Acknowledgement This Powerpoint presentation was prepared by Dr. Terry Weigel, University of Louisville. This

Acknowledgement This Powerpoint presentation was prepared by Dr. Terry Weigel, University of Louisville. This work and other contributions to the text by Dr. Weigel are gratefully acknowledged. 2

Types of Compression Members Short compression blocks - pedestals Short reinforced columns Long or

Types of Compression Members Short compression blocks - pedestals Short reinforced columns Long or slender reinforced columns 3

Short Compression Block Height less than three times least lateral dimension May be designed

Short Compression Block Height less than three times least lateral dimension May be designed as unreinforced or plain member Maximum force is: 4

Short Reinforced Column Stocky members Material failure Maximum load supported is controlled by section

Short Reinforced Column Stocky members Material failure Maximum load supported is controlled by section dimensions and strength of materials 5

Slender Reinforced Column Bending deformations Secondary moments Instability or buckling 6

Slender Reinforced Column Bending deformations Secondary moments Instability or buckling 6

Secondary Moments P is the axial force M is the primary moment 7

Secondary Moments P is the axial force M is the primary moment 7

Types of Columns Tied Columns Spiral Columns Composite columns 8

Types of Columns Tied Columns Spiral Columns Composite columns 8

Tied Column 9

Tied Column 9

Spiral Column 10

Spiral Column 10

Composite Columns 11

Composite Columns 11

Tied Columns Ties increase column strength Ties hold longitudinal bars in place during construction

Tied Columns Ties increase column strength Ties hold longitudinal bars in place during construction Ties prevent longitudinal bars from buckling after cover spalls Tied columns are usually, but not always, rectangular in shape 12

Spiral Columns Spiral columns are usually, but not always, circular in shape Helical spirals

Spiral Columns Spiral columns are usually, but not always, circular in shape Helical spirals Spirals are more effective than ties in increasing column strength Spirals are loaded in hoop tension when compressive load is place on a column 13

Spiral Columns Spiral columns are more expensive than tied columns Spiral columns are better

Spiral Columns Spiral columns are more expensive than tied columns Spiral columns are better for seismic applications 14

Axial Load Capacity of Columns 15

Axial Load Capacity of Columns 15

Failure of Columns Tied columns – cover spalls and, unless ties are closely space,

Failure of Columns Tied columns – cover spalls and, unless ties are closely space, longitudinal bars buckle Spiral columns – cover spalls but longitudinal bars and concrete core are confined by spirals and remain intact Spiral cage is designed to be have a strength equal to the spalled cover 16

Strength of Spiral Shell strength Spiral strength 17

Strength of Spiral Shell strength Spiral strength 17

Strength of Spiral ACI Code Equation 10 -5 18

Strength of Spiral ACI Code Equation 10 -5 18

Spiral Steel Percentage 19

Spiral Steel Percentage 19

Spiral Parameters 20

Spiral Parameters 20

ACI Code Requirements for CIP Columns Percentage of longitudinal steel may not be less

ACI Code Requirements for CIP Columns Percentage of longitudinal steel may not be less than 1% nor more than 8% At least four longitudinal bars must be used within rectangular or circular ties At least six longitudinal bars must be used within spiral ties The practical minimum column dimension is about 8 to 10 in. 21

ACI Code Requirements for CIP Columns For tied columns with No 10 and smaller

ACI Code Requirements for CIP Columns For tied columns with No 10 and smaller longitudinal bars, the minimum size tie is No 3 For tied columns with longitudinal bars larger than No 10 , and for bundled bars, the minimum size tie is No 4 For tied columns, the maximum ties spacing is the smallest of: 48 tie bar diameters, 16 longitudinal bar diameters, or the least lateral column dimension 22

ACI Code Requirements for CIP Columns For tied columns , ties must be arranged

ACI Code Requirements for CIP Columns For tied columns , ties must be arranged so that every corner and every alternate longitudinal bar has lateral support provided by a tie bent around the longitudinal bar with an included angle not o greater than 135. No longitudinal bar can be located more than 6 in. from such a laterally supported bar 23

Supported Bars 24

Supported Bars 24

Supported Bars 25

Supported Bars 25

Supported Bars 26

Supported Bars 26

ACI Code Requirements for CIP Columns Spirals may not have diameters less than 3/8

ACI Code Requirements for CIP Columns Spirals may not have diameters less than 3/8 in. The clear spacing between spirals may not be less than 1 in. or greater than 3 in. 27

Capacity Reduction Factor Failure of a column is more significant than failure of a

Capacity Reduction Factor Failure of a column is more significant than failure of a beam For tied columns, f = 0. 65 For spiral columns, f = 0. 75 28

Eccentricity of Axial Load To account for (accidental) eccentricity, the ACI Code uses a

Eccentricity of Axial Load To account for (accidental) eccentricity, the ACI Code uses a factor a a = 0. 80 for tied columns a = 0. 85 for spiral columns 29

ACI Column Design Capacity Equations (spiral) (tied) ACI Code Equation 10 -1 (spiral) ACI

ACI Column Design Capacity Equations (spiral) (tied) ACI Code Equation 10 -1 (spiral) ACI Code Equation 10 -2 (tied) 30

Column Design Examples 31

Column Design Examples 31

Example 9. 1 Design a square tied column to support an axial dead load

Example 9. 1 Design a square tied column to support an axial dead load o 130 k and an axial live load of 180 k. Begin using approximately 2 percent longitudinal steel, a concrete strength of 4, 000 psi and Grade 60 steel. 32

Example 9. 1 Determine the factored axial load 33

Example 9. 1 Determine the factored axial load 33

Example 9. 1 Select the column dimensions 34

Example 9. 1 Select the column dimensions 34

Example 9. 1 Select the longitudinal steel 35

Example 9. 1 Select the longitudinal steel 35

Example 9. 1 Design the ties 36

Example 9. 1 Design the ties 36

Example 9. 1 Other ACI Code requirements 37

Example 9. 1 Other ACI Code requirements 37

Example 9. 1 Other ACI Code requirements 38

Example 9. 1 Other ACI Code requirements 38

Example 9. 1 39

Example 9. 1 39

Example 9. 2 Design a round spiral column to support an axial dead load

Example 9. 2 Design a round spiral column to support an axial dead load of 240 k and an axial live load of 300 k. Begin using 2 percent longitudinal steel, a concrete strength of 4, 000 psi and Grade 60 steel. 40

Example 9. 2 Determine the factored axial load 41

Example 9. 2 Determine the factored axial load 41

Example 9. 2 Select the column dimensions Since 255 < 266 in 2, the

Example 9. 2 Select the column dimensions Since 255 < 266 in 2, the reinforcing steel percentage will be greater than 2% 42

Example 9. 2 Select the longitudinal steel 43

Example 9. 2 Select the longitudinal steel 43

Example 9. 2 Design of the spiral ties 44

Example 9. 2 Design of the spiral ties 44

Example 9. 2 Design of Spiral 45

Example 9. 2 Design of Spiral 45

Example 9. 2 6 No 9 bars 15” 18” 46

Example 9. 2 6 No 9 bars 15” 18” 46
