The Local Manufacture Leader of ExplosionProof Electrical Equipment
- Slides: 34
The Local Manufacture Leader of Explosion-Proof Electrical Equipment in Saudi Arabia Panel Boards • Circuit Breakers • Junction Boxes • Enclosures • Lighting Fixtures • Switch Racks Designed and Built Locally 2016
ISG, Established in 2008 and Signed manufacturing agreement in the beginning of 2009. ISG is an Authorized, License manufacture of explosion-proof electrical equipment (Panel Boards, Junction Boxes and Enclosures, Lighting Fixtures, etc. ) ISG has 18, 700 m² air-conditioned manufacturing area and is strategically located in 2 nd Industrial Area, Dammam, Kingdom of Saudi Arabia. ABOUT US
q Established since 2008 q ISO 9001: 2008 Management System certified q DEKRA Production Quality Assurance certified: IECEx and ATEX q Manufacture/Customize Explosion Proof Electrical Equipment ABOUT US q 86 Qualified & Well-Trained Staff q 42% are Saudi Nationals
ISG Organization Chart
FACILITIES
EQUIPMENT
The goal of ISG; to meet client's needs accurately, correctly, first time, every time and in the required time, to carry out work consistently satisfying the requirement of our clients. Our strategy; to focus on our customer satisfaction in the Oil and Gas, Petrochemicals, Utilities, instrumentation, Communication, Information Technology, including development of Human Resources. QUALITY POLICY
Hazardous and Non-Hazardous LIST OF PRODUCTS
ISG-CSEW Control Center ISG-JBEW Junction Boxes ISG-EXB Cast Iron Body with Hot. Dipped Galvanized Covers Junction Box: ISG-DTX Junction Boxes D 2 P and EWP Factory Sealed Circuit Breakers Panel boards ISG ALP, APPN AGPN SERIES ISG APPF 480 V Factory Sealed Power Distribution Panel boards Boxes are Copper free Aluminium Cast Junction Boxes: Explosion proof, Dust-Ignition proof used where hazardous materials are handled or stored Junction Boxes, Control Panels & Panel Boards
ISG-GUB and ISG-ETE Enclosures ISG-GUBB Series ISG-GUBBD Series (Dome and Plate) ISG-GUBBM Series (Instrument) Instrument and Meter Enclosures; explosion-proof, Dust-Ignition-proof. Furnished with cast copper-free Aluminium body and solid or window cover. Ideal for use to pull or splice wires and/or to mount and enclose electrical devices in hazardous locations. Explosion-Proof Enclosures
Mercmaster. M lll Low Profile W/Gasket Fixtures for Hazardous and Wet Locations. High Pressure Sodium, Metal Halide, Mercury Vapour and Pulse Start Metal Halide luminaries. Listed for simultaneous exposure to combustible dusts and flammable gases or vapours. Mercmaster. M III Enclosed W/Gasket, HID 50 -250 W Lighting Fixtures High Pressure Sodium, Metal Halide, Pulse Start Metal Halide and Mercury Vapour. Listed for simultaneous exposure to combustible dusts and flammable gases or vapours. Lighting Fixtures
Push Buttons and Selector Switches used in conjunction with contactors or magnetic starters for remote control of motors, providing circuit control and/or selection. Pilot Lights providing visual assurance that of electrical function being performed at a remote or local location. Push Buttons & Selector Switches
Switch Racks
Ladder Cable Tray High Strength Corrosion Resistant FRP Instrumentation / Channel Tray High Strength Corrosion Resistant FRP Strut & Structural Support High Strength Corrosion Resistant FRP Instrument & Pushbutton Stands High Strength Corrosion Resistant FRP Enduro Middle East Engineered Reinforced Fiberglass
Analyzer Shelter, Sampling System, System Integration, Process Analytical Systems Sampling Systems, Analyzer Shelter, System Integration
ISG Organization Chart
ISG Qualifications
ISG Qualifications
ISG Qualifications
ISG Qualifications
Product Machinery Capacity/Year Production Level Junction Boxes 3, 500 2, 800 Motor Starters & Panel Boards 1, 500 ea 900 ea Control Stations 8, 500 3, 900 Light Fixtures 30000 25000 Switchrack, Outdoor Low Voltage 125 120 FRP CABLELADDER TRAY AND ACCESORIES 150, 000 Meter 112, 500 Meter Analyzer Shelter including Process analyzers 25 20 Sample Conditioning Systems (SCS) 100 80 Analyzer Cabinets 80 50 Technical Capabilities
Material Description 9 COM Applicable Standards Electrical Junction Box (Explosion-Proof) 6000000830 CCC Code 150056 Electrical Box; Device & Covers 6000000793 CCC Code 150001 Electrical Junction Box; Aluminum, Steel, Iron, Plastic, or Fiberglass 6000000794 CCC Code 150002 Electrical Box; Outlet or Switch 6000000795 CCC Code 150003 Electrical Box; Terminal L. V Panel board Explosion-Proof 6000000796 6000000897 CCC Code 150004 16 -SAMSS-518 CCC 160069 L. V Panel board Non-Explosion-Proof 6000000859 16 -SAMSS-518 CCC 160024 L. V Switchrack Outdoor 6000000886 16 -SAMSS-512 CCC 160055 Cable Gland 6000000817 CCC Code 150031 SCOPE OF SUPPLY
Material Description 9 COM Applicable Standards Lighting Fixtures Fluorescent 6000000978 CCC Code 170046 Lighting Fixtures HID; Metal Halide 6000000979 CCC Code 170047 Lighting Fixtures HID; Mercury Vapor 6000000981 CCC Code 170049 Lighting Fixtures HID; High Pressure Sodium 6000000983 CCC Code 170051 Plugs & Receptacles 6000000860 CCC Code 160025 Push Button Unit 6000000862 CCC Code 160027 Switch rack, Outdoor – Low Voltage 6000000886 16 -SAMSS-512 CCC 160055 SCOPE OF SUPPLY
Material Description TRAY; CABLE TYPE, FIBERGLASS, NEMA 9 COM Applicable Standards 6000000774 12 -SAMSS-023 6000002898 SAES-J-502 FG 1 BUILDING; ANALYZER TYPE, SAES-J 502, INCLUDES PROCESS ANALYZERS SCOPE OF SUPPLY
Saudi Arabian Oil Company Saudi Basic Industries Corporation Al-Abdulkarim Holding Company Technip JGC Gulf International Saipem SK Engineering & Construction Samsung Technicas Reunidas Worley Parsons Zamil Offshore Al Fanar Co. East West CLIENTS
PARTNERS
Saudi Aramco Approval
Saudi Aramco Approval
HUBBELL KILLARK CERTIFICATION
COOPER LIGHTING & WEIDMUELLER CERTIFICATION
Enduro & Anatrac CERTIFICATION
ISO CERTIFICATION
IECEx CERTIFICATION
Physical Address: 12 th Street, Second Industrial City Mailing Address: P. O. Box 4779 Khobar Central 31952 Kingdom of Saudi Arabia Contact No: +966 13 8123349; 8123280 Fax No: +966 13 8123278 Please refer your inquiries to: rfq@isg. com. sa Visit: www. isg. com. sa ISG CONTACT INFORMATION
