHDL Language • Hardware Description Language (HDL) – High-level language for to model, simulate, and synthesize digital circuits and systems. • History – 1980: US Department of Defense Very High Speed Integrated Circuit program (VHSIC) – 1987: Institute of Electrical and Electronics Engineers ratifies IEEE Standard 1076 (VHDL’ 87) – 1993: VHDL language was revised and updated • Verilog is the other major HDL – Syntax similar to C language • At CERN VHDL is mostly used for FPGA design • Many tools accept both Verilog and VHDL 4

Terminology • Behavioral modeling – Describes the functionality of a component/system – For the purpose of simulation and synthesis • Structural modeling – A component is described by the interconnection of lower level components/primitives – For the purpose of synthesis and simulation • Synthesis: – Translating the HDL code into a circuit, which is then optimized • Register Transfer Level (RTL): – Type of behavioral model used for instance for synthesis 5

Digital Circuits and VHDL Primitives • Most digital systems can be described based on a few basic circuit elements: – Combinational Logic Gates: • NOT, OR, AND – Flip Flop – Latch – Tri-state Buffer • Each circuit primitive can be described in VHDL and used as the basis for describing more complex circuits. 6

Digital Circuit Primitives • • Combinational Logic Gates: NOT, OR, AND Flip Flop/Latch Tri-state Buffer Logic gates can be modeled using concurrent signal assignments: Z Y X W U V <= <= <= not A; A or B; C and D; E nor F; B nand D; C xor F; C D X AND E W F NOR • It is possible to design circuits from logic gates in this way • For design entry it is preferable to use other VHDL structures that allow circuit descriptions at a higher level of abstraction 7

Combinatorial Logic: Decoder entity decoder is port ( A : in std_logic_vector(1 downto 0); Z : out std_logic_vector(3 downto 0) ); end entity decoder; Interface architecture when_else of decoder is begin Z <= "0001" when A = "00" else "0010" when A = "01" else "0100" when A = "10" else "1000" when A = "11" else "XXXX"; end architecture when_else; Functionality Example: 2 -to-4 decoder Z(3) A(1) Z(2) A(0) Z(1) Z(0) A(1. . 0) Z(3. . 0) 0 0 0 1 0 1 0 0 1 1 1 0 0 0 8

4 -to-1 Multiplexer entity mux is port ( a, b, c, d: in std_logic; s: in std_logic_vector(1 downto 0); y: out std_logic); end entity mux; architecture mux 1 of mux is begin process (a, b, c, d, s) begin case s is when "00“ => y <= a; when "01" => y <= b; when "10" => y <= c; when "11" => y <= d; end case; end process; end architecture mux 1; a b y c d S(1) S(0) 9

Sequential Logic: D-Flip Flop architecture rtl of D_FF is begin process (Clock, Reset) is begin if Reset = ‘ 1’ then Q <= ‘ 0’; if rising_edge(Clock) then Q <= D; end if; end process; end architecture rtl; Flip-flop D Clock D Q Q R Reset 10

Binary Counter entity counter is generic (n : integer : = 4); port ( clk : in std_logic; reset: in std_logic; count: out std_logic_vector(n-1 downto 0) ); use ieee. numeric_std. all; end entity counter; • This example is not explicit on the primitives that are to be used to construct the circuit. • The “+” operator is used to indicate the increment operation. architecture binary of counter is begin process (clk, reset) variable cnt : unsigned(n-1 downto 0); begin if reset = '1' then -- async reset cnt : = (others => '0'); elsif rising_edge(clk) then cnt : = cnt + 1; end if; count <= std_logic_vector(cnt); end process; end architecture binary; 11

State Machine If a trigger signal is received, will stretch it to 2 cycles and wait for accept signal entity trigger is port ( clk, reset: in trigger, accept : in active: out end entity trigger; std_logic; std_logic); architecture rtl of trigger is type state_type is (s 0, s 1, s 2); signal cur_state, next_state: state_type; begin registers: process (clk, reset) begin if (reset='1') then cur_state <= s 0; elsif rising_edge(clk) then cur_state <= next_state; end if; end process; curr_state trigger clk State Transition Logic Output Logic accept R reset 12

State Machine (cont. ) process (cur_state, trigger, accept) is begin case cur_state is when s 0 => active <= '0'; if (trigger = '1') then next_state <= s 1; else next_state <= s 0; end if; when s 1 => active <= '1'; next_state <= s 2; when s 2 => active <= '1'; if (accept = '1') then next_state <= s 0; else next_state <= s 2; end if; end case; end process; S 0 accept trigger S 1 S 2 clk curr_state State Transition Logic Output Logic R 13

FPGA Design Flow Design Entry/RTL Coding Design Specification Behavioral or Structural Description of Design RTL Simulation • Functional Simulation • Verify Logic Model & Data Flow (No Timing Delays) LE MEM Synthesis I/O • Translate Design into Device Specific Primitives • Optimization to Meet Required Area & Performance Constraints Place & Route • Map Primitives to Specific Locations inside Target Technology with Reference to Area & • Performance Constraints • Specify Routing Resources to Be Used 14

FPGA Design Flow tclk Timing Analysis - Verify Performance Specifications Were Met - Static Timing Analysis Gate Level Simulation - Timing Simulation - Verify Design Will Work in Target Technology Program & Test - Program & Test Device on Board 15

Design Entry Methods

Text-based: emacs VHDL-mode • Special mode for editing VHDL source files in emacs • Features: – – Syntax colouring Automatic completions Automatic indentation Templates for all VHDL constructs – Launching external VHDL compiler 17

