Model Identification Model Identification Clark Hyster Nissan Toyota

Model Identification

Model Identification • Clark • Hyster • Nissan • Toyota • Yale

Clark Model Coding System 1969 -1984 C 500 Series C 500 HY 50 Model Family Special Designation Rated Capacity E: Electric Version 020 = 2, 000 lbs F: Friction Clutch 025 = 2, 500 lbs H: Hydracool Clutch 030 = 3, 000 lbs S: Short Wheel Base 035 = 3, 500 lbs Y: Pneumatic Version 040 = 4, 000 lbs

Clark Serial Coding System 1969 -1984 C 500 Series HY 355 105 2507 Special Designation E: Electric Version Lot Number F: Friction Clutch H: Hydracool Clutch S: Short Wheel Base Y: Pneumatic Version Series 235, E 235, Y 235, F 235, 355, E 355, Y 355, HY 355, 685, E 685, Y 685, HY 685, 915, E 912, H 915, 1015, Y 1015, HY 1015 Sequence Number

Clark Serial Coding System 1985 -1994 GPS 30 MB Fuel Type G: Gas D: Diesel Suffix Repeated In Serial Number Tire Type Rated Capacity P: Pneumatic 020 = 2, 000 lbs C: Cushion 025 = 2, 500 lbs Design 030 = 3, 000 lbs S: Systems Trucks 035 = 3, 500 lbs X: Second Design 040 = 4, 000 lbs

Clark Serial Coding System 1985 -1994 GP 138 MB 105 7168 Fuel Type G: Gas Lot Number D: Diesel Tire Type Sequence Number P: Pneumatic C: Cushion Series Engine Type 127, 138, 230, 711 C: Continental Engine B: Straight Drive Axle with Drum Brakes C: Offset Drive Axle with Oil Cooled Disc Brakes E: Enhanced I: Overhead Valve Continental Engine M: Mitsubishi Engine W: Waukesha Engine

Clark Model Coding System 1995 – Present Genesis CGP 25 C: Clark Rated Capacity E: Electric 10: 2, 000 lbs / 1. 0 ton T: Three Wheel 15: 3, 000 lbs / 1. 5 ton G: Genesis 25: 5, 000 lbs / 2. 5 ton M: Multi-tire 30: 6, 000 lbs / 3. 0 ton C: Cushion G: Genesis P: Pneumatic X: New design, All AC 35: 7, 000 lbs / 3. 5 ton Model Identification 40: 8, 000 lbs / 4. 0 ton CGC: Genesis Series Cushion IC CGP: Genesis Series Pneumatic IC ECG: Four Wheel Sit-down Electric ECX: Current Four Wheel Sit-down Electric ESM 2: Stand-up Counterbalanced Electric TMG: Genesis Series Three Wheel Electric TMX: Current Three Wheel Sit-down Electric

Clark Serial Coding System 1995 – Present Genesis P 365 L-10 -9395 P: Pneumatic Lot Number C: Cushion ECG: Repeats from Model Sequence Number TMG: Repeats from Model Series Fuel Type 232, 248, 250, 268, 360, 365, 460, 470 L: LPG LI: GM 3. 0 LPG C: CNG G: Gas D: Diesel CI: CNG GM 3. 0

Clark Model Coding System 1998 – Present M Series CMP 15 G Series Type Clark “M” Series Fuel Type Tire Type G: Gasoline P: Pneumatic L: LPG C: Cushion Rated Capacity 10: 2, 000 lbs / 1. 0 ton 15: 3, 000 lbs / 1. 5 ton 25: 5, 000 lbs / 2. 5 ton 30: 6, 000 lbs / 3. 0 ton 35: 7, 000 lbs / 3. 5 ton 40: 8, 000 lbs / 4. 0 ton D: Diesel

Clark Serial Coding System 1998 – Present M Series CMP 158 G-101 -6852 Repeats From Model Lot Number Tire Type P: Pneumatic C: Cushion Series 158, 230, 450, 570 Fuel Type G: Gasoline L: LPG D: Diesel Sequence Number

Clark Forklifts Locating the Model and Serial Number The serial number on a Clark is stamped into the data plate, which is usually located in the operator’s compartment. If the data plate is missing or illegible, you can find the serial number stamped into the frame. On a Clark forklift, this will usually be beneath the step into the operator’s compartment and may be either on the left or right side. Key Information Lot Number

Hyster Serial Coding - Prior To 1957 Serial numbers issued prior to 1957 were from specific blocks of numbers assigned on a yearly basis. Early in 1957, the serial number was changed from straight numeric to a four-part alpha/numeric arrangement identifying the design series, manufacturing plant, sequence and year of manufacture. Hyster began to publish a “Technician’s Handbook” to help identify truck models/components. Publications # 872169 and # 599869 will cover current and non-current truck technical data/specifications.

