HYTERA Dispatch applications Smart Dispatch V 4 0

HYTERA Dispatch applications Smart. Dispatch V 4. 0 2029 -Nov-20

Hytera Application Portfolio Tier II Smart Dispatcher + Voice Recorder DWS Dispatcher DVRS Voice Recorder Tier III 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 2

DMR Tier II Dispatcher Smart. Dispatch Flexible Topologies § The Smart. Dispatch solution uses the following software and service composition. - Smart. Dispatch Client-Workstation - Smart. Dispatch Server - Smart. Dispatch Gateway § All components can be installed on a separated hardware with IP-technology for a flexible topology. § For a single line dispatcher all components can be installed on a single computer. Server Client 2029 -Nov-20 Gateway Vo. IP DMR Radio Network © Hytera Mobilfunk Gmb. H 3

DMR Tier II Dispatcher Smart. Dispatch Connection mode § Wireless connection Up to 8 mobile devices can be connected with the Smart. Dispatch Server/Gateway to build up a Radio. Dispatcher-System Antenna § IP connection Repeaters can be directly connected with the Smart. Dispatch Server/Gateway to use the full functionality of the system. 2029 -Nov-20 IP Network © Hytera Mobilfunk Gmb. H 4

DMR Tier II Dispatcher Smart. Dispatch system requirements Workstation operating system Windows XP Sp 3 / 7 / 8 Server / Gateway operating sys. Windows XP sp 3 / 7 / 8 / Server 2008 CPU 2 Ghz (dual core) RAM 2 GB HDD Server 250 GB (recommend for voice recording) Client / Gateway 500 MB Bandwith of one channel > 100 Kbps Database Microsoft SQL 2008 Express (included) Soundcard One soundcard per PC 43 connecting cable (MD 785 Dispatch Station connection) 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 5

DMR Tier II Dispatcher Smart. Dispatch Voice communication § All calls are displayed central in the dispatch area § Operate all types of calls (individual call, group call, broadcast call) § Change the Repeater channel per remote. IP Networ k 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 6

DMR Tier II Dispatcher Smart. Dispatch Phonebook § All subscribers in the system are listed in a phonebook according to their online/offline status § Phonebook can be sorted by groups, organization or by a registered repeater § Direct control of devices using the phonebook § Enable / disable of radio equipment from a distance 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 7

DMR Tier II Dispatcher Smart. Dispatch Map / AVL § Position data on demand by the dispatcher § Periodic location update with configurable interval § Color-coded icons for radio status (online/offline, location, alarm status) § Representation of the route on the map § Direct call of subscribers on the map 2029 -Nov-20 § Easy map usage per drag & drop © Hytera Mobilfunk Gmb. H 8

DMR Tier II Dispatcher Smart. Dispatch Map / AVL § Support of various map engines Google. Maps Online / Offline Open. Street. Maps Offline § Instant map-change without a needed restart of the program 2029 -Nov-20 Google Maps Open. Street. Maps © Hytera Mobilfunk Gmb. H 9

DMR Tier II Dispatcher Smart. Dispatch Map / AVL § Create various Geofence zones § Define group- or terminal rules for entering or leaving the geofence § Each zone can contain multiple rules § POI (Points of interests) on the map quick search for important places 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 10

DMR Tier II Dispatcher Smart. Dispatch Voice recording § System wide voice recording of all calls, as long as the dispatcher is connected to a multi-site repeater § Detailed search-engine 2029 -Nov-20 § High security: All voice records are stored in the Hytera own format. vrds and the playback is only possible with the Smart. Dispatch software. Only the export change the format to the. wav format. © Hytera Mobilfunk Gmb. H 11

DMR Tier II Dispatcher Smart. Dispatch Emergency notification § Emergency scenarios can be triggered by the emergency call function of the terminals and Mandown feature § In an emergency scenario, the alarm message is highlighted in red and indicated by a sound § Radios with a GPS-module will be displayed red on the map 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 12

DMR Tier II Dispatcher § “Handle “ process for Emergerncy Alarm § clicking “Take” it means the dispatcher is informed of the emergency § clicking “Handle” indicates the dispatcher has handled the emergency § the message will not disappear until the dispatcher handles this alarm and clicks “Handle”. 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 13

DMR Tier II Dispatcher Smart. Dispatch Text & Email § Sending text messages to a radio or radio-group § Easy-to-use interface similar to instant messaging § Predefined messages § Use SMTP and POP 3 servers for receiving e-mail messages IP Network § Allows users to send e-mails to terminals Internet POP 3 & SMTP Server Smart. Dispatch Station T M 2029 -Nov-20 © Hytera Mobilfunk Gmb. H DMR Radio Network 14

DMR Tier II Dispatcher Smart. Dispatch System logging § With the IP connection all the system activitys can be logged and stored. § All data is stored in a database and can be placed on filter functions for displaying § Export the reports via Excel § Radio Status report § Call Log Report § Text Message Report § Emergency Report § … 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 15

DMR Tier II Dispatcher Smart. Dispatch Client capability § Each user can obtain different levels of acces-rights to the system § The administrator can configure for each client: § Different feature-sets, § Different available groups, § Different dispatch stations, repeaters, timeslots. 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 16

DMR Tier II Dispatcher Smart. Dispatch OTAP § Over the air programming § Each terminal can be programmed per remote over the air interface § The following parameter can be configured: § Radio ID § Alias § Color Code § Contacts § Tx/Rx frequency § RX group list 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 17

DMR Tier II Dispatcher Smart. Dispatch Telemetry § The programmable pins of the terminals can be programmed and checked over the air. § Check the current status of the pins (high or low voltage) § Send commands (active / inactive / toggle / pulse) 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 18

