Audiomatica Clio. Win 7 – Measurement System

Topics n n n General System Overview System Philosophy System Hardware and Accessories Software Layout Measurement Modules Some Application Examples

Clio Measurement System n n Clio uses a simple audio platform for computer In/Out – PCI Card Calculations are based Computer CPU A signal conditioner is used as a Front-End with the external world Additional accessories may expand functions and possibilities

Clio Measurement System PB-4281 PCI board and SC-01 Signal Conditioner

Clio Measurement System

Clio Accessories CLIOQC Model 4 Amplifier & Switch. Box

The QCBOX

Clio Measurement System: General Application

Clio Measurement System: Clio + QCBOX Amplifier

Clio Measurement System: QCBOX used as a connection panel

Clio Accessories: The Microphones Mic-01 & Mic-02

Clio Accessories 0 or 20 d. B of Gain A, B, C Weighting Filters Selectable

Clio. Win version 7: Calibration Procedure

Clio Measurement System: Measurement Precision

Clio. Win version 7 – Software Layout

Clio. Win version 7 – Software Layout: User selectable options

Clio. Win version 7 – Software Layout: External Hardware Interface

Clio. Win version 7 – Software Layout: Generator dialog boxes

Clio. Win version 7 – Generator

Clio. Win version 7 – Software Layout: Measurement Notes

Clio. Win version 7 – Software Layout: Graphics & Data Export

Clio. Win 7: Multiple Document Layout

Clio. Win 7: MLS & Log Chirp Module

Clio. Win 7: Cumul. Spectral Decay

Clio. Win 7: Polar Directivity Map

Clio. Win 7: Polar Analysis

Clio. Win 7: Acoustical Parameters

Clio. Win 7: FFT Spectrum + Time Data

Clio. Win 7: RTA Spectrum Analyzer

Clio. Win 7: "LIVE" Transfer Function

Sinusoidal Freq. Response + Harmonics

Clio. Win 7: Sinusoidal Impedance

Clio. Win 7: Multi-Meter Module

Clio. Win 7: T&S Parameters Modules

Clio. Win 7: Wow & Flutter Analysis

Clio. Win 7: Leq Sound Level Analysis

Clio. Win 7: Linearity Analysis

Clio. Win 7: Distortion Analisys

Clio. Win 7: QC Capability

Clio. Win 7: A QC Script

QC: Tolerance masks (Limits) [ABSOLUTE] [UPPER LIMIT DATA] 200 100 300 97 10000 97 15000 100 [LOWER LIMIT DATA] 200 82 300 85 10000 85 15000 82 relative limits [RELATIVE] [UPPER LIMIT DATA] 200 5 300 2 10000 2 15000 5 [LOWER LIMIT DATA] 200 -5 300 -2 10000 -2 15000 -5 absolute limits

QC: Sensitivity & Level check

QC: Sensitivity & Level check level shift

QC: Sensitivity & Level check [RELATIVE] [LEVEL] UPPER=3 LOWER=-3 FREQHI=5000 FREQLO=400 [UPPER LIMIT DATA] 200 5 300 2 10000 2 15000 5 [LOWER LIMIT DATA] 200 -5 300 -2 10000 -2 15000 -5

QC: Sensitivity & Level check [RELATIVE] [SENSITIVITY] FREQ 1=500 FREQ 2=1000 FREQ 3=2000 UPPER=102 LOWER=100 [UPPER LIMIT DATA] 200 10 500 10 1000 5 1500 5 2000 10 4000 10 [LOWER LIMIT DATA] 200 -10 500 -10 1000 -5 1500 -5 2000 -10 4000 -10

QC: T&S parameters check SCRIPT [SIN] OUT=-2. 0 IN=0. 0 REFERENCE=IMPEDANCE. SINI LIMITS=IMPEDANCE. LIMITS [TSPARAMETERS] REDC=6. 2 DIAMETER=110 KNOWNMMD=10. 7952 QTSUPPER=0. 6 QTSLOWER=0. 3 FSUPPER=90 FSLOWER=50 CMSUPPER=1. 1 CMSLOWER=0. 8 BLUPPER=6. 5 BLLOWER=6 ZMINUPPER=7. 5 ZMINLOWER=7

QC: RUB&BUZZ check SCRIPT [FFT] OUT=0. 0 IN=-10 REFERENCE=R&B. FFT LIMITS=R&B. LIMITS [UPPER LIMIT DATA] 689. 75 82. 84 793. 78 67. 80 856. 99 64. 41 1362. 95 65. 68 1693. 42 59. 96 1737. 23 58. 26 1982. 28 62. 92 2223. 72 51. 69 2625. 30 56. 99 2883. 04 48. 31 3462. 13 45. 55 3659. 12 38. 56 4018. 35 40. 25 4283. 29 35. 38 4887. 50 30. 72 5696. 91 35. 17 7292. 28 26. 06 21046. 80 22. 88

QC: THD & Harmonics check LIMITS [UPPER LIMIT DATA] 1000 106 2000 116 5000 116 7000 96 [LOWER LIMIT DATA] 1000 89 2000 99 4000 99 6000 80 [3 UPPER LIMIT DATA] 300 70 500 90 2000 90 5000 70 [4 UPPER LIMIT DATA] 200 55 400 68 1300 79 2500 77 5300 77 6300 67 [THD UPPER LIMIT DATA] 200 80 1000 95 5300 95 6300 78

QC: Operator interaction

Clio. Win 7: Suggested Hardware & Software Requirements Pentium. II Processor or better 1 Free PCI Slot Microsoft Windows 98, ME, 2000 or XP 1024 x 768 256 Colors Video or better