Hyster Serial Coding System C 187 D 19219 B Serial Prefix Manufacturing Date See Model Identification Guide Manufacturing Plant Production Sequence See Model Identification Guide Starts with 01501 at all locations

Hyster IC Model Coding System S 50 XL Model Suffix Model Prefix B: Electric Walkie/Rider C: Electric Walkie, Center Control E: Electric – Counterbalanced Cushion H: Pneumatic Tire Forklift (IC) J: Electric – Counterbalanced Pneumatic N: Electric Narrow Aisle R: Electric Order Picker S: Cushion Tire Forklift (IC) T: Electric Tractor V: Very Narrow Aisle W: Electric Walkie Load Capacity Rating 20 = 2, 000 lbs 30 = 3, 000 lbs 40 = 4, 000 lbs 50 = 5, 000 lbs XL, XM and XN A: Straddle C: Center Control CT: Commercial Grade FT: Fortis™ H: Pneumatic L: Low Level Pallet R: Reach S: Short Wheelbase T: Three Wheel DR: MD: MU: Double Reach Man Down Man Up **Suffixes XL and XM denote a design concept and have no other meaning

Hyster Electric Model Coding System E 60 XM-33 Model Prefix Model Suffix B: Electric Walkie/Rider XL, XM and XN C: Electric Walkie, Center Control A: Straddle E: Electric – Counterbalanced Cushion C: Center Control H: Pneumatic Tire Forklift (IC) CT: Commercial Grade J: Electric – Counterbalanced FT: Fortis™ Pneumatic H: Pneumatic N: Electric Narrow Aisle L: Low Level Pallet R: Electric Order Picker R: Reach S: Cushion Tire Forklift (IC) S: Short Wheelbase T: Electric Tractor Load Capacity T: Three Wheel V: Very Narrow Aisle 20 = 2, 000 lbs DR: Double Reach W: Electric Walkie 30 = 3, 000 lbs MD: Man Down 40 = 4, 000 lbs MU: Man Up 50 = 5, 000 lbs Battery Compartment Size (in inches)

Hyster Mast Identification Unique serial numbers are assigned to all mast assemblies and attachments so that the individual mast of attachment can be identified for content, manufacturing location/date and service requirements The location of the serial number and/or part number is shown in the illustration to the left. The serial number format, serial number code, plant location and lift height are as below: Example: A 510 1 A 2 1501 3 2960 4 1 Indicates the design series and model according to the serial number prefix code in the Tech Handbook. 2 Identifies the manufacturing plant (page one of the Tech Handbook). 3 Indicates the sequence of manufacture at the identified plant. 4 Indicates the total lift height of the mast in millimeters.

Hyster Forklifts Locating the Model and Serial Number The data plate is on the dash or hood on the right side near the hydraulic control levers. If the serial number is missing, it can be found stamped on the right side where the counterweight meets the frame. Key Information Serial Number Prefix: ex. B 187 Engine Type: This is needed for most, if not all, Hyster parts look ups requiring engine parts. If you cannot identify the engine, you should be able to find the part number for the valve cover (stamped into the valve cover) and track the engine down. Mast Number: If you are looking for mast parts, you need the mast number. This information is generally stamped on the right side of the mast on the outer channel (near the tilt cylinder). In larger trucks (i. e. H 300 HD) the mast info will be found stamped onto a plate welded onto the mast where the tilt cylinder connects to the mast (right side as you are sitting in the truck).

Exercise 1 Your customer calls with a Hyster E 50 XM 2 -27 (S/N F 108 V 15840 D). He’s looking for the following parts: • Traction Motor Brushes (Note: The customer has an 11. 0” motor with BWI. The numbers on the motor are 2038113. ) • Drive Axle Seals • Drive Axle Bearings

Exercise 2 Your customer with the Hyster E 50 XM 2 -27 (S/N F 108 V 15840 D) called back. He’s now looking for the following parts: • Battery Roller Tray • Plate • Roller Tray Gate • Emergency Power Bypass Switch

