The Java Assertion

Assertion • A Java statement in JDK 1. 4 & newer • Intent: enables code to test assumptions. E. g. , a method that calculates the a particle’s speed, asserts: speed < c (speed of light). • Has a boolean expression whose value is “asserted” to be true when the assertion executes. – If it is false, the system throws an error. – By evaluating the boolean expression, the assertion confirms assumptions about program behavior. Increases confidence that the program is error-free. 2

Assertion … • Assert: Detecting bugs is quicker when assertions are included in the code. • Assertions also document the program, enhancing maintainability. 3

Outline • Introduction • Using Assertions • Compiling Files That Use Assertions • Enabling & Disabling Assertions 4

Introduction • The assertion statement has 2 forms: assert Expression; // Expression 1 is boolean Meaning: if ( ! Expression ) { throw Assertion. Error // no message } 5

Introduction … assert Expression 1 : Expression 2 ; where: – Expression 1 is boolean – Expression 2 has a value Cannot be the returned value of a void method. Meaning: if ( ! Expression 1 ) { throw new Assertion. Error( Expression 2 ) } // Expression 2’s String value is the message. 6

The Message • Should convey details of the assertion failure • Is not a user-level message • Need not be understandable in isolation • Is intended for use with: – a full stack trace – the source code. 7

Introduction … • The stack trace gives the file/line# of the failed assertion. • Use the message form only to add information that helps diagnose the failure. E. g. , if Expression 1 involves a relationship between variables x & y, use the message form. E. g. , assert x < y : “x: “ + x + “, y: “ + y ; 8

Introduction … • Assertions can be enabled or disabled when the program is started. • Assertions are disabled by default. • Disabled assertions are equivalent to empty statements in semantics & performance. 9

Outline • Introduction • Using Assertions • Compiling Files That Use Assertions • Enabling & Disabling Assertions 10

Using Assertions • Do not use assertions for: argument checking in public methods. Argument checking is part of the method’s published specifications (or contract): Specifications are obeyed whether or not assertions are enabled. • Assert’s expression should have no sideeffects. Exception: assertions can modify state used only from within other assertions (illustrated later). 11

Internal Invariants Replace With if ( i % 3 == 0 ) {. . . } else if ( i % 3 == 1 ) {. . . } else { // We know ( i % 3 == 2 ). . . } {. . . } else { assert i % 3 == 2 : i; . . . } // assert fails for i = -5 12

Control-Flow Invariants Use: assert false; // an unreachable point Replace With void foo() { { for (. . . ) { { if (. . . ) return; } } // unreachable point assert false; // unreachable } 13

Control-Flow Invariants Use: assert false; // an unreachable point • The foregoing only makes sense if reaching a point is possible but erroneous. • If it is impossible, the compiler handles it. • If it is possible, you may always throw an exception Not just when assertions are enabled. Replace “assert false; ” with “throw new Assertion. Error(); ” 14

Preconditions • Do not assert method contracts /** * Sets the refresh rate. * @param rate refresh rate, in frames per second. * @throws Illegal. Argument. Exception if rate <= 0 or * rate > MAX_REFRESH_RATE. */ public void set. Refresh. Rate(int rate) { // Enforce specified precondition in public method if (rate <= 0 || rate > MAX_REFRESH_RATE) throw new Illegal. Argument. Exception("Illegal rate: " + rate); set. Refresh. Interval(1000/rate); } 15

Preconditions … • Assert a nonpublic method's precondition. • An assertion is appropriate in the following “helper” method invoked by the previous method. 16

/** * Sets the refresh interval (to a legal frame rate). * @param interval refresh interval in milliseconds. */ private void set. Refresh. Interval( interval ) { // Confirm adherence to precondition in nonpublic method assert interval > 0 && interval <= 1000/MAX_REFRESH_RATE : interval; . . . // Set the refresh interval } The assertion can fail if MAX_REFRESH_RATE > 1000. 17

Lock-Status Precondition Original private Object[] a; public synchronized int find(Object key) { return find(key, a, 0, a. length); } // Recursive helper method: always has lock on this private int find(Object key, Object[] arr, int start, int len) {. . . } Assert lock status: // Recursive helper method: always has lock on this. private int find(Object key, Object[] arr, int start, int len) { // lock-status assertion assert Thread. holds. Lock(this); . . . } 18

Postconditions Replace void push( Object o ) { With void push( Object o ) { … … stack. add( ++top, o ); // top == stack. size(); assert top == stack. size() : “top: ” } + top + “, size: ” + stack. size(); } 19

Postconditions … • An assert’s expression may need state. void foo(int[] array) { // Manipulate array. . . // At this point, array contents == itself // prior to manipulation } Replace the above with the following. 20

Postconditions … void foo(final int[] array) { // Inner class that saves state & performs final consistency check class Data. Copy { private int[] array. Copy; Data. Copy() { array. Copy = ( int[] ) array. clone(); } boolean is. Consistent() { return Arrays. equals( array, array. Copy ); } } Data. Copy copy = null; // Always succeeds; has side effect of saving a copy of array assert ( ( copy = new Data. Copy() ) != null ); // copy only if ea. . . // Manipulate array // Ensure array has same ints in same order as before. assert copy. is. Consistent(); 21 }

Class State Invariants • Class state invariant: an invariant that applies to all instances at the beginning & ending of all methods. E. g. , in a balanced tree, a class invariant is that the tree is balanced. • Style: combine the expressions that check required constraints into an internal method. // Returns true if this tree is properly balanced private boolean is. Balanced() {. . . } • Assert class invariant just prior to return from public methods & constructors: assert is. Balanced(); 22

Outline • Introduction • Using Assertions • Compiling Files That Use Assertions • Enabling & Disabling Assertions • Compatibility with Existing Programs 23

Compiling Files That Use Assertions To tell javac to accept assertions, use the source 1. 4 command-line option: javac -source 1. 4 My. Class. java 24

Outline • Introduction • Using Assertions • Compiling Files That Use Assertions • Enabling & Disabling Assertions 25

Enabling & Disabling Assertions • • By default, assertions are disabled. Enable assertions, using the -ea, switch. Disable assertions, using the -da, switch. Specify granularity as the switch argument: • no arguments Enables/disables assertions in all classes except system classes. • package. Name. . . Enables/disables assertions in the package & any subpackages. • . . . Enables/disables assertions in the unnamed package in the current working directory. • class. Name Enables/disables assertions in the named class. 26

Enabling & Disabling Assertions • To run Bat. Tutor, with assertions enabled in only package com. wombat. fruitbat & its subpackages: java -ea: com. wombat. fruitbat. . . Bat. Tutor • To run Bat. Tutor with assertions: – enabled in package com. wombat. fruitbat – disabled in class com. wombat. fruitbat. Brickbat: java -ea: com. wombat. fruitbat. . . da: com. wombat. fruitbat. Brickbat Bat. Tutor 27

Enabling & Disabling Assertions To (en/dis)able system class assertions, use: -esa -dsa To run Bat. Tutor with assertions: • enabled in system classes, • enabled in the com. wombat. fruitbat package & its subpackages: java -esa -ea: com. wombat. fruitbat. . . Bat. Tutor 28
