Welcome Simone Campanoni simoneceecs northwestern edu Outline Structure
- Slides: 47
Welcome! Simone Campanoni simonec@eecs. northwestern. edu
Outline • Structure of the course • Example of a code analysis and transformation (CAT) • CAT and compilers • CAT and computer architecture • CAT and programming language
CAT in a nutshell • About: understanding and transforming code automatically • EECS 395/495 • Satisfy the system depth for CS major • Tuesday/Thursday 2: 00 pm – 3: 20 pm at L 221 Tech (here ; )) • Office hours: Friday 2: 00 pm – 5: 00 pm • But feel free to stop by at my office (2. 217@Ford) any time • CAT is on Canvas • Materials/Calendar/Assignments/Grades on Canvas • You’ll upload your assignments on Canvas
CAT materials • Compilers: Principles, Techniques, and Tools • Slides and assigned papers • LLVM documentation http: //llvm. org
The CAT structure Topic & homework Today Project discussion Topic & project 11/12 11/19 12/3 12/8 Week Tuesday Thursday Homework 12/10
The CAT structure Topic & homework Today 11/12 11/19 Week Tuesday Project Thursday Project discussion Topic & project 12/3 12/8 12/10 Week Tuesday Thursday
The CAT structure Topic & homework Today Topic & project 11/12 11/19 Project discussion 12/3 12/8 12/10 Week Tuesday Whole class discussion Thursday Whole class discussion
The CAT grading • Homework: 70 points • 10 points per assignment • Project: 20 points • Final result • Paper • Final discussion: 10 points Grade Points A AB+ B C D F 95 – 100 90 – 94 80 – 89 61 – 79 50 - 60 25 – 49 0 - 24
Rules for homework & final project • No copying of code is allowed • Tool, infrastructure help is allowed • First try it on your own (google and tool documentation are your friend) • You must report who helped you and how on your reports • Avoid plagiarism www. northwestern. edu/provost/policies/academic-integrity/how-to-avoid-plagiarism. html • If you don’t know, please ask simonec@eecs. northwestern. edu
Summary • My duties x e m a • Teach you code analysis and transformation • Your duties l a if n • Learn code analysis and transformation • Implement a few of them in LLVM • Write code • Write reports for each homework o N • Implement a final project • Write code • Write a final document about your project • Prepare a presentation and be ready for discussion
Structure & flexibility • CAT is structured w/ topics • Best way to learn is to be excited about a topic • Interested in something? Speak I’ll do my best to include your topic on the fly
The CAT structure Topic & homework Topic & project Project discussion Week 1 Today • Welcome/Structure • Compiler/CAT F. E. M. E. B. E. Thursday LLVM
The role of compilers If there is no coffee, if I still have work to do, I’ll keep working, I’ll go to the coffee shop Code analysis and transformation If there is no coffee{ if I still have work to do{ I’ll keep working; } I’ll go to the coffee shop; } Compilers ? ? ? 0010111001010101011010
Theory Compilers & CATs ct ic Pr a fie terld s e In
Example of CAT What will it print? var. X = 5 … … print var. X …
Example of CAT What will it print? var. X = 5 … … print 5 … print var. X
Example of CAT var. X = 5 … … print 5 … var. X = 5 … … print var. X … Is it worth transforming? Code Analysis Property Transformatio n Transformed code
Designing CATs • Choose a goal • Performance, energy, finding bugs, discovering properties • Design automatic analysis to obtain the required information • Occasionally design the code transformation
Use of CATs • Compilers • Optimize performance • energy efficiency • code generation • Developing tools • Understanding code • Computer architecture
Structure of a compiler Character stream (Source code) i n t ma i n … Lexical analysis Tokens Syntactic & semantic analysis AST INT SPACE STRING SPACE … int main. Function (){ signature printf(“Hello World!n”); Function name Return type return 0; STRING } INT