Exercise 3 Hyster E 50 XM 2 -27 (S/N F 108 V 15840 D) is back again. His operator had a run in with a stubborn dock door, and he now needs the following parts: • Free Lift Seal Kit (Note: When asked, the customer gives B 564 C 2860 V for the mast. If asked further, he states this is a two-stage, full free-lift mast. ) • Free Lift Cylinder Rod • LH Lift Cylinder (Note: Need to determine what the ECN affects. ECN 76380 affects S/N F 108 V 15841 D ) • Mast Channel Rollers

Answers: Exercise 1 Your customer calls with a Hyster E 50 XM 2 -27 (S/N F 108 V 15840 D). He’s looking for the following parts: • Traction Motor Brushes (Note: The customer has an 11. 0” motor with BWI. The numbers on the motor are 2038113. ) 1461816 Brush Kit (1) • Drive Axle Seals Outer 325568 (2) Inner 1354997 (2) • Drive Axle Bearings o Outer (2) 264893 (cup) (2) 264892 (cone) o Inner (2) 30076 (cup) (2) 230443 (cone)

Answers: Exercise 2 Your customer with the Hyster E 50 XM 2 -27 (S/N F 108 V 15840 D) called back. He’s now looking for the following parts: • Battery Roller Tray 1376802 • Plate 1376804 • Roller Tray Gate 1380810 • Emergency Power Bypass Switch 2054597

Answers: Exercise 3 Hyster E 50 XM 2 -27 (S/N F 108 V 15840 D) is back again. His operator had a run in with a stubborn dock door, and he now needs the following parts: • Free Lift Seal Kit (Note: When asked, the customer gives B 564 C 2860 V for the mast. If asked further, he states this is a twostage, full free-lift mast. ) 1358969 • Free Lift Cylinder Rod 1356679 • LH Lift Cylinder (Note: Need to determine what the ECN affects. ECN 76380 affects S/N F 108 V 15841 D ) 1342280 • Mast Channel Rollers (4) 1333396

Nissan Gas Powered Model Coding System KCUGJ 02 F 35 PV New KH 01 or KH 02 Series Tire Type No Letter: Pneumatic C: Cushion A: Engine Compact Type Pneumatic No Letter: A 15, J 15 (Gas) B: E: H: P: Q: R: U: (Gas) W: TB 42 (Gas) SD 25 (Diesel) H 30 (Gas) H 20 -II, K 21 (Gas) SD 22 (Diesel) Z 24 (Gas) H 25, K 25, P 40 TD 42 (Diesel) Transmission A: Automatic (1 -speed) F: Automatic (2 -speed) M: Manual Basic Model CF 01, CF 02, F 01, F 02, F 03, F 05, H 01, H 02, KH 01, KH 02, J 01, J 02, L 01, L 02 Wheel Base No Letter: G: Long S: Short Standard

Nissan Gas Powered Model Coding System KCUGJ 02 F 35 PV Load Capacity Rating Destination 10: 15: 18: 20: 25: 30: V: North America U: Europe & General Areas S: North America UL “GS” & “LPS” Type 2, 000 lbs / 1. 0 ton 3, 000 lbs / 1. 5 ton 3, 500 lbs / 1. 75 ton 4, 000 lbs / 2. 0 ton 5, 000 lbs / 2. 5 ton 6, 000 lbs / 3. 0 ton Fuel Type No Letter: Gas D: Dual EFI (Electronic Fuel Injection) J: Gasoline EFI L: LPG EFI P: LPG W: Gas & LPG (Dual Fuel)

Nissan Electric Powered Model Coding System CWGP 02 L 25 AS Tire Type No Letter: Pneumatic C: Cushion Traction Motor Output or Size W: 9. 9 KW (GE) H: 9. 2 KW (at closed) (GE) D: 300 mm diameter M: 2. 5 KW U: 250 mm diameter U: 7. 5 KW Y: 276 mm diameter Y: 10 KW Load Capacity Rating 10: 15: 18: 20: 25: 30: 2, 000 lbs / 1. 0 ton 3, 000 lbs / 1. 5 ton 3, 500 lbs / 1. 75 ton 4, 000 lbs / 2. 0 ton 5, 000 lbs / 2. 5 ton 6, 000 lbs / 3. 0 ton Body Size L: Standard Wheel Base Basic Model No Letter: Standard G: Long A 01, B 02, M 01, M 02, N 01, P 02

Nissan Electric Powered Model Coding System CWGP 02 L 25 AS Application No Letter: Standard F: Cold Storage A: Seat Brake R: Long Battery Compartment Destination S: North American UL ES Type E: North American UL EE Type

