Stacks CS 302 Data Structures Sections 5 1

Stacks CS 302 – Data Structures Sections 5. 1, 5. 2, 6. 1, 6. 5

Warning • Although data structure concepts between this and last semesters will be the same, there might be implementation differences. • Your answers in questions in quizzes and exams should be based on this semester’s (CS 302) implementations!

Definitions • Image. Type. h • Image. Type. cpp • Driver. cpp class specification class implementation application (client code)

Question • In object oriented programming, class implementation details are hidden from applications that use the class. • Why?

What is a stack? • • • It is an ordered group of homogeneous items. Items are added to and removed from the top of the stack LIFO property: Last In, First Out The last item added would be the first to be removed TOP OF THE STACK

Stack Implementations Array-based Linked-list-based

Array-based Stacks template<class Item. Type> class Stack. Type { public: Stack. Type(int); void Make. Empty(); bool Is. Empty() const; bool Is. Full() const; void Push(Item. Type); void Pop(Item. Type&); private: int top, max. Stack; Item. Type *items; }; dynamically allocated array

Array-based Stacks (cont’d) template<class Item. Type> Stack. Type<Item. Type>: : Stack. Type(int size) { top = -1; max. Stack = size; items = new Item. Type[max]; O(1) } template<class Item. Type> Stack. Type<Item. Type>: : ~Stack. Type() { delete [ ] items; } O(1)

Array-based Stacks (cont’d) template<class Item. Type> void Stack. Type<Item. Type>: : Make. Empty() { top = -1; } O(1)

Array-based Stacks (cont. ) template<class Item. Type> bool Stack. Type<Item. Type>: : Is. Empty() const { return (top == -1); } O(1) template<class Item. Type> bool Stack. Type<Item. Type>: : Is. Full() const { return (top == max. Stack-1); } O(1)

Push (Item. Type new. Item) • Function: Adds new. Item to the top of the stack. • Preconditions: Stack has been initialized and is not full. • Postconditions: new. Item is at the top of the stack.

Stack overflow • The condition resulting from trying to push an element onto a full stack. if(!stack. Is. Full()) stack. Push(item);

Array-based Stacks (cont. ) template<class Item. Type> void Stack. Type<Item. Type>: : Push(Item. Type new. Item) { top++; items[top] = new. Item; } O(1)

Pop (Item. Type& item) • Function: Removes top. Item from stack and • • returns it in item. Preconditions: Stack has been initialized and is not empty. Postconditions: Top element has been removed from stack and item is a copy of the removed element.

Stack underflow • The condition resulting from trying to pop an empty stack. if(!stack. Is. Empty()) stack. Pop(item);

Array-based Stacks (cont. ) template<class Item. Type> void Stack. Type<Item. Type>: : Pop(Item. Type& item) { item = items[top]; O(1) top--; }

Templates • Templates allow the compiler to generate multiple versions of a class type by allowing parameterized types. • Compiler generates distinct class types and gives its own internal name to each of the types.

Compiling Templates • Cannot anymore compile Stack. Type. cpp separately from the application of the class (e. g. , driver. cpp) • Compiler needs to know the data type of the stack to instantiate the class! • Where can the compiler find this information?

Compiling Templates (cont’d) // Client code Stack. Type<int> my. Stack; Stack. Type<float> your. Stack; Stack. Type<Str. Type> another. Stack; my. Stack. Push(35); your. Stack. Push(584. 39);

Compiling Templates (cont’d) • Must compile Stack. Type. cpp and client code (e. g. , driver. cpp) together! (1) Use “include” directive to include Stack. Type. cpp at the end of Stack. Type. h (2) “include” Stack. Type. h in client’s code (3) Compile client code

Linked-list-based Stacks template<class Item. Type> struct Node. Type<Item. Type> { Item. Type info; Node. Type<Item. Type>* next; };

Linked-list-based Stacks (cont’d) template<class Item. Type> struct Node. Type<Item. Type>; template<class Item. Type> class Stack. Type { public: Stack. Type(); ~Stack. Type(); void Make. Empty(); bool Is. Empty() const; bool Is. Full() const; void Push(Item. Type); void Pop(Item. Type&); private: Node. Type<Item. Type>* top. Ptr; };

