3 Transition Metal Chemistry © 2009 Brooks/Cole - Cengage

4 Transition Metal Chemistry © 2009 Brooks/Cole - Cengage

5 Gems & Minerals Citrine and amethyst are quartz (Si. O 2) with a trace of cationic iron that gives rise to the color. © 2009 Brooks/Cole - Cengage

6 Gems & Minerals © 2009 Brooks/Cole - Cengage Rhodochrosite, Mn. CO 3

Reactions: Transition Metals Fe + Cl 2 Fe + O 2 © 2009 Brooks/Cole - Cengage Fe + HCl 7

Periodic Trends: Atom Radius © 2009 Brooks/Cole - Cengage 8

Periodic Trends: Density © 2009 Brooks/Cole - Cengage 9

Periodic Trends: Melting Point © 2009 Brooks/Cole - Cengage 10

Periodic Trends: Oxidation Numbers Most common © 2009 Brooks/Cole - Cengage 11

12 Metallurgy: Element Sources © 2009 Brooks/Cole - Cengage

13 Pyrometallurgy • Involves high temperature, such as Fe • C and CO used as reducing agents in a blast furnace • Fe 2 O 3 + 3 C f 2 Fe + 3 CO • Fe 2 O 3 + 3 CO f 2 Fe + 3 CO 2 • Lime added to remove impurities, chiefly Si. O 2 + Ca. O f Ca. Si. O 3 • Product is impure cast iron or pig iron © 2009 Brooks/Cole - Cengage

14 Metallurgy: Blast Furnace See Active Figure 22. 8 © 2009 Brooks/Cole - Cengage

Metallurgy: Blast Furnace Molten iron is poured from a basic oxygen furnace. © 2009 Brooks/Cole - Cengage 15

16 Metallurgy: Copper Ores Azurite, 2 Cu. CO 3·Cu(OH)2 Native copper © 2009 Brooks/Cole - Cengage

17 Metallurgy: Hydrometallurgy • Uses aqueous solutions • Add Cu. Cl 2(aq) to ore such as Cu. Fe. S 2 (chalcopyrite) Cu. Fe. S 2 (s) + 3 Cu. Cl 2 (aq) f 4 Cu. Cl(s) + Fe. Cl 2 (aq) + 2 S(s) • Dissolve Cu. Cl with xs Na. Cl Cu. Cl(s) + Cl-(aq) f [Cu. Cl 2] • Cu(I) disproportionates to Cu metal 2 [Cu. Cl 2]- f Cu(s) + Cu. Cl 2 (aq) + 2 Cl- © 2009 Brooks/Cole - Cengage

Electrolytic Refining of Cu See. Figure 22. 11 © 2009 Brooks/Cole - Cengage 18

Coordination Chemistry • Coordination compounds – combination of two or more atoms, ions, or molecules where a bond is formed by sharing a pair of electrons originally associated with only one of the compounds. © 2009 Brooks/Cole - Cengage 19

Coordination Chemistry Pt(NH 3)2 Cl 2 “Cisplatin” - a cancer chemotherapy agent Co(H 2 O)62+ Cu(NH 3)42+ © 2009 Brooks/Cole - Cengage 20

Coordination Chemistry An iron-porphyrin, the basic unit of hemoglobin © 2009 Brooks/Cole - Cengage 21

22 Vitamin B 12 A naturally occurring cobalt-based compound Co atom © 2009 Brooks/Cole - Cengage

Nitrogenase • Biological nitrogen fixation contributes about half of total nitrogen input to global agriculture, remainder from Haber process. • To produce the H 2 for the Haber process consumes about 1% of the world’s total energy. • A similar process requiring only atmospheric T and P is carried out by N-fixing bacteria, many of which live in symbiotic association with legumes. • N-fixing bacteria use the enzyme nitrogenase — transforms N 2 into NH 3. • Nitrogenase consists of 2 metalloproteins: one with Fe and the other with Fe and Mo. © 2009 Brooks/Cole - Cengage 23

24 Coordination Compounds of Ni 2+ © 2009 Brooks/Cole - Cengage

Nomenclature Ni(NH 3)6]2+ A Ni 2+ ion surrounded by 6, neutral NH 3 ligands Gives coordination complex ion with 2+ charge. © 2009 Brooks/Cole - Cengage 25