DMR Tier II Dispatcher § Speed alarm § An alarm message will be dispatched to the over speed radios. Speed alarm message IP Networ k Smart. Dispatch Overspeed 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 19

DMR Tier II Dispatcher Smart. Dispatch Licence system § Basic licence contains: § 1 x Client + Server + Gateway § 1 x Repeater or § 2 x MD 785 § 25 x Subscribers § USB dongle based licencing § License file based on USB dongle’s SN 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 20

DMR Tier II Dispatcher Smart. Dispatch System Performance § One server maximum support § 28 clients § 24 gateways § 16 dispatching repeaters access or § 32 dispatching mobile radios access § One gateway maximum support § 16 dispatching repeaters access or § 4 dispatching mobile radios access 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 21

Smart. Dispatch system topologies With mobile dispatch station DMR Radio Network Dispatcher Client LAN / WAN IP Network Dispatcher Cable IP Smart. Dispatch Gateway Dispatcher Client Smart. Dispatch Server Single Site Dispatcher Client 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 22

Smart. Dispatch system topologies With mobile dispatch station DMR Radio Network Dispatcher Client LAN / WAN IP Network Dispatcher Cable IP Smart. Dispatch Gateway Dispatcher Client Smart. Dispatch Server Single Site Dispatcher Client 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 23

Smart. Dispatch system topologies DMR Radio Network Dispatcher Client Channel 2 LAN / WAN IP Network IP Channel 1 Smart. Dispatch Gateway Dispatcher Client Smart. Dispatch Server Single Site Dispatcher Client 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 24

Smart. Dispatch system topologies DMR Radio Network Master Repeater Dispatcher Client Slave Reperter 1 LAN / WAN IP Network Dispatcher Client LAN / WAN IP Network IP Slave Reperter 2 Smart. Dispatch Gateway Smart. Dispatch Server Slave Reperter N Dispatcher Client 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 25

Smart. Dispatch system topologies Dispatcher Cable DMR Radio Network Smart. Dispatch Gateway Dispatcher Client IP LAN / WAN IP Network Master Repeater Dispatcher Client LAN / WAN IP Network Smart. Dispatch Server Slave Repeater 1 Slave Repeater 2 Dispatcher Client Smart. Dispatch Gateway Slave Repeater N 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 26

Screenshot – Dispatch area 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 27

DS 6500 DMR Tier II Dispatcher System 2029 -Nov-20

Product Overview The DS 6500 is a all-in-one solution combined with plug and play design: § industrial grade computer + Smart. Dispatch Software + DMR Mobile Radio in one case § High integration with a compact design § Small footprint with the internal power supply § The Smart. Dispatch Software is preinstalled and configured § Easy for delivery, installation and operation 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 29

DS 6500 package • Two options of the DS 6500 available (one or two mobile radios included) • The DS 6500 comes with needed computer equipment § 2 mobile Radios § 1 mobile Radio Keyboard Mouse DVD Reader + Writer Smart. Dispatch Manuals + Backup Software 2029 -Nov-20 DS 6500 Manual © Hytera Mobilfunk Gmb. H 30

DS 6500 package • For using the Dispatch Solution you just need to connect your individual Screen + Mic + Loudspeakers Screen Loudspeake r Mic 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 31

DS 6500 Expandibility Rich interface supports flexible system setup with more external radios, Repeater connection, HD Displays, Loudspeakers, USB-periphery. The DS 6500 provides many options for extending the DMR-Network • Connect two additional MD 785 G for additional timeslots ! (2 integrated + 2 external) • Connect the RD 985 Repeater to Dispatch a whole multisite-IP System 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 32

DS 6500 Hardware The DS 6500 comes with powerful hardware: Configurations Dimension 440 mm(W) x 136 mm(H) x 288 mm(D) CPU Intel® Core™ 2 Duo Processor P 8400 (3 M Cache, 2. 26 GHz, 1066 MHz FSB) Storage Memory： 2 G/DDR 2/800 M/200 p Hard disk： 500 G/5400 R/8 M/SATA 2/ 2. 5" I/O interface Main board：EC 7 -1814 L 2 NAIntel CPU with dual cores and high-performance 2 xΦ 3. 5 mm Mic-in/Line-out(Special for Multi-dispatch Mobile Radio) 2 x 10/1000 Mbps RJ 45 2 x. RS 232 1 xΦ 3. 5 mm Line-in 1 x. HDMI 6 x. USB 2. 0 1 xΦ 3. 5 mm Line-out 1 x. DVI 1 xΦ 3. 5 mm Mic-in 1 x. VGA 1 x. PS/2 Mouse and Keyboard Antenna interface The antenna interface for BNC of radio frequency (One Mobile Radio with one interface, and 2 built-in Mobile Radios supported at most) Expansion Build-in 1 x PCI , independent / multi-path sound card with expandable PCI Power supply 500 W ATX, 90 -265 V AC input Noise ≤ 45 d. B OS WIN 7 Dispatch radio Build-in 1 or 2 DMR mobile radio，136~174 Mhz，400~470 Mhz，470~520 Mhz Software Hytera Smart. Dispatch Basic package: 1 client , 1 gateway, 2 dispatch stations，25 terminals (Licences can be extended) 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 33

DS 6500 • No complex installation process • No issues about compatibility between hardware and software • Full Dispatch, Voice-Recorder, Logging functionality from Smart. Dispatch • DS 6500 package connected with additional Screen and Mic = Full Dispatching center 2029 -Nov-20 © Hytera Mobilfunk Gmb. H 34
