MACHINE-LEVEL PROGRAMMING III: SWITCH STATEMENTS AND IA 32 PROCEDURES

University of Texas at Austin Today • Switch statements • IA 32 Procedures • Stack Structure • Calling Conventions • Illustrations of Recursion & Pointers 2

University of Texas at Austin long switch_eg (long x, long y, long z) { long w = 1; switch(x) { case 1: w = y*z; break; case 2: w = y/z; /* Fall Through */ case 3: w += z; break; case 5: case 6: w -= z; break; default: w = 2; } return w; } Switch Statement Example • Multiple case labels • Here: 5 & 6 • Fall through cases • Here: 2 • Missing cases • Here: 4 3

University of Texas at Austin Jump Table Structure Switch Form switch(x) { case val_0: Block 0 case val_1: Block 1 • • • case val_n-1: Block n– 1 } Approximate Translation target = JTab[x]; goto *target; Jump Table jtab: Targ 0 Targ 1 Targ 2 • • • Targn-1 Jump Targets Targ 0: Code Block 0 Targ 1: Code Block 1 Targ 2: Code Block 2 • • • Targn-1: Code Block n– 1 4

University of Texas at Austin Switch Statement Example (IA 32) long switch_eg(long x, long y, long z) { long w = 1; switch(x) {. . . } return w; } What range of values takes default? Setup: switch_eg: pushl %ebp movl %esp, %ebp movl 8(%ebp), %eax cmpl $6, %eax ja. L 2 jmp *. L 7(, %eax, 4) # # # Setup %eax = x Compare x: 6 If unsigned > goto default Goto *JTab[x] Note that w not initialized here 5

University of Texas at Austin Switch Statement Example (IA 32) long switch_eg(long x, long y, long z) { long w = 1; switch(x) {. . . } return w; } Setup: Indirect jump switch_eg: pushl %ebp movl %esp, %ebp movl 8(%ebp), %eax cmpl $6, %eax ja. L 2 jmp *. L 7(, %eax, 4) # # # Jump table. section. align 4. L 7: . long . rodata. L 2 #. L 3 #. L 4 #. L 5 #. L 2 #. L 6 # x x x x Setup eax = x Compare x: 6 If unsigned > goto default Goto *JTab[x] = = = = 0 1 2 3 4 5 6 6

University of Texas at Austin Assembly Setup Explanation • Table Structure • Each target requires 4 bytes • Base address at. L 7 • Jumping • Direct: jmp. L 2 • Jump target is denoted by label Jump table. section. rodata. align 4. L 7: . long. L 2 # x = 0. long. L 3 # x = 1. long. L 4 # x = 2. long. L 5 # x = 3. long. L 2 # x = 4. L 2. long. L 6 # x = 5. long. L 6 # x = 6 • Indirect: jmp *. L 7(, %eax, 4) • Start of jump table: . L 7 • Must scale by factor of 4 (labels have 32 -bits = 4 Bytes on IA 32) • Fetch target from effective Address. L 7 + eax*4 • Only for 0 ≤ x ≤ 6 7

University of Texas at Austin Jump Table Jump table. section. rodata. align 4. L 7: . long. L 2 # x = 0. long. L 3 # x = 1. long. L 4 # x = 2. long. L 5 # x = 3. long. L 2 # x = 4. long. L 6 # x = 5. long. L 6 # x = 6 switch(x) { case 1: //. L 3 w = y*z; break; case 2: //. L 4 w = y/z; /* Fall Through */ case 3: //. L 5 w += z; break; case 5: case 6: //. L 6 w -= z; break; default: //. L 2 w = 2; } 8

University of Texas at Austin Handling Fall-Through long w = 1; . . . switch(x) {. . . case 2: w = y/z; /* Fall Through */ case 3: w += z; break; . . . } case 3: w = 1; goto merge; case 2: w = y/z; merge: w += z; 9

University of Texas at Austin Code Blocks (Partial) switch(x) { case 1: //. L 3 w = y*z; break; . . . case 3: //. L 5 w += z; break; . . . default: //. L 2 w = 2; } . L 2: # Default movl $2, %eax # w = 2 jmp. L 8 # Goto done. L 5: # x == 3 movl $1, %eax # w = 1 jmp. L 9 # Goto merge. L 3: movl 16(%ebp), imull 12(%ebp), jmp. L 8 # x == 1 %eax # z %eax # w = y*z # Goto done 10