26 Nomenclature Inner coordination sphere Ligand: monodentate + Cl- Ligand: bidentate Co 3+ + 2 Cl- + 2 neutral ethylenediamine molecules Cis-dichlorobis(ethylenediamine)cobalt(II) chloride © 2009 Brooks/Cole - Cengage

27 Common Bidentate Ligands Bipyridine (bipy) Acetylacetone (acac) Ethylenediamine (en) © 2009 Brooks/Cole - Cengage Oxalate (ox)

28 Acetylacetonate Complexes Commonly called the “acac” ligand. Forms complexes with all transition elements. © 2009 Brooks/Cole - Cengage

Multidentate Ligands EDTA 4 - - ethylenediaminetetraacetate ion Multidentate ligands are sometimes called CHELATING ligands © 2009 Brooks/Cole - Cengage 29

Multidentate Ligands Co 2+ complex of EDTA 4 - © 2009 Brooks/Cole - Cengage 30

31 Nomenclature Cis-dichlorobis(ethylenediamine)cobalt(III) chloride 1. Positive ions named first 2. Ligand names arranged alphabetically 3. Prefixes -- di, tri, tetra for simple ligands bis, tris, tetrakis for complex ligands 4. If M is in cation, name of metal is used 5. If M is in anion, then use suffix -ate [Cu. Cl 4]2 - = tetrachlorocuprate 6. Oxidation no. of metal ion indicated © 2009 Brooks/Cole - Cengage

Nomenclature [Co(H 2 O)6]2+ Hexaaquacobalt(II) H 2 O as a ligand is aqua Pt(NH 3)2 Cl 2 [Cu(NH 3)4]2+ Tetraamminecopper(II) diamminedichloroplatinum(II) NH 3 as a ligand is ammine © 2009 Brooks/Cole - Cengage 32

Nomenclature Pt( Tris(ethylenediamine)nickel(II) [Ni(NH 2 C 2 H 4 NH 2)3]2+ Ir. Cl(CO)(PPh 3)2 Vaska’s compound Carbonylchlorobis(triphenylphosphine)iridium(I) © 2009 Brooks/Cole - Cengage 33

Structures of Coordination Compounds © 2009 Brooks/Cole - Cengage 34

Isomerism • Two forms of isomerism – Constitutional – Stereoisomerism • Constitutional – Same empirical formula but different atomto-atom connections • Stereoisomerism – Same atom-to-atom connections but different arrangement in space. © 2009 Brooks/Cole - Cengage 35

36 Constitutional Isomerism Aldehydes & ketones Peyrone’s chloride: Pt(NH 3) 2 Cl 2 Magnus’s green salt: [Pt(NH 3)4][Pt. Cl 4] © 2009 Brooks/Cole - Cengage

Linkage Isomerism sunlight Such a transformation could be used as an energy storage device. © 2009 Brooks/Cole - Cengage 37

38 Stereoisomerism • One form is commonly called geometric isomerism or cis-trans isomerism. Occurs often with square planar complexes. cis trans Note: there are VERY few tetrahedral complexes. Would not have geometric isomers. © 2009 Brooks/Cole - Cengage

39 Geometric Isomerism Cis and trans-dichlorobis(ethylenediamine)cobalt(II) chloride © 2009 Brooks/Cole - Cengage

Geometric Isomerism Fac isomer © 2009 Brooks/Cole - Cengage Mer isomer 40

41 Stereoisomerism • Enantiomers: stereoisomers that have a nonsuperimposable mirror image • Diastereoisomers: stereoisomers that do not have a non-superimposable mirror image (cistrans isomers) • Asymmetric: lacking in symmetry—will have a non-superimposable mirror image • Chiral: an asymmetric molecule © 2009 Brooks/Cole - Cengage

42 An Enantiomeric Pair [Co(NH 2 C 2 H 4 NH 2)3]2+ © 2009 Brooks/Cole - Cengage

Stereoisomerism 43 [Co(en)(NH 3)2(H 2 O)Cl]2+ These two isomers have a plane of symmetry. Not chiral. These two are asymmetric. Have non -superimposable mirror images. © 2009 Brooks/Cole - Cengage

