![Wave Transfers Energy Without Transferring Matter Wave Transfers Energy Without Transferring Matter](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-1.jpg)
Wave Transfers Energy Without Transferring Matter
![Wave A wave can be described as a disturbance that travels through a Wave • A wave can be described as a disturbance that travels through a](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-2.jpg)
Wave • A wave can be described as a disturbance that travels through a medium from one location to another location.
![There are three types of waves Mechanical waves require a material medium to There are three types of waves: • Mechanical waves require a material medium to](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-3.jpg)
There are three types of waves: • Mechanical waves require a material medium to travel (air, water, ropes). • Electromagnetic waves do not require a medium to travel (light, radio). • Matter waves are produced by electrons and particles.
![Mechanical Waves Transverse waves cause the medium to move perpendicular to the direction Mechanical Waves • Transverse waves cause the medium to move perpendicular to the direction](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-4.jpg)
Mechanical Waves • Transverse waves cause the medium to move perpendicular to the direction of the wave. • Longitudinal waves cause the medium to move parallel to the direction of the wave. • Surface waves are both transverse waves and longitudinal waves mixed in one medium. (Such as water waves) • Torsional waves produce a twisting motion through the medium – such as the ones which caused the collapse of the Tacoma Narrows Bridge.
![Tacoma Narrows Bridge Torsional Oscillation Mechanical Universe Video Tacoma Narrows Bridge Torsional Oscillation Mechanical Universe Video](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-5.jpg)
Tacoma Narrows Bridge Torsional Oscillation Mechanical Universe Video
![Transverse Longitudinal Waves In a transverse wave the particles of the medium Transverse & Longitudinal Waves • In a transverse wave, the particles of the medium](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-6.jpg)
Transverse & Longitudinal Waves • In a transverse wave, the particles of the medium oscillate perpendicular to the direction of wave travel. • In a longitudinal wave, the particles of the medium oscillate along the direction of wave travel.
![3 Types of Mechanical Waves 3 Types of Mechanical Waves](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-7.jpg)
3 Types of Mechanical Waves
![Wave Tutorial Links http library thinkquest org10796ch 8 ch 8 htm http Wave Tutorial Links • http: //library. thinkquest. org/10796/ch 8/ ch 8. htm • http:](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-8.jpg)
Wave Tutorial Links • http: //library. thinkquest. org/10796/ch 8/ ch 8. htm • http: //www. physicsclassroom. com/Class/w aves/wavestoc. html
![Longitudinal Tuning Fork Wave Vibrating tines produce an alternating pattern of high pressure Longitudinal Tuning Fork Wave • Vibrating tines produce an alternating pattern of high pressure](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-9.jpg)
Longitudinal Tuning Fork Wave • Vibrating tines produce an alternating pattern of high pressure and low pressure regions. • This pattern travels away from the fork. • Compression – high pressure • Rarefaction – low pressure
![Period T The PERIOD of a wave is the time for a particle Period: T • The PERIOD of a wave is the time for a particle](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-10.jpg)
Period: T • The PERIOD of a wave is the time for a particle of the medium to complete one oscillation. • The SI unit for period is the second.
![Frequency f The FREQUENCY of a wave is the number of cycles per Frequency: f • The FREQUENCY of a wave is the number of cycles per](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-11.jpg)
Frequency: f • The FREQUENCY of a wave is the number of cycles per unit time. • The unit is Hertz (Hz) which is a cycle per second. • FREQUENCY is also the reciprocal of the period.
![](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-12.jpg)
![Amplitude A The AMPLITUDE of a wave is the maximum distance of a Amplitude: A • The AMPLITUDE of a wave is the maximum distance of a](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-13.jpg)
Amplitude: A • The AMPLITUDE of a wave is the maximum distance of a particle from the equilibrium position. • The SI unit for amplitude is meter
![Wavelength l lambda The WAVELENGTH of a wave is the length of one Wavelength: l (lambda) • The WAVELENGTH of a wave is the length of one](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-14.jpg)
Wavelength: l (lambda) • The WAVELENGTH of a wave is the length of one complete cycle. • It is the distance between two consecutive “in phase” points. • In phase points are those that are moving in step with each other.