Nissan Forklifts • Locating the Model and Serial Number The data plate is located on the right side of the dash or hood. If the serial number is missing, it can be found stamped on the right side of the frame. • Key Information Full Model Number

Toyota Model & Serial Coding System 42 -6 FGCU 20 - 10447 Engine Type See Chart Transmission 0: Manual 1: Manual w/Dual Tires 2: Power Shift 3: Power Shift w/Dual Model Changes Tires No Number: Original 2: 2 nd Generation 3: 3 rd Generation 4: 4 th Generation Type of Vehicle th 5: 5 Generation F: Forklift th 6: 6 Generation S: Shovel 7: 7 th Generation Loader 8: 8 th Generation T: Towing Tractor Manufacturing Country U: United States No Letter: Japan Tire Type/Special Construction No Letter: Pneumatic A: High capacity battery, other C: Cushion E: Three Wheel, Heavy Duty, Sit Down Type of Power B: Motor D: G: Battery & Electric Diesel Gas

Toyota Model & Serial Coding System 42 -6 FGCU 20 - 10447 Load Capacity 10 = 1, 000 K = 2, 205 lbs 15 = 1, 500 K = 3, 308 lbs 20 = 2, 000 K = 4, 409 lbs 23 = 2, 300 K = 5, 070 lbs 25 = 2, 500 K = 5, 511 lbs Serial Number

Toyota Forklifts • Locating the Model and Serial Number The year of manufacture for a Toyota forklift is determined by the frame number, found on the load capacity plate on the front cowl. It is also stamped on the top or either side of the frame. • Key Information Full Model Number

Yale Gas Powered Model Coding System GLC 035 BCNNAS 083 Fuel Type G: GL: GT: GD: Gasoline LP Gas Dual Fuel Diesel Tire Type Design Series C: P: (A, B, C, etc. ) Cushion Pneumatic Rated Capacity 020 = 2, 000 lbs 025 = 2, 500 lbs 030 = 3, 000 lbs 035 = 3, 500 lbs 040 = 4, 000 lbs Special Designation

Yale Gas Powered Model Coding System GLC 035 BCNNAS 083 Manufacturing Source N: J: North America Japan Retracted Mast Height Engine Type (in inches) N: U: F 2, VA, G: S: H 225 P: F: Type Continental F 163 Mazda UA, FE, D 5, XA, ZB, TM GM V 6 4. 3 Liter Mast Chrysler H 239, Transmission A: Automatic S: M: Manual D: Perkins 4. 203 Ford 192 B: Automatic 2 -speed T: Simplex Duplex Triplex

Yale Electric Powered Model Coding System ELC 030 ABN 36 SV 083 Power/Model E: M: N: OS: Type of Vehicle C: DR: E: L: P: R: Aisle) R: S: S: S: Design Series Electric Motorized Hand Narrow Aisle Order Selector (A, B, C, etc. ) Tire Type Counterbalanced C: Cushion Double Reach P: Pneumatic Extend Platform Operator Position Pallet E: End Control Reach (Narrow C: Center Control W: Walk Control Sit Down Rider SUEC Rider Battery Power Stacker No Letter: Industrial Battery Straddle B: Power Pack w. Charger Special Designation Rated Capacity 020 = 2, 000 lbs 025 = 2, 500 lbs 030 = 3, 000 lbs 035 = 3, 500 lbs 040 = 4, 000 lbs

Yale Electric Powered Model Coding System ELC 030 ABN 36 SV 083 Manufacturing Source N: J: North America Japan Voltage Control S: T: C: SCR Transistor Contactor Mast Type V or S: F or D: E or T: Q: Simplex Duplex Triplex Quadplex Retracted Mast Height (in inches)

Yale Serial Coding System 1995 & Prior N 523910 Serial Number Prefix Serial Number Used to Determine Year of Manufacture 523910 = 1992

Yale Serial Coding System 1973 - 1994 During the years from 1973 to 1994, blocks of serial numbers were assigned to various plants or models. Below are the blocks used in each year. 1973 1974 1975 1976 220000 – 222908 222910 – 226620 226621 – 227866 227867 – 228891 213739 – 219999 100000 – 100691 100692 – 100999 289800 – 290499 230000 – 242000 241001 – 282900 282901 – 289799 290700 – 291299 293500 – 293900 293966 - 294099 1977 294237 - 269499 228892 – 229999 296500 – 297099 309100 – 310250 297100 – 299077 303280 – 303599 299100 – 299599 303600 – 304099 301600 – 303599 305050 – 305099 304100 – 305099 305100 – 306099 306100 – 309099 319100 – 328599 329100 – 329599 331000 – 331297