University of Texas at Austin Code Blocks (Rest) switch(x) {. . . case 2: //. L 4 w = y/z; /* Fall Through */ merge: //. L 9 w += z; break; case 5: case 6: //. L 6 w -= z; break; } . L 4: # x == 2 movl 12(%ebp), %edx movl %edx, %eax sarl $31, %edx idivl 16(%ebp) # w = y/z. L 9: # merge: addl 16(%ebp), %eax # w += z jmp. L 8 # goto done. L 6: # x == 5, 6 movl $1, %eax # w = 1 subl 16(%ebp), %eax # w = 1 -z 11

University of Texas at Austin x 86 -64 Switch Implementation • Same general idea, adapted to 64 -bit code • Table entries 64 bits (pointers) Jump Table • Cases use {revised code. section switch(x) case 1: //. L 3 w = y*z; break; . . . }. L 3: movq imulq ret %rdx, %rax %rsi, %rax . rodata . align 8. L 7: . quad. L 2. quad. L 3. quad. L 4. quad. L 5. quad. L 2. quad. L 6 # # # # x x x X x = = = = 0 1 2 3 4 5 6 13

University of Texas at Austin IA 32 Object Code • Setup • Label. L 2 becomes address 0 x 8048422 • Label. L 7 becomes address 0 x 8048660 Assembly Code switch_eg: . . . ja. L 2 # If unsigned > goto default jmp *. L 7(, %eax, 4) # Goto *JTab[x] Disassembled Object Code 08048410 <switch_eg>: . . . 8048419: 77 07 ja 804841 b: ff 24 85 60 86 04 08 jmp 8048422 <switch_eg+0 x 12> *0 x 8048660(, %eax, 4) 14

University of Texas at Austin IA 32 Object Code (cont. ) • Jump Table • • Doesn’t show up in disassembled code Can inspect using GDB gdb switch (gdb) x/7 xw 0 x 8048660 • Examine 7 hexadecimal format “words” (4 -bytes each) • Use command “help x” to get format documentation 0 x 8048660: 0 x 8048670: 0 x 08048422 0 x 08048432 0 x 0804844 b 0 x 0804843 b 0 x 0804844 b 0 x 08048429 15

University of Texas at Austin IA 32 Object Code (cont. ) • Deciphering Jump Table 0 x 8048660: 0 x 8048670: 0 x 08048422 0 x 08048432 0 x 0804844 b 0 x 0804843 b 0 x 0804844 b Address Value x 0 x 8048660 0 x 8048422 0 0 x 8048664 0 x 8048432 1 0 x 8048668 0 x 804843 b 2 0 x 804866 c 0 x 8048429 3 0 x 8048670 0 x 8048422 4 0 x 8048674 0 x 804844 b 5 0 x 8048678 0 x 804844 b 6 0 x 08048429 16

University of Texas at Austin Disassembled Targets 8048422: 8048427: 8048429: 804842 e: 8048430: 8048432: 8048435: 8048439: 804843 b: 804843 e: 8048440: 8048443: 8048446: 8048449: 804844 b: 8048450: 8048453: 8048454: b 8 eb b 8 66 eb 8 b 0 f eb 8 b 89 c 1 f 7 03 eb b 8 2 b 5 d c 3 02 2 a 01 90 14 45 af 18 55 d 0 fa 7 d 45 08 01 45 00 00 00 10 45 0 c 0 c 1 f 10 10 00 00 00 10 mov jmp mov xchg jmp mov imul jmp mov sar idivl add jmp mov sub pop ret $0 x 2, %eax 8048453 <switch_eg+0 x 43> $0 x 1, %eax %ax, %ax # noop 8048446 <switch_eg+0 x 36> 0 x 10(%ebp), %eax 0 xc(%ebp), %eax 8048453 <switch_eg+0 x 43> 0 xc(%ebp), %edx, %eax $0 x 1 f, %edx 0 x 10(%ebp), %eax 8048453 <switch_eg+0 x 43> $0 x 1, %eax 0 x 10(%ebp), %eax %ebp 17