![Wave Applets Wavelength Amplitude Phase Frequency Wavelength Speed Longitudinal Wave Transverse Wave Applets • • • Wavelength, Amplitude, Phase Frequency, Wavelength, Speed Longitudinal Wave Transverse](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-15.jpg)
Wave Applets • • • Wavelength, Amplitude, Phase Frequency, Wavelength, Speed Longitudinal Wave Transverse Wave Superposition Principle 1 Superposition Principle 2
![Wave Equation The speed of a wave is equal to the product of Wave Equation • The speed of a wave is equal to the product of](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-16.jpg)
Wave Equation • The speed of a wave is equal to the product of the wave’s frequency and wavelength. • v: wave speed • f: frequency • l : wavelength
![Speed of Wave on String Speed of Wave on String](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-17.jpg)
Speed of Wave on String
![Sound Waves The origin of any sound is a vibrating object Usually Sound Waves • The origin of any sound is a vibrating object – Usually](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-18.jpg)
Sound Waves • The origin of any sound is a vibrating object – Usually the frequency of the sound is the same as that of the vibrating object • Frequency Range: Sound: 20 Hz – 20, 000 Hz Ultrasound: >20, 000 Hz Infrasound: < 20 Hz
![Forced Vibration Resonance forced vibration example strike tuning fork and Forced Vibration & Resonance • forced vibration – example -- strike tuning fork and](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-19.jpg)
Forced Vibration & Resonance • forced vibration – example -- strike tuning fork and hold the stem against the table • sounding board -- used to amplify sound in music boxes and all string • resonance -- when the frequency of forced vibrations matches the object's natural frequency, a dramatic increase in amplitude occurs
![Speed of Sound Material Speed ms Aluminum 6420 Granite 6000 Steel 5960 Pyrex glass Speed of Sound Material Speed (m/s) Aluminum 6420 Granite 6000 Steel 5960 Pyrex glass](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-20.jpg)
Speed of Sound Material Speed (m/s) Aluminum 6420 Granite 6000 Steel 5960 Pyrex glass 5640 Copper 5010 Plastic 2680 Fresh water (20 ºC) 1482 Fresh water (0 ºC) 1402 Hydrogen (0 ºC) 1284 Helium (0 ºC) 965 Air (20 ºC) 343 Air (0 ºC) 331
![Speed of Sound in Air depends on wind conditions temperature and humidity Speed of Sound in Air • depends on wind conditions, temperature, and humidity •](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-21.jpg)
Speed of Sound in Air • depends on wind conditions, temperature, and humidity • does NOT depend on loudness or frequency of the sound • all sounds travel at the same speed in the same medium in dry air at 0°C ~ 331 m/s (1200 km/h) (740 mi/h) • Sound travels faster through warm air than cold air. • In air, vsound = 331. 4 m/s + (0. 6 m/s/Co)*TC
![Distance to Lightning Light travels at 3 x 108 ms in air Distance to Lightning • Light travels at 3 x 108 m/s in air •](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-22.jpg)
Distance to Lightning • Light travels at 3 x 108 m/s in air • Sound travels at about 330 m/s in air at 0 o. C • It takes about 5 seconds for the sound (the thunder) to travel 1 mile. • Count the seconds between the flash and the sound, divide by 5, and you have the approximate distance in miles to the lightning.
![Pitch Loudness Pitch frequency Double frequency go up an octave Pitch & Loudness • Pitch – frequency Double frequency – go up an octave](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-23.jpg)
Pitch & Loudness • Pitch – frequency Double frequency – go up an octave • Loudness – amplitude – Units – W/m 2
![Human Ear Human Ear](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-24.jpg)
Human Ear
![Decibel Scale incredibly sensitive c i m h t i r a g Decibel Scale • incredibly sensitive c i m h t i r a g](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-25.jpg)
Decibel Scale • incredibly sensitive c i m h t i r a g • can hear everything from lo s i e l a fingertip brushing lightly c S l over fabric to a loud jet Decibe engine • sound of jet engine is about 1012 times more powerful than smallest audible sound • a big difference! • decibel scale -- smallest audible sound is 0 d. B • A sound 10 times more powerful is 10 d. B • A sound 100 times more powerful than near total silence is 20 d. B
![Sound Intensities Wm 2 Loudest sound produced in laboratory 109 Saturn V rocket at Sound Intensities (W/m 2) Loudest sound produced in laboratory 109 Saturn V rocket at](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-26.jpg)
Sound Intensities (W/m 2) Loudest sound produced in laboratory 109 Saturn V rocket at 50 m 108 Rupture of the eardrum 104 Jet engine at 50 m 10 Threshold of pain 1 Rock concert 10– 1 Jackhammer at 1 m 10– 3 Heavy street traffic 10– 5 Conversation at 1 m 10– 6 Classroom 10– 7 Whisper at 1 m 10– 10 Normal breathing 10– 11 Threshold of hearing 10– 12
![Intensity Level Logarithmic Scale Dimensionless I 0 10 12 Wm Intensity Level • Logarithmic Scale • Dimensionless • I 0 = 10 -12 W/m](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-27.jpg)
Intensity Level • Logarithmic Scale • Dimensionless • I 0 = 10 -12 W/m 2
![](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-28.jpg)
