www raisecom com The Company Service oriented solution

www. raisecom. com The Company Service oriented solution company • • Establish in 1999 and achieved with a 250+ M. USD annual turnover with endeavors of 2, 200+ employees Aiming at offering the best connectivity for service providers, power & utilities, transportation, government and enterprises Service Providers Reduced TCO combined with increased revenues • Utilities & Transportation Robust growth towards packetized communication Government & Enterprises Secured packet-based communication for NG services Business with over 120 sales partners in 80+ countries 2

www. raisecom. com 3

www. raisecom. com Raisecom Solutions Business Access • 3 G/LTE: Carrier Ethernet • 2 G/3 G/LTE: PTN NT (E 1+Eth) • 2 G/3 G: PDH, SDH, Fiber. Mux Mobile Backhaul Residential FTTH Industrial & Utility • Optical Fiber: Carrier Ethernet, SME/SOHO Router, MSAP & MSAN & PTN NT, TDMo. IP • Cooper-based: G. SHDSL • Passive: x. PON OLT/ONU • Active: Carrier Ethernet, SME/SOHO Router • TDM-based: SCADA solutions • Ethernet-based: Industrial/Po. E Switches 4

www. raisecom. com Aggregation Transport & Core Carriers & Service Providers ISCOM 2924 XF-4 Q ISCOM 2948 XF-4 Q ISCOM 2924 G-4 C ISCOM 2948 G-4 C ISCOM 2924 GF-4 C ISCOM 2948 GF-4 C ISCOM 2924 GF-4 GE ISCOM RAX 711 -X i. TN 8000 -II RC 002 -16 ISCOM 5508 -GP Access GE ISCOM RAX 711 -C ISCOM 2128 G ISCOM RAX 711 (A) ISCOM 2128 GE-MA-PWR ISCOM RAX 711 (B) ISCOM 6800 i. TN 2100 OPCOM 100 -OAU-H i. TN 201 i. TN 165 ISCOM HT 803 G-1 GE RC 1201 -GESTM 1/4 ISCOM 2110 G(-PWR) RC 1201 -2 GE 16 E 1 T 1 ISCOM HT 803 G-W ISCOM HT 803 G-U RCMS 2911 -16 E 1 -4 GE-BL Splitters ISCOM 2128 EA-MA RC 552 -GE FE ISCOM 2128 EA-MA-PWR RCMS 2902 -60 FE-BL RC 1201 -2 FEE 1 T 1 MSG 2100 E MSG 2110 -SHDSL ISCOM 2110 EA-MA-PWR Carrier Ethernet & Switch RC 1104 RC 552 -FE RC 862 -30 -FV 35 MSG 1200 -GEC RC 862 -30 -BL OTN/PTN/TDM/WDM GPON & SME Router 5

www. raisecom. com Aggregation Transport & Core Mobile Backhaul ISCOM 2924 XF-4 Q ISCOM 2948 XF-4 Q ISCOM 2924 G-4 C ISCOM 2948 G-4 C ISCOM 2924 GF-4 C ISCOM 2948 GF-4 C ISCOM 2924 GF-4 GE ISCOM RAX 711 -X i. TN 8000 -II i. TN 2100 RC 002 -16 ISCOM RAX 711 -C ISCOM RAX 711 (B) Access GE ISCOM RAX 711 (A) i. TN 201 i. TN 165 RCMS 2911 -16 E 1 -4 GE-BL FE RCMS 2902 -60 FE-BL RC 862 -30 -FV 35 Gazelle R 102 i Gazelle R 202 i RC 862 -30 -BL Carrier Ethernet & Switch OTN/PTN/TDM/WDM Industrial Switch 6 & PCM

www. raisecom. com Aggregation Transport & Core ISP, Cable Operator, Corporate & Government OPCOM 600 ISCOM 6800 ISCOM 5508 -GP GE OPCOM 100 -OAU-H ISCOM HT 803 G-1 GE ISCOM HT 803 -W Gazelle S 5028 i ISCOM HT 803 -U Access Gazelle S 1508 i Gazelle S 1112 i-PWR Splitters Gazelle S 1020 i FE MSG 2100 E MSG 1200 -GEC OTN/PTN/TDM/WDM GPON & SME Router Gazelle S 1010 i Gazelle R 102 i Gazelle R 202 i Industrial Switch & PCM 7

Aggregation Transport & Core Transportations & Industrial & Utilities www. raisecom. com i. TN 8000 -II i. TN 2100 Gazelle S 5028 i Gazelle S 1508 i Gazelle S 1112 i-PWR RC 3000 E Gazelle S 1210 i Gazelle S 1020 i FE Access GE RC 3000 -15 Gazelle S 1010 i OTN/PTN/TDM/WDM Gazelle R 102 i Industrial Switch & PCM Gazelle R 202 i 8