44 Stereoisomerism These are non-superimposable mirror images [Co(en)(NH 3)2(H 2 O)Cl]2+ © 2009 Brooks/Cole - Cengage

Bonding in Coordination Compounds • Model must explain – – Basic bonding between M and ligand Color and color changes Magnetic behavior Structure • Two models available – Molecular orbital – Electrostatic crystal field theory – Combination of the two f ligand field theory © 2009 Brooks/Cole - Cengage 45

Bonding in Coordination Compounds • As ligands L approach the metal ion M+, – L/M+ orbital overlap occurs – L/M+ electron repulsion occurs • Crystal field theory focuses on the latter, while MO theory takes both into account © 2009 Brooks/Cole - Cengage 46

Bonding in Coordination Compounds © 2009 Brooks/Cole - Cengage 47

Crystal Field Theory • Consider what happens as 6 ligands approach an Fe 3+ ion All electrons have the same energy in the free ion Orbitals split into two groups as the ligands approach. Value of ∆o depends on ligand: e. g. , H 2 O > Cl© 2009 Brooks/Cole - Cengage 48

Octahedral Ligand Field © 2009 Brooks/Cole - Cengage 49

Tetrahedral & Square Planar Ligand Field © 2009 Brooks/Cole - Cengage 50

Crystal Field Theory • Tetrahedral ligand field • Note that ∆t = 4/9 ∆o and so ∆t is small • Therefore, tetrahedral complexes tend to blue end of spectrum © 2009 Brooks/Cole - Cengage 51

52 Ways to Distribute Electrons • For 4 to 7 d electrons in octahedral complexes, there are two ways to distribute the electrons. – High spin — maximum number of unpaired e– Low spin — minimum number of unpaired e- • Depends on size of ∆o and P, the pairing energy. • P = energy required to create e- pair. © 2009 Brooks/Cole - Cengage

Magnetic Properties/Fe 2+ • High spin Paramagnetic • Weak ligand field strength and/or lower Mn+ charge • Higher P possible? • Low spin Diamagnetic © 2009 Brooks/Cole - Cengage • Stronger ligand field strength and/or higher Mn+ charge • Lower P possible? 53

High and Low Spin Octahedral Complexes See Figure 22. 25 High or low spin octahedral complexes only possible for d 4, d 5, d 6, and d 7 configurations. © 2009 Brooks/Cole - Cengage 54

Crystal Field Theory Why are complexes colored? Fe 3+ © 2009 Brooks/Cole - Cengage Co 2+ Ni 2+ Cu 2+ Zn 2+ 55

56 Crystal Field Theory Why are complexes colored? – © 2009 Brooks/Cole - Cengage Note that color observed for Ni 2+ in water is transmitted light

Crystal Field Theory • Why are complexes colored? – Note that color observed is transmitted light Absorption band © 2009 Brooks/Cole - Cengage 57

Crystal Field Theory • Why are complexes colored? – Note that color observed is transmitted light – Color arises from electron transitions between d orbitals – Color often not very intense • Spectra can be complex – d 1, d 4, d 6, and d 9 --> 1 absorption band – d 2, d 3, d 7, and d 8 --> 3 absorption bands • Spectrochemical series — ligand dependence of light absorbed. © 2009 Brooks/Cole - Cengage 58

59 Light Absorption by Octahedral Co 3+ Complex Ground state Excited state Usually excited complex returns to ground state by losing energy, which is observed as heat. © 2009 Brooks/Cole - Cengage

Spectrochemical Series • d orbital splitting (value of ∆o) is in the order I- < Cl- < F- < H 2 O < NH 3 < en < phen < CN- < CO As ∆ increases, the absorbed light tends to blue, and so the transmitted light tends to red. © 2009 Brooks/Cole - Cengage 60

Other Ways to Induce Color • Intervalent transfer bands (IT) between ion of adjacent oxidation number. – Aquamarine and kyanite are examples – Prussian blue • Color centers – Amethyst has Fe 4+ – When amethyst is heated, it forms citrine as Fe 4+ is reduced to Fe 3+ © 2009 Brooks/Cole - Cengage 61 Prussian blue contains Fe 3+ and Fe 2+