University of Texas at Austin Matching Disassembled Targets Value 0 x 8048422 0 x 804843 b 0 x 8048429 0 x 8048422 0 x 804844 b 8048422: 8048427: 8048429: 804842 e: 8048430: 8048432: 8048435: 8048439: 804843 b: 804843 e: 8048440: 8048443: 8048446: 8048449: 804844 b: 8048450: 8048453: 8048454: mov jmp mov xchg jmp mov imul jmp mov sar idivl add jmp mov sub pop ret $0 x 2, %eax 8048453 <switch_eg+0 x 43> $0 x 1, %eax %ax, %ax 8048446 <switch_eg+0 x 36> 0 x 10(%ebp), %eax 0 xc(%ebp), %eax 8048453 <switch_eg+0 x 43> 0 xc(%ebp), %edx, %eax $0 x 1 f, %edx 0 x 10(%ebp), %eax 8048453 <switch_eg+0 x 43> $0 x 1, %eax 0 x 10(%ebp), %eax %ebp 18

University of Texas at Austin Summarizing • C Control • • if-then-else do-while, for switch • Assembler Control • • Conditional jump Conditional move Indirect jump Compiler generates code sequence to implement more complex control • Standard Techniques • Loops converted to do-while form • Large switch statements use jump tables • Sparse switch statements may use decision trees 19

University of Texas at Austin Today • Switch statements • IA 32 Procedures • Stack Structure • Calling Conventions • Illustrations of Recursion & Pointers 20

University of Texas at Austin IA 32 Stack • Region of memory managed with stack discipline • Grows toward lower addresses • Register %esp contains lowest stack address Stack “Bottom” Increasing Addresses • address of “top” element Stack Grows Down Stack Pointer: %esp Stack “Top” 21

University of Texas at Austin IA 32 Stack: Push Stack “Bottom” • pushl Src • Fetch operand at Src • Decrement %esp by 4 • Write operand at address given by %esp Stack Pointer: %esp Increasing Addresses Stack Grows Down -4 Stack “Top” 22

University of Texas at Austin IA 32 Stack: Pop Stack “Bottom” Increasing Addresses Stack Pointer: %esp +4 Stack Grows Down Stack “Top” 23

University of Texas at Austin Procedure Control Flow • Use stack to support procedure call and return • Procedure call: call label • Push return address on stack • Jump to label • Return address: • Address of the next instruction right after call • Example from disassembly 804854 e: e 8 3 d 06 00 00 call 8048 b 90 <main> 8048553: 50 pushl %eax • Return address = 0 x 8048553 • Procedure return: ret • Pop address from stack • Jump to address 24

University of Texas at Austin Procedure Call Example 804854 e: 8048553: e 8 3 d 06 00 00 50 call pushl 8048 b 90 <main> %eax call 8048 b 90 0 x 110 0 x 10 c 0 x 108 %esp 123 0 x 108 %eip 0 x 804854 e %eip: program counter 0 x 108 123 0 x 104 0 x 8048553 %esp 0 x 104 %eip 0 x 8048 b 90 25

University of Texas at Austin Procedure Return Example 8048591: c 3 ret %eip: program counter 0 x 110 0 x 10 c 0 x 108 123 0 x 104 0 x 8048553 %esp 0 x 104 %esp 0 x 108 %eip 0 x 8048591 %eip 0 x 8048553 26

University of Texas at Austin Stack-Based Languages • Languages that support recursion • e. g. , C, Pascal, Java • Code must be “Reentrant” • Multiple simultaneous instantiations of single procedure • Need some place to store state of each instantiation • Arguments • Local variables • Return pointer • Stack discipline • State for given procedure needed for limited time • From when called to when return • Callee returns before caller does • Stack allocated in Frames • state for single procedure instantiation 27

University of Texas at Austin Call Chain Example yoo(…) { • • who(); • • } Example Call Chain who(…) { • • • am. I(); • • • } yoo am. I(…) { • • am. I(); • • } who am. I Procedure am. I() is recursive 28

University of Texas at Austin Stack Frames Previous Frame • Contents • Local variables • Return information • Temporary space Frame Pointer: %ebp Frame for proc Stack Pointer: %esp • Management • Space allocated when enter procedure Stack “Top” • “Set-up” code • Deallocated when return • “Finish” code 29

University of Texas at Austin Example yoo(…) { • • who(); • • } Stack yoo %ebp yoo who am. I %esp am. I 30