Application 1: FTTX Triple-Play by Activewww. raisecom. com Ethernet • FTTH/FTTB Triple-Play with Telecom Ethernet Switch • Broadband access, Data, IPTV, Vo. IP, SLA 9

www. raisecom. com AON for Internet and IPTV Services p Ten thousands of residential subscribers p High bandwidth, fluent streaming, stable PPPo. E connection GE Internet ISCOM RAX 711 GE IP MPLS DHCP Radius ACS Reserved for LTE backhauling access GE/FE PC STB CPE ISCOM RAX 711 GE/10 G VIP Subscribers IPTV BRAS E 320 DGS-3240 ISCOM 2900 GE PC STB FE ISCOM 2110 EA-MA CPE Common Subscribers IPTV/VOD GE DNS Our Advantages • • • PC STB FE ISCOM 2128 EA-MA CPE Residential Apartment STB IPTV Multiple PPPo. E sessions IPTV Rich multicast functions including MVR, IGMP Snooping, MVR Proxy and IGMP Profile Zero interference between multicast flow subscribers Port-based and VLAN-based multicast flows and PPPo. E sessions 10

www. raisecom. com WLAN in China Topology 11

Application 2: FTTX Triple-Play by x. PON www. raisecom. com • FTTH/FTTB Triple-Play Service: Internet, Phone, IPTV/CATV 12

www. raisecom. com Cost Effective FTTH Solution in On. Line Customer Benefits • Pure data service with low-cost solution • GE connection to the home • IPTV application for home end users • Quick deployment Our Advantages • Service template with batch deployment • 4 FE/1 GE connection to the home • Light weight Plastic chassis • IGMP V 1/V 2/V 3 IPTV 13

www. raisecom. com Application 3: CATV EDFA (Erbium Doped Fiber Amplifier) • CATV Typical application • OPCOM 100 -OAM-H amplifier optical signal • OPCOM 100 -OAM-H mix three wavelength • Three wavelength transmit in one fiber. 14

www. raisecom. com Residential FTTH Solution in Telecabl Bulgaria Customer Benefits • IEEE 802. 3 ah EPON and ITU-T G. 984 standards • Full redundant protection of uplink • Triple-play service on single fiber • Hot-swappable redundant power supply • Modular chassis design Our Advantages • control module supporting real-time redundancy • IEEE 802. 3 ah (EPON), ITU-T G. 984 (GPON), IEEE 802. 3 av (10 G EPON) • Trunk group and Link Aggregation Control Protocol • Wireless 802. 11 b/g/n and allow for multiple 15 SSIDs

Application 4: Business Connection - by i. TN 2100 on SDH Network www. raisecom. com • TDM and Ethernet services delivery over SDH network 16

www. raisecom. com Akado, Russia Customer Benefits • 1 U device for remote sites, saving space • Whole solution managed on one GUIbased NMS • transparent Ethernet VLAN service • 1+1 protection on optical STM-1 links Our Advantages • full range of small fibermux (with 2/4 x. E 1, FE, V. 35 interface) available • In-band management covering all remote substation • Split TDM and Ethernet service in aggregation node 17

www. raisecom. com Bel. Telecom, Belarus Customer Benefits • Enough Ethernet and E 1 links for on 1 U device for each site • Ring topology with link protection • All nodes on the ring are fully managed Our Advantages • Support 16 x E 1 plus 4 x Ethernet on each 1 U SDH mux • In-band management covering all remote substation • Split TDM and Ethernet service in aggregation node 18

Application 5: Business Connection - by i. TN 2100 on CE/PTN/MPLS Network www. raisecom. com • TDM and Ethernet services delivery over CE/PTN/MPLS network 19

Carrier Ethernet over copper links www. raisecom. com • Business connection over existing copper infrastructure • Higher bandwidth over copper, capacity • High bandwidth over copper, solutions available for smaller and bigger sites, centralized management 20

10 M Ethernet Private Line for Banks Jiang’Su Customer Benefits • All-optical access, low failure rate • Full network be managed include access • Communication of different network modes • Ethernet interface reserved • Capable to reduce CAPEX & OPEX and increase ROI dramatically Our Advantages www. raisecom. com • Complete CPE product types include SDH mux, FOM, Media Converter, G. SHDSL, … • All service managed by one unified NMS • Reduce human resources to manage whole access 21 network

Application 6: SME Access www. raisecom. com • Intelligent Gateway for Prosperous SME/SOHO Customers • Small & medium enterprise, VPN, network security, Wi-Fi, 3 G backup Intelligent aggregation switch > ISCOM 2924 GF-4 C SME/SOHO gateway > MSG 2200/2300, MSG 2100 E 22