Yale Serial Coding System 1973 - 1994 1978 310251 – 311999 328600 – 329099 329600 – 330099 331300 – 333999 334000 – 334999 335000 – 338999 339000 – 339860 342000 – 342940 1982 380300 – 380489 381450 – 382400 371400 – 372425 372500 – 373199 374600 – 374800 375200 – 376299 385400 – 385999 386300 – 389900 390900 - 391750 1979 312000 – 31500 342941 – 345499 345500 – 346599 346600 – 353099 353100 – 354099 354100 – 354600 357100 – 357599 357600 – 358099 1980 315001 – 317000 354601 – 357099 358100 – 362599 363700 – 365400 366700 – 367199 367200 – 367745 368300 – 368525 1981 317001 – 319009 380500 – 380730 381336 – 381449 388800 – 388807 365401 – 366699 367746 – 367785 368526 – 370299 377300 – 378600 379300 – 379699 386000 – 386299 373200 – 374599

Yale Serial Coding System 1973 - 1994 1983 1984 1985 1986 376300 – 377299 384801 – 385299 404951 – 410999 422000 – 423425 378601 – 379299 396501 – 399150 415501 – 421999 425710 – 433100 382401 – 384800 399400 – 404950 424550 – 425700 437700 – 444500 389901 – 390899 411000 – 415500 391751 – 392800 393400 – 396500 1987 1988 1989 1990 433200 – 437699 452841 – 453249 465000 – 465590 465600 – 466350 444501 – 452840 453981 – 458299 474000 – 477399 477400 – 477864 459531 – 459699 477865 – 490899 490900 – 505200 459851 – 459999 463251 – 464900 466351 – 473999

Yale Serial Coding System 1973 - 1994 1991 1992 1993 1994 505201 – 509999 514000 – 515129 526000 – 526999 546124 – 550000 511001 – 513999 516000 – 516837 532958 – 533999 550861 – 552000 517056 – 518946 519100 – 525991 536822 – 547124 555609 – 565409 527000 – 532957 550001 – 550859 567001 – 569869 534000 – 536821 552001 – 555623 573000 – 574360 556081 – 583495 580001 – 581078 591501 – 591685 601407 – 601768 701402 – 701947 851402 – 854579

Yale Serial Coding System Post 1995 B 813 D 11364 V Model Family & Design Series Plant Designator Serial Number Year of Manufacture S through Z represent 1995 – 2002, starts over with A in 2003 S: 1995 T: 1996 U: 1997 V: 1998

Yale Forklifts • Locating the Model and Serial Number The data plate is located on the right side of the dash or hood. If the serial number is missing, it can be found stamped on the right side of the frame. • Key Information The two letters after the rated capacity in the model number.

Exercise 1 Your customer has a Yale GLP 050 TENUAV 086 (S/N N 854579). He is in need of the following parts: • • • Impco Carburetor Assembly Fuel Filter Repair Kit Vaporizer Repair Kit

Exercise 2 Your GLP 050 TENUAV 086 (S/N of N 854579) customer is back! And he needs more parts. • • • Lift Cylinder Assembly Mast Trunion Bushings Lift Cylinder Hydraulic Hoses Left-hand Right-hand Dog Bones Steer Cylinder Packing Kit Steer Axle Mounting Bushings

Answers: Exercise 1 Your customer has a Yale GLP 050 TENUAV 086 (S/N N 854579). He is in need of the following parts: • Impco Carburetor Assembly 9050356 -02 • Fuel Filter Repair Kit 9009708 -20 • Vaporizer Repair Kit 5170808 -00

Answers: Exercise 2 Your GLP 050 TENUAV 086 (S/N of N 854579) customer is back! And he needs more parts. • • • Lift Cylinder Assembly 503072718 Mast Trunion Bushings 518998011 Lift Cylinder Hydraulic Hoses 506387801 and 1299913 -06 Left-hand Right-hand Dog Bones Steering links 9151364 -00 Steer Cylinder Packing Kit Did you find the number that is stamped in the cylinder? It is 911427600. The kit is 9017888 -10. Steer Axle Mounting Bushings 9166673 -00 (2)

Competitive Parts Guide Link http: //www. mcfadealers. com/~/media/MCFA/Sites/Portal/Files/Parts%20 and%20 Service/Training/Parts%20 Traini ng/Bootcamp/Competitive%20 Model%20 Identification%20 Guide. pdf
