Fully Pipelined FPU for OR 1200 Eric Zhang
- Slides: 23
Fully Pipelined FPU for OR 1200 Eric Zhang Electrical & Computer Engineering
Introduction & Motivation • Floating Point Unit: – Performs floating point operations such as: • add/sub, multiplication, division, sine, cosine, FMA – Wide dynamic range and high precision – Required by many algorithms and applications • Eg. Hotspot, SRAD, etc. – High performance and Low power consumption
FPU in OR 1200 • Arithmetic, Conversion, Comparison
FPU in OR 1200 • Serial implementation with long stalls 10 cycles total 38 cycles total 37 cycles total
Goals and Objectives • Pipeline the current version of floating point multiplication and division • Reduce number of clock cycles • Eliminate the stalls due to serial implementation • Synthesize and obtain the physical layout of the pipelined FPU using Synopsys Top-Down design flow
Methodology • Analyze existing floating point implementation – Identify serial implementation that possible for pipelining • Pipeline the FPU multiplier and divider using Synopsys Register Retiming design flow • DC for synthesis, VCS for functional simulation and verification, IC compiler for physical layout, and power and area measurement
Register Retiming
Register Retiming 1. Library setup 2. Constraint setup 3. 4. Compile 5. New constraint 6. Retiming
Register Retiming Flow
Register Retiming Timing Report
Schematic Before Retiming
Schematic After Retiming
VCS Functional Simulation 1. 6 * 4. 0 = 6. 4
VCS Functional Simulation 1. 6 / 4. 0 = 0. 0625
Physical Layout
Specification Results Spec Pipelined Original Frequency 222 MHz 222 Mhz VDD 1. 05 V 1. 05 V Metal Layers 9 9 # of input pins 143 # of output pins 80 80 Area 0. 5 mm^2 0. 45 mm^2 FPMUL Cycles 13 38 FPDIV Cycles 11 37 Dynamic Power 3. 79 m. W 0. 65 m. W Leakage Power 1. 33 m. W 0. 69 m. W Total Power 5. 13 m. W 1. 34 m. W
Design. Ware IP • Technology-independent • Microarchitecture-level library • Synthesizable for ASIC, So. C, and FPGA design • IPs include: – Arithmetic Components: Multiplier, divider, adder, etc • DW 01_add, DW 02_mult, DW_fp_mult – DSP, AMBA Bus, Memory Controller • DW_fir – etc
Design. Ware IP • To use Design. Ware IP: 1. set synthetic_library dw_foundation. sldb 2. set link_library $target_library $synthetic_library 3. License: Design. Ware • Instantiation In Verilog file: – • DW 01_mult #(8, 8) U 1 (A, B, TC, PRODUCT); Synthesize using normal flow
Design. Ware IP • Benefits of using Design. Ware IP – Increased productivity: parameterized, pre-verified – Better quality of results (Qo. R): optimized by Synopsys – Design reusability
Improved Scripts for design flow • Automaticly setup all necessary folders and scripts • Automaticly setup scratch storage for synthesis results • Scripts common to different projects are created as symbolic links – Eg. setup. tcl
Improved Scripts for design flow Top level folder without any projects: Create a project called “test”:
Improved Scripts for design flow Top level folder after creating “test”: Folder layout of project “test” : Other useful scripts : timing_closure. sh : binary search for minimum delay project_init. tcl: Project specific information: top-level design name, language, etc