Design Entry: Visual Elite HDL • HDL design and verification environment • Features: – Enables graphical and text-based design entry methods – Design verification using built-in or external simulator – Generation of synthesizable VHDL or Verilog code appropriate for the selected synthesis tool • Design unit types: – – – Block Diagram HDL Code State Diagram Flowchart Truth Table 18

Block Diagram • Hierarchical design methods: – top-down – bottom-up • Contents of a block can be any type of design unit • Top-level block diagram: – Partitioning of the design – Connections between the underlying HDL design units 19

State Diagram • “Bubble” diagram • States • Conditions • Transitions • Outputs • Useful for developing control modules 20

Truth Table • • Normally used to describe combinatorial logic Can also be used for sequential circuits (e. g. state machines) 21

Design Cycle: Simulation • Functional simulation: – simulate independent of FPGA type – may postpone selection – no timing • Timing simulation: – simulate after place and routing – detailed timing Design Entry Simulation Synthesis Place & Route Simulation Program device & test 22

Simulation Results Example of simulation waveforms. Test vectors are normally defined in a VHDL unit (testbench) 23

RTL Synthesis • Input is RTL code • Compilation & translation – Generates technology independent netlist – RTL schematic (HDL code analysis) • Technology mapping – Mapping to technology specific structures: • • • Look-up tables (LUT) Registers RAM/ROM DSP blocks Other device specific components/features • Logic optimization Design Entry Simulation Synthesis Place & Route Simulation Program device & test – Implementation analysis (technology view) 24

Technology Mapping Example 6 -bit binary counter Altera Stratix device 25

Design Cycle: Place and Route • FPGA fitter – Tools supplied by the FPGA vendor – Specific for each FPGA device architecture • Functions – Place-and-route – Constraints editor – Backannotated netlist for timing simulation – Configuration bitstream Design Entry Simulation Synthesis Place & Route Simulation Program device & test 26

Example: Altera Quartus II • Fully integrated design tool – Multiple design entry methods • Text-based: VHDL, Verilog, AHDL • Built-in schematics editor – – – Logic synthesis Place & route Simulation Timing & power analysis Create netlist for timing simulation – Device programming • Xilinx ISE has similar features 27

IP Cores & System On a Programmable Chip (So. PC)

Macros & IP Cores • Macros: – Generic pre-made design blocks: • e. g. PLL, FIFOs, DDR I/O, Multiply-accumulate, etc. – – Accelerate design entry and verification Pre-optimized for FPGA vendor architecture Provided at no cost by the FPGA vendor to optimize performance Instantiate block in the design: • Makes HDL code technology dependent • IP cores: – – More complex blocks: PCI-X interface, CPU, etc. Some are provided by the FPGA vendor IP cores from third party suppliers cost money Evaluation before buying usually possible 29

Macro Example 30

System On a Programmable Chip • Many ready-made blocks for free – RAM/FIFO – UART • Can buy ready-made parts, just like IC's: IP Cores – PCI interface – Processors (8051 -style up to RISC/ARM processors) • FPGA's with extra dedicated hardware built-in – Gigabit serialiser – high-end processor with RAM • Handle different I/O standards – LVDS, LVPECL, LVCMOS, LVTTL, PCI-X – Programmable slew-rate, termination resistors 31

Example: Altera NIOS-II CPU 32

Tools and Support for FPGA Design at CERN

Tools available at CERN • Design entry: – FPGA vendor tools – Visual HDL – Cadence Concept. HDL • Simulation – Cadence NCsim • Synthesis – Synplify (Synplify) – Leonardo (Mentor) – FPGA fitter built-in • FPGA vendor tools: – Altera, Xilinx, Actel, Lattice 34

Tools available at CERN (cont. ) • IP cores: – PCI & PCI-X Master/Target for Altera – Altera NIOS-II Processor soft core – DDR SDRAM controller – DSP cores for Altera: • FFT, NCO, FIR – 10/1000 Ethernet MAC • If you need an IP core contact IT-PS or the DUG • Tools for implementing DSP systems in FPGAs: – Xilinx system generator for DSP – Altera DSP builder & evaluation kit • Altera NIOS-II evaluation kit • Programming cables for FPGAs are available for short -term loan • Tool usage: – Windows PC tools can be installed from: \dsy-srv 4caeprogs – CAE Sun cluster: – login to dsy-srv 35

CERN Support for FPGA Development • IT/PS – Tool Support Send e-mail to: Dig-Electronics-Cae. Support@cern. ch Direct contact: Serge Brobecker, John Evans http: //cern. ch/product-support/electronicscae. html • Other resources: – Mailing list for electronics designers at CERN: cern-electronics@cern. ch – Digital CAE User's Group (DUG): http: //wwwinfo. cern. ch/ce/dc/DUG_home. html • Technical Training: – Visual HDL course – Introduction to VHDL & using the ncvhdl simulator from Cadence http: //cern. ch/humanresources/Training/tech/electronics/te_elec. asp 36

Bibliography • Acknowledgements: – E. van der Bij (CERN), J. Christiansen (CERN) • Further reading: – FPGA vendor sites: http: //www. altera. com http: //www. xilinx. com … – P. Alfke (Xilinx), “Field Programmable Gate Arrays in 2004”, Proceedings of LECC’ 2004. – M. Zwolinski, “Digital System Design with VHDL - 2 nd Ed. ”, Prentice-Hall, 2000, (Chap. 4 & 6) 37