![Decibel Levels Near total silence 0 d B A whisper Decibel Levels • • Near total silence - 0 d. B A whisper -](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-29.jpg)
Decibel Levels • • Near total silence - 0 d. B A whisper - 15 d. B Normal conversation - 60 d. B A lawnmower - 90 d. B A car horn - 110 d. B A rock concert or a jet engine - 120 d. B A gunshot or firecracker - 140 d. B
![Doppler Effect Doppler Effect Lesson Doppler Effect • Doppler Effect Lesson](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-30.jpg)
Doppler Effect • Doppler Effect Lesson
![Doppler Effect Moving Source General Expression Moving Observer Doppler Effect • Moving Source • General Expression Moving Observer](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-31.jpg)
Doppler Effect • Moving Source • General Expression Moving Observer
![Superposition Principle Wave interference occurs when two or more waves act simultaneously on Superposition Principle • Wave interference occurs when two or more waves act simultaneously on](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-32.jpg)
Superposition Principle • Wave interference occurs when two or more waves act simultaneously on a medium. • Whenever two or more waves pass through each other, the resulting disturbance at a given point in the medium may usually be found by adding the individual displacements that each wave would have caused. (Principle of Superposition)
![Constructive Interference Constructive interference occurs when the waves are trying to displace the Constructive Interference • Constructive interference occurs when the waves are trying to displace the](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-33.jpg)
Constructive Interference • Constructive interference occurs when the waves are trying to displace the medium in the same direction.
![Destructive Interference When these two waves are completely overlapping there will be complete Destructive Interference • When these two waves are completely overlapping, there will be complete](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-34.jpg)
Destructive Interference • When these two waves are completely overlapping, there will be complete destructive interference. • Destructive interference occurs when the waves are trying to displace the medium in opposite directions.
![PulseWave Reflection Fixed End Reflection Free End Reflection Interference between incident and reflected pulse Pulse/Wave Reflection Fixed End Reflection Free End Reflection Interference between incident and reflected pulse](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-35.jpg)
Pulse/Wave Reflection Fixed End Reflection Free End Reflection Interference between incident and reflected pulse in a fixed end reflection • Fixed/Free End Reflection of Sine Wave
![Standing Waves For certain frequencies the interference of the incident and reflected waves Standing Waves • For certain frequencies, the interference of the incident and reflected waves](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-36.jpg)
Standing Waves • For certain frequencies, the interference of the incident and reflected waves results in a standing wave pattern.
![Fundamental Frequency and Harmonics Fundamental Frequency and Harmonics](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-37.jpg)
Fundamental Frequency and Harmonics
![Standing Waves in a Tube Closed on one end Open on both Standing Waves in a Tube • Closed on one end: • Open on both](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-38.jpg)
Standing Waves in a Tube • Closed on one end: • Open on both ends:
![Waves Moving in and Out of Phase When the 2 waves are in Waves Moving in and Out of Phase • When the 2 waves are in](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-39.jpg)
Waves Moving in and Out of Phase • When the 2 waves are in phase, the resulting disturbance has a maximum amplitude. • When the 2 waves are out of phase, the resulting disturbance has a minimum amplitude.
![Beats Waves of slightly different frequencies form a pattern of alternating maximum and Beats • Waves of slightly different frequencies form a pattern of alternating maximum and](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-40.jpg)
Beats • Waves of slightly different frequencies form a pattern of alternating maximum and minimum amplitude. • The packets of maximum amplitude are called beats.
![Noise Canceling tiny microphones one on each earpiece detect ambient noise before it Noise Canceling • tiny microphones, one on each earpiece, detect ambient noise before it](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-41.jpg)
Noise Canceling • tiny microphones, one on each earpiece, detect ambient noise before it gets to your ears. • noise-cancellation circuitry inverts the captured signal, turning the noise's sound wave upside down. • noise-cancellation system adds the sonic opposite of the external noise to whatever you're listening to • eliminating most of the pollution and leaving you with just your music.
![Standing Waves http phet colorado edu Standing Waves • http: //phet. colorado. edu](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-42.jpg)
Standing Waves • http: //phet. colorado. edu
![Fundamental Harmonics Fundamental & Harmonics](https://slidetodoc.com/presentation_image/233ab011cc470520731d70e42f453c0d/image-43.jpg)
Fundamental & Harmonics