University of Texas at Austin Example yoo(…) { who(…) • { • • am. I(); who(); • • • am. I(); • • • } } Stack yoo yoo who am. I %ebp am. I %esp who am. I 31

University of Texas at Austin Example yoo(…) { who(…) • { am. I(…) • • { am. I(); who(); • • am. I(); • } • } Stack yoo yoo who am. I %ebp am. I %esp am. I 32

University of Texas at Austin Example yoo(…) { who(…) • { am. I(…) • • { am. I(); who(); am. I(…) • • { • • • am. I(); • • } • am. I(); • } Stack yoo yoo who am. I %ebp am. I %esp 33

University of Texas at Austin Example yoo(…) { who(…) • { am. I(…) • • { am. I(); who(); am. I(…) • • { • • • am. I(); • am. I(…) • • am. I(); • • { } • am. I(); • • • } • am. I(); • } Stack yoo yoo who am. I %ebp am. I %esp 34

University of Texas at Austin Example yoo(…) { who(…) • { am. I(…) • • { am. I(); who(); am. I(…) • • { • • • am. I(); • • } • am. I(); • } Stack yoo yoo who am. I %ebp am. I %esp 35

University of Texas at Austin Example yoo(…) { who(…) • { am. I(…) • • { am. I(); who(); • • am. I(); • } • } Stack yoo yoo who am. I %ebp am. I %esp am. I 36

University of Texas at Austin Example yoo(…) { who(…) • { • • am. I(); who(); • • • am. I(); • • • } } Stack yoo yoo who am. I %ebp am. I %esp who am. I 37

University of Texas at Austin Example yoo(…) { who(…) • { am. I(…) • • { am. I(); who(); • • am. I(); • } • } Stack yoo yoo who am. I %ebp am. I %esp am. I 38

University of Texas at Austin Example yoo(…) { who(…) • { • • am. I(); who(); • • • am. I(); • • • } } Stack yoo yoo who am. I %ebp am. I %esp who am. I 39

University of Texas at Austin Example yoo(…) { • • who(); • • } Stack yoo %ebp yoo who am. I %esp am. I 40

University of Texas at Austin IA 32/Linux Stack Frame • Current Stack Frame (“Top” to Bottom) Caller • “Argument build: ” Frame Parameters for function about to call Frame pointer • Local variables %ebp If can’t keep in registers • Saved register context • Old frame pointer • Caller Stack Frame • Return address • Pushed by call instruction • Arguments for this call Stack pointer %esp Arguments Return Addr Old %ebp Saved Registers + Local Variables Argument Build 41

University of Texas at Austin Revisiting swap Calling swap from call_swap int course 1 = 15213; int course 2 = 18243; void call_swap() { swap(&course 1, &course 2); } void swap(int *xp, int *yp) { int t 0 = *xp; int t 1 = *yp; *xp = t 1; *yp = t 0; } call_swap: • • • subl movl call • • • $8, %esp $course 2, 4(%esp) $course 1, (%esp) swap Resulting Stack %esp &course 2 subl &course 1 %esp Rtn adr %esp call 42

University of Texas at Austin Revisiting swap void swap(int *xp, int *yp) { int t 0 = *xp; int t 1 = *yp; *xp = t 1; *yp = t 0; } swap: pushl %ebp movl %esp, %ebp pushl %ebx movl movl 8(%ebp), %edx 12(%ebp), %ecx (%edx), %ebx (%ecx), %eax, (%edx) %ebx, (%ecx) popl ret %ebx %ebp Set Up Body Finish 43

University of Texas at Austin swap Setup #1 Entering Stack Resulting Stack %ebp • • • &course 2 yp &course 1 xp Rtn adr %esp Rtn adr Old %ebp %esp swap: pushl %ebp movl %esp, %ebp pushl %ebx 44

University of Texas at Austin swap Setup #2 Entering Stack Resulting Stack %ebp • • • &course 2 yp &course 1 xp Rtn adr %esp Rtn adr Old %ebp %esp swap: pushl %ebp movl %esp, %ebp pushl %ebx 45

University of Texas at Austin swap Setup #3 Entering Stack Resulting Stack %ebp • • • &course 2 yp &course 1 xp Rtn adr %esp Rtn adr Old %ebp Old %ebx %esp swap: pushl %ebp movl %esp, %ebp pushl %ebx 46