Linked-list-based Stacks (cont’d) template<class Item. Type> Stack. Type<Item. Type>: : Stack. Type() { top. Ptr = NULL; O(1) } template<class Item. Type> void Stack. Type<Item. Type>: : Make. Empty() { Node. Type<Item. Type>* temp. Ptr; while(top. Ptr != NULL) { temp. Ptr = top. Ptr; top. Ptr = top. Ptr->next; delete temp. Ptr; } } O(N)

Linked-list-based Stacks (cont’d) template<class Item. Type> Stack. Type<Item. Type>: : ~Stack. Type() { Make. Empty(); } O(N) template<class Item. Type> bool Stack. Type<Item. Type>: : Is. Empty() const { return(top. Ptr == NULL); } O(1)

Linked-list-based Stacks (cont’d) template<class Item. Type> bool Stack. Type<Item. Type>: : Is. Full() const { Node. Type<Item. Type>* location; location = new Node. Type<Item. Type>; // test if(location == NULL) return true; else { O(1) delete location; return false; } }

Push (Item. Type new. Item) • Function: Adds new. Item to the top of the stack. • Preconditions: Stack has been initialized and is not full. • Postconditions: new. Item is at the top of the stack.

Pushing on a non-empty stack

Pushing on a non-empty stack (cont. ) • The order of changing the pointers is important!

Special Case: pushing on an empty stack

Function Push template <class Item. Type> void Stack. Type<Item. Type>: : Push(Item. Type Push item) { Node. Type<Item. Type>* location; location = new Node. Type<Item. Type>; location->info = new. Item; O(1) location->next = top. Ptr; top. Ptr = location; }

Pop (Item. Type& item) • Function: Removes top. Item from stack and • • returns it in item. Preconditions: Stack has been initialized and is not empty. Postconditions: Top element has been removed from stack and item is a copy of the removed element.

Popping the top element

Popping the top element (cont. ) Need a temporary pointer !

Special case: popping the last element on the stack temp. Ptr

Function Pop template <class Item. Type> void Stack. Type<Item. Type>: : Pop(Item. Type& item) Pop { Node. Type<Item. Type>* temp. Ptr; item = top. Ptr->info; temp. Ptr = top. Ptr; top. Ptr = top. Ptr->next; delete temp. Ptr; } O(1)

Comparing stack implementations Big-O Comparison of Stack Operations Operation Array Linked Implementation Constructor Make. Empty Is. Full Is. Empty Push Pop Destructor O(1) O(1) O(N) O(1) O(N)

Array-vs Linked-list-based Stack Implementations • Array-based implementation is simple but: – The size of the stack must be determined when a stack object is declared. – Space is wasted if we use less elements. – We cannot "enqueue" more elements than the array can hold. • Linked-list-based implementation alleviates these problems but time requirements might increase.

Example using stacks: evaluate postfix expressions • Postfix notation is another way of writing arithmetic • expressions. In postfix notation, the operator is written after the two operands. infix: 2+5 postfix: 2 5 + • Why using postfix notation? Precedence rules and parentheses are not required!

Example: postfix expressions (cont. ) Expressions are evaluated from left to right.

Postfix expressions: Algorithm using stacks (cont. )

Exercise 15: Write the body for a client function that replaces each copy of an item in a stack with another item. Use the following specification. Replace. Item(Stack. Type& stack, Item. Type old. Item, Item. Type new. Item) Function: Replaces all occurrences of old. Item with new. Item. Precondition: stack has been initialized. Postconditions: Each occurrence of old. Item in stack has been replaced by new. Item. Order of other elements remains unchanged. Warning: you may not assume any knowledge of how the stack is implemented!

{ Stack temp. Stack 3 1 2 5 1 3 Item. Type item; Stack. Type temp. Stack; while (!Stack. Is. Empty()) { Stack. Pop(item); if (item==old. Item) temp. Stack. Push(new. Item); else temp. Stack. Push(item); } while (!temp. Stack. Is. Empty()) { temp. Stack. Pop(item); Stack. Push(item); } } Stack 3 old. Item = 2 5 new. Item = 5 1

{ Item. Type item; Stack. Type temp. Stack; while (!Stack. Is. Empty()) { Stack. Pop(item); if (item==old. Item) temp. Stack. Push(new. Item); else temp. Stack. Push(item); } while (!temp. Stack. Is. Empty()) { temp. Stack. Pop(item); Stack. Push(item); } } What are the time requirements using big-O? O(N)

Exercises 19, 20

Exercises 19, 20

Exercise 20 small large

Exercise 20 (cont’d) etc.

Exercise 20 (cont’d)