SME Access in Telekom Slovenije www. raisecom. com • Business connection over existing copper infrastructure • Higher bandwidth over copper, capacity • High bandwidth over copper, solutions available for smaller and bigger sites, centralized management 23

Application 7: 2 G/3 G Mobile Backhaul www. raisecom. com • 2 G BTS/3 G Node. B Backhaul by Multiservice PDH Fiber. Mux RCMS tributary card > OPCOM 3500 E-240 GEx 4 L, OPCOM 3500 E 120 FEx 4 -GE/120 FEx 8 L-GE/120 EOSx 4 Multi-Service Fiber. Mux > RCMS 2912 -4(8)E 1 T 1 GE, RCMS 2903 -4 E 1 -4 GE 24

www. raisecom. com 2 G/3 G Backhaul over PTN Colombia Customer Benefits • SDH/SONET-level service quality for mobile voice and data • Hardware-based Ethernet OAM, network performance monitoring across backhaul network • Provide high density of E 1 aggregation • Intelligent traffic management • Multi-generation support for 2 G, 3. 5 G and LTE Our Advantages • MEF-defined Ethernet service features with Gb. E access rates from the cell-site • Comprehensive hierarchical OAM solutions based on 802. 3 ah, 802. 1 ag for OPEX reduction • Ethernet and TDM pseudowire capabilities(MEF 8) • Support clock synchronization including 1 Sync -E, adaptive clock. 25

Application 8: Industrial & Utility www. raisecom. com • SCADA using MSAP & DXC • SCADA, Primary voice & data traffic, DXC, Signaling • Multi-service access platform Basic system > RC 3000 -15/6，RC 3000 -15/6 -DXC • Multi-service Terminal Mux > RC 3000 E 26

www. raisecom. com Rostelecom, Russia Customer Benefits Our Advantages • Deliver SCADA, Voice, Video, Data, and LAN traffics altogether in one chassis • Different form factors for different size substations to transmit in chain • Full redundant backup of the network • Hot redundancy for both SDH network connection and the MUX chassis • In-band management of both local MUX and remote MUX • Standard low speed industry interfaces 27

Air Traffic Control (ATC) Solution Lithuania Customer Benefits • Deliver Direct Phone/Speech, Data, VHF & PTT traffic & radar signals altogether in one chassis • Different form factors for different location capacities to save Cap. Ex • Full redundant backup of the network www. raisecom. com Our Advantages • Hot redundancy for both SDH network connection and the MUX chassis • In-band management of both local MUX and remote MUX • Standard low speed industry interfaces 28

Highway Monitoring System Beijing Customer Benefits • Based on the TCP/IP protocol, compatible with existing networks and ensuring system stability as well as security. • Self-test system and fault diagnosis function. • Centralized control of remote equipment • Levels of transmission service priority • Integrated network management system www. raisecom. com Our Advantages • Support for multiple Ethernet ring network protocol such as RRPS, Spanning Tree, ERPS and MRP, ring recovery time less than 50 ms • Support 802. 1 x, radius, TACACS+ and certification • Support Layer 2/3 SLA(Frame Delay, Jitter & packet loss) • Support queue scheduling algorithm such as SP, WRR, DDR, SP+WRR, SP+DRR, etc. 29

www. raisecom. com Intelligent Bus System in Yantai City China Smart phone WIFI City Bus WIFI Yantai City bus system in China Gazelle R 202 i 3 G Ba /4 G ck Mo ha ul bile Public Transport Management Center 3 G/4 G Base Station Pad Long Distance Bus Internet Push Ad Server Gazelle R 202 i 3 G/4 G Mobile WIFI Backhaul Bus location system/Station Rest Area Gazelle R 202 i Customer Benefits • Intelligent Mobile wireless access • Small size design to achieve flexible deployment 3 G/4 G Base Station bile Mo G 4 3 G/ khaul a B c Our Advantages Public Transport Service Platform • Extended temperature range: -40 ˚C to 85 ˚C • adapt to the high humidity environment : 5% -95% • IP 40 protection class • EMC performance reaches industrial level 4; 30 • Wi. Fi access to ensure the services

www. raisecom. com Bicycle Renting System in Chang Sha, China Chang Sha City in China System Platform/Central Room Gazelle R 102 i LCD Monitor Servers Carrier Ethernet Bicycle Rental Point Gazelle R 102 i HD Camera 3 G Network Bicycle Rental Point Gazelle R 102 i Access Router Card Reader Bicycle Rental Point Customer Benefits • Satisfy the access of multi Hd cameras, card readers, annunciators and guiding panels simultaneously; • Small size design to achieve flexible deployment Our Advantages • Extended temperature range: -40 ˚C to 85 ˚C • adapt to the high humidity environment : 5%-95% • IP 40 protection class • EMC performance reaches industrial level 4; • 3 G backline to ensure the business communication 31

www. raisecom. com Thank You !