University of Texas at Austin swap Body Entering Stack Resulting Stack %ebp • • • Offset relative to %ebp • • • &course 2 12 yp &course 1 8 xp 4 Rtn adr %esp movl 8(%ebp), %edx movl 12(%ebp), %ecx. . . Old %ebp Old %ebx %esp # get xp # get yp 47

University of Texas at Austin swap Finish Stack Before Finish Resulting Stack %ebp • • • popl %ebx %ebp • • • yp yp xp xp Rtn adr Old %ebp Old %ebx %esp ¢ %esp Observation § Saved and restored register %ebx § Not so for %eax, %ecx, %edx 48

University of Texas at Austin Disassembled swap 08048384 <swap>: 8048384: 55 8048385: 89 e 5 8048387: 53 8048388: 8 b 55 08 804838 b: 8 b 4 d 0 c 804838 e: 8 b 1 a 8048390: 8 b 01 8048392: 89 02 8048394: 89 19 8048396: 5 b 8048397: 5 d 8048398: c 3 push mov mov pop ret %ebp %esp, %ebp %ebx 0 x 8(%ebp), %edx 0 xc(%ebp), %ecx (%edx), %ebx (%ecx), %eax, (%edx) %ebx, (%ecx) %ebx %ebp Calling Code 80483 b 4: 80483 bc: 80483 c 3: 80483 c 8: 80483 c 9: movl call leave ret $0 x 8049658, 0 x 4(%esp) # $0 x 8049654, (%esp) # 8048384 <swap> # # # Copy &course 2 Copy &course 1 Call swap Prepare to return Return 49

University of Texas at Austin Today • Switch statements • IA 32 Procedures • Stack Structure • Calling Conventions • Illustrations of Recursion & Pointers 50

University of Texas at Austin Register Saving Conventions • When procedure yoo calls who: • yoo is the caller • who is the callee • Can register be used for temporary storage? yoo: • • • movl $15213, %edx call who addl %edx, %eax • • • ret who: • • • movl 8(%ebp), %edx addl $18243, %edx • • • ret • Contents of register %edx overwritten by who • This could be trouble ➙ something should be done! • Need some coordination 51

University of Texas at Austin Register Saving Conventions • When procedure yoo calls who: • yoo is the caller • who is the callee • Can register be used for temporary storage? • Conventions • “Caller Save” • Caller saves temporary values in its frame before the call • “Callee Save” • Callee saves temporary values in its frame before using 52

University of Texas at Austin IA 32/Linux+Windows Register Usage • %eax, %edx, %ecx • Caller saves prior to call if values are used later Caller-Save Temporaries • %eax • also used to return integer value Callee-Save Temporaries • %ebx, %esi, %edi • Callee saves if wants to use them Special %eax %edx %ecx %ebx %esi %edi %esp %ebp • %esp, %ebp • special form of callee save • Restored to original values upon exit from procedure 53

University of Texas at Austin Today • Switch statements • IA 32 Procedures • Stack Structure • Calling Conventions • Illustrations of Recursion & Pointers 54

University of Texas at Austin pcount_r: Recursive Function pushl %ebp /* Recursive popcount */ int pcount_r(unsigned x) { if (x == 0) return 0; else return (x & 1) + pcount_r(x >> 1); } • Registers • %eax, %edx used without first saving • %ebx used, but saved at beginning & restored at end movl %esp, %ebp pushl %ebx subl $4, %esp movl 8(%ebp), %ebx movl $0, %eax testl %ebx, %ebx je. L 3 movl %ebx, %eax shrl %eax movl %eax, (%esp) call pcount_r movl %ebx, %edx andl $1, %edx leal (%edx, %eax), %eax. L 3: addl $4, %esp popl %ebx popl %ebp ret 55

University of Texas at Austin pcount_r: pushl %ebp movl %esp, %ebp pushl %ebx subl $4, %esp movl 8(%ebp), %ebx • • • Recursive Call #1 /* Recursive popcount */ int pcount_r(unsigned x) { if (x == 0) return 0; else return (x & 1) + pcount_r(x >> 1); } • • Actions • Save old value of %ebx on stack • Allocate space for argument to recursive call • Store x in %ebx x x Rtn adr Old %ebp Old %ebx %esp 56

