NAFA TECH 2015 AIR FILTRATION MEDIA April 17
- Slides: 39
NAFA TECH 2015 AIR FILTRATION MEDIA April 17, 2015 Embassy Suites DFW Dallas, TX Steven Ogle Instructor
Nonwovens Are Not! q Knitted q Woven q Tufted q Typically, do not use yarns q Paper 2 © INDA
What Are Nonwovens? q Engineered fabrics q Fabric made directly from fibers or resins q Manufactured at high speed q Competitive cost q Excludes most “paper” q Many applications q Nonwovens are everywhere You typically don’t think about a products components 3 © INDA
Nonwoven Markets/Applications q Disposables: Diapers, medical gowns/drapes/wraps, wipes, dryer sheets q Semi-durables: Filters (air, oil, gas) q Durables: Automotive, home furnishings, geotextiles 4 © INDA
Thousands of End Products 5 © INDA
Thousands of End Products 6 © INDA
Air Filtration Products 3. 9% Growth – $13. 7 MM North America by 2018 7 7
Nonwoven Air Filtration Media q How are they Made q Raw Materials q Web Forming q Fabric Bonding q Converting – Final Product 9 9
How Nonwovens Are Made q 4 Step Process ü Select raw material ü Form a web ü Bond web into fabric ü Finish/convert fabric 10 © INDA
Step #1 q Material Selection Staple Fiber –Natural –Man made Polymer Resin 11 © INDA
A Word About Fibers! q Fiber choice critical to end-product q Fiber decisions based on fabric requirements • Strength • Flexibility • Melting point, flexible/brittle temperature (glass transition) • Stability toward its environment (i. e. , flame, sunlight) • Dyeability • Cost, availability 12 © INDA
Step #2 q Web formation – staple fiber to fabric Carded Air laid Wet laid q Web formation – polymer to fabric Spunbond Meltblown SMS 13 © INDA
Roll Goods Fibers Materials Web Formation Bonding Finishing Polyester Carding Calender Surfactant Nylon Air Laid Through Air Repellent Cotton Cross-lap Hydro Color Needled Coating Adhesive Other Rayon Polypropylene Pulp Wet Laid None Finished Products Gowns and Drapes Paper Tape (Transfusions) Surgical Sponges Fluff Pulp Bi-component Others 14 © INDA
What Is a Web? q A web is a random structure of loose fiber q Dry laid webs made by carding or air laying q What is Carding • Individual fibers between 1/2”-2” are separated by combing • A web is formed with a high degree of fiber alignment q What is Air Laid? • Individual fibers 1/2” or less are separated & carried by air fiber distribution is very random 15 © INDA
Web Carding: Dual Cylinder 16 © INDA
Air Laid Card © INDA 17
Air Laid Short Fiber 18 © INDA
What Is Wet Laid? q Fibers, very short, are suspended in water and then collected on a screen, forming the web q Water is drained, then vacuumed, then pressed, and finally evaporated with heat 19 © INDA
Wet Laid Process 20 © INDA
Roll Goods Materials Web Bonding Formation Finishing Finished Products Polypropylene Spunbond Surfactant Calender Polymers Polyethylene Meltblown Through Air Repellent Polyester SMS Hydro Color Nylon Film Needled Coating PLA Other PVA None Gowns and Drapes Mayo Stand Cover Head Gear and Booties Face Masks Others 21 © INDA
What Is Melt Spinning? q Extrusion of melted polymers to form fibers and webs q Meltspinning: • Spunbond • Meltblown 22 © INDA
Spunbond Process 23 © INDA
Meltblown Process 24 © INDA
SMS Schematic 25 © INDA
SMS Cross Section Courtesy of Fiberweb PLC 26
Coform Process 27 © INDA
Step #3 Bonding methods • Chemical (adhesive, resin, latex) • Needlepunch • Spunlaced/hydroentangling • Thermal bond 28 © INDA
Chemical Bonding (Gravure Printer) 29 © INDA
Chemical Bonding (Dip & Nip) 30 © INDA
Chemical Bonding (Foam Padder) 31 © INDA
Chemical Bonding (Spray) Courtesy of Roy Broughton 32
Needle Penetration 33 © INDA
Dual Entangler 34 © INDA
Calendar Bonding Web passed between two rolls • One or both are heated internally • One or both may be embossed Heating via conduction Cooling via convection Courtesy of NCRC – NCSU - 2001 35
Through Air Hot air Courtesy of NCRC – NCSU - 2001 36
Ultrasonic Bonding Horn Anvil Friction between horn and fabric heats fibers under raised points 37 Courtesy of NCRC – NCSU - 2001
Step #4 Converting Examples include: • Slitting • Sheet cutting • Die stamping • Perforations for easy tearing 38 • • • Pleating Molding Assembling Folding Packaging 38
Thank You Steve Ogle 919 -793 -6411 oglelanding@gmail. com 39