Structure of a compiler Character stream (Source code) i n t ma i n … Lexical analysis Tokens Syntactic & semantic analysis AST INT SPACE STRING SPACE … Function signature Return type INT Function name STRING
Structure of a compiler Syntactic & semantic analysis AST Function signature Return type INT Function name STRING IR code generation IR ; Function Attrs: nounwind uwtable define int @main() {
Structure of a compiler Character stream (Source code) Front-end IR Middle-end IR i n t ma i n … EECS 322: Compiler Construction ; Function Attrs: nounwind uwtable define int @main() { Code analysis and transformation ; Function Attrs: nounwind uwtable define int @main() { Back-end EECS 322: Compiler Construction Machine code 01010111010101
Structure of a compiler Character stream (Source code) Front-end IR Middle-end Character stream (Source code) Front-end Middle-end Back-end IR Back-end Machine code
Structure of a compiler C Front-end IR Middle-end Java C Front-end Middle-end Back-end IR Back-end Machine code
Structure of a compiler C Front-end IR Middle-end Java Front-end Middle-end Back-end IR Back-end Machine code
Structure of a compiler C Java Front-end FE IR Middle-end Java Front-end Middle-end Back-end IR Back-end Machine code M 2 Machine code
Structure of a compiler C Java Front-end FE IR Middle-end Java Front-end Middle-end Back-end IR Back-end BE Machine code M 2
Structure of a compiler L 1 L 2 Front-end 1 Front-end 2 IR Middle-end IR Back-end A MA Back-end B MB
Multiple IRs • Abstract Syntax Tree R 1 + R 2 R 3 • Register-based representation (three-address code) R 1 = R 2 add R 3 • Stack-based representation push 5; push 3; add; pop ;
Example of LLVM IR define i 32 @main(i 32 %argc, i 8** %argv) { entry: %add = add i 32 %argc, 1 ret i 32 %add }
Multiple IRs used together L 1 Static compiler IR 1 Dynamic compiler FE IR 2 Dynamic compiler BE Machine code
Multiple IRs used together Java compiler Java bytecode Java VM FE IR 2 Java VM BE Machine code
CATs that we’ll focus on • Semantics-preserving transformations • Correctness guaranteed • Goal: performance • Automatic • Efficient
Evolution of CATs (hardware point of view) • Simple hardware (few resources), simple CATs Core Size Registers Latency Cache L 1 Cache L 2 Memory
Evolution of CATs (hardware point of view) • Simple hardware (few resources), simple CATs Compilers/CATs • Opportunities to improve programs • Challenging CATsare developed in the processor-design stage! • Execution model mismatch between • More hardware resources available to compilers source code and hardware • Challenging CATs
Evolution of CATs (hardware point of view) (2) 1960 - ? : Complex instruction set computing (CISC) 1980 - ? : Reduced instruction set computer (RISC)
Evolution of CATs (hardware point of view) (3) Very long instruction word (VLIW) Superscalar Inst 1 Inst 2 Inst 3 Inst 4 Inst 5 Inst 6 Inst 7 Inst 8 CATs Inst 1 Inst 4 Inst 7 Inst 8 Inst 2 Inst 5 Inst 3 Inst 6
Evolution of CATs (PL point of view) • Low level programming language, simple CATs • Not very productive • More abstraction in programming language, more work for CATs to reduce their performance impact • CATs enable new programming languages
Evolution of CATs (PL point of view)(2) PL without procedures void main (){ String s 1, s 2; s 1. append(‘c’); s 2. append(‘c’); }
Evolution of CATs (PL point of view)(3) Let’s add procedures to our PL • Call-by-Value void proc 1 (int a){…} proc 1(my. Var 1) • Call-by-Reference void proc 1 (String a){…} proc 1(my. String 1)
Evolution of CATs (PL point of view)(2) void my. Proc (String s 1, String s 2){ s 1. append(‘a’); s 2. append(‘c’); }
Conclusion • CATs used for multiple goals • Enable PLs • Enable hardware features • CATs are effected by • Their input language • The target hardware
Ideal CATs • Proved to be correct • Improve performance of many important programs • Minor compilation time • Negligible implementation efforts
Demo time