University of Texas at Austin Recursive Call #2 /* Recursive popcount */ int pcount_r(unsigned x) { if (x == 0) return 0; else return (x & 1) + pcount_r(x >> 1); } • • • movl $0, %eax testl %ebx, %ebx je. L 3 • • • . L 3: • • • ret • Actions • If x == 0, return • with %eax set to 0 %ebx x 57

University of Texas at Austin Recursive Call #3 /* Recursive popcount */ int pcount_r(unsigned x) { if (x == 0) return 0; else return (x & 1) + pcount_r(x >> 1); } • Actions • • • movl %ebx, %eax shrl %eax movl %eax, (%esp) call pcount_r • • Store x >> 1 on stack • Make recursive call • Effect • %eax set to function result • %ebx still has value of x Rtn adr Old %ebp Old %ebx x x >> 1 %esp 58

University of Texas at Austin Recursive Call #4 /* Recursive popcount */ int pcount_r(unsigned x) { if (x == 0) return 0; else return (x & 1) + pcount_r(x >> 1); } • • movl %ebx, %edx andl $1, %edx leal (%edx, %eax), %eax • • • Assume • %eax holds value from recursive call • %ebx holds x • Actions %ebx x • Compute (x & 1) + computed value • Effect • %eax set to function result 59

University of Texas at Austin Recursive Call #5 /* Recursive popcount */ int pcount_r(unsigned x) { if (x == 0) return 0; else return (x & 1) + pcount_r(x >> 1); } • Actions • Restore values of %ebx and %ebp • Restore %esp • • • L 3: addl$4, %esp popl%ebx popl%ebp ret %ebp • • • %esp Rtn adr Old %ebp %ebx Old %ebx %esp Old %ebx 60

University of Texas at Austin Observations About Recursion • Handled Without Special Consideration • Stack frames mean that each function call has private storage • Saved registers & local variables • Saved return pointer • Register saving conventions prevent one function call from corrupting another’s data • Stack discipline follows call / return pattern • If P calls Q, then Q returns before P • Last-In, First-Out • Also works for mutual recursion • P calls Q; Q calls P 61

University of Texas at Austin Pointer Code Generating Pointer /* Compute x + 3 */ int add 3(int x) { int localx = x; incrk(&localx, 3); return localx; } Referencing Pointer /* Increment value by k */ void incrk(int *ip, int k) { *ip += k; } • add 3 creates pointer and passes it to incrk 62

University of Texas at Austin Creating and Initializing Local Variable int add 3(int x) { int localx = x; incrk(&localx, 3); return localx; } • Variable localx must be stored on stack • Because: Need to create pointer to it • Compute pointer as -4(%ebp) First part of add 3: pushl%ebp movl %esp, %ebp subl $24, %esp # Alloc. 24 bytes movl 8(%ebp), %eax movl %eax, -4(%ebp)# Set localx to x 8 x 4 Rtn adr 0 Old %ebp -4 localx = x -8 -12 Unused -16 -20 -24 %esp 63

University of Texas at Austin Creating Pointer as Argument int add 3(int x) { int localx = x; incrk(&localx, 3); return localx; } • Use leal instruction to compute address of localx Middle part of add 3 movl leal movl call $3, 4(%esp) # 2 nd arg = 3 -4(%ebp), %eax# &localx %eax, (%esp) # 1 st arg = &localx incrk 8 x 4 Rtn adr 0 Old %ebp -4 %ebp localx -8 -12 Unused -16 -20 -24 3 %esp+4 %esp 64

University of Texas at Austin Retrieving local variable int add 3(int x) { int localx = x; incrk(&localx, 3); return localx; } • Retrieve localx from stack as return value Final part of add 3 movl -4(%ebp), %eax # Return val= localx leave ret 8 x 4 Rtn adr 0 Old %ebp -4 %ebp localx -8 -12 Unused -16 -20 -24 %esp 65

University of Texas at Austin IA 32 Procedure Summary • Important Points • Stack is the right data structure for procedure call / return • If P calls Q, then Q returns before P • Recursion (& mutual recursion) handled by normal calling conventions Caller Frame Arguments %ebp Saved Registers + Local Variables • Can safely store values in local stack frame and in callee-saved registers • Put function arguments at top of stack • Result return in %eax • Pointers are addresses of values • On stack or global Return Addr Old %ebp %esp Argument Build 66
