GFI LANguard Network Security Scanner 1 Contents Introduction

GFI LANguard Network Security Scanner 1

Contents Introduction n Features n Source & Installation n Testing environment n Results n Conclusion n 2

Introduction n Importance of Network security ¨ Internal Security ¨ External Security n Purpose of GFI LANguard ¨ Enable Network admins to perform Security audit n Remote system analysis n 3

Features n Security Audit ¨ Results in a verbose manner ¨ Flexible scanning n n Scan one computer Scan range of computers Scan list of computers Domain specific scan 4

Features (Cont…) n System detection ¨ SNMP , NETBIOS queries , Ping Sweep n Configuring ports for port scan 5

Features (Cont. . ) n Enumeration of entry points ¨ SNMP holes ¨ CGI holes ¨ Open shares ¨ Rogue , Backdoor users ¨ Weak network passwords 6

Features (Cont…) n Alerts ¨ Well known security problems are clearly identified ¨ Intelligent scanning ¨ Listing of hot-fixes & service packs 7

Features (Contd. . ) Remote Machine shutdown n Exploitation of Net. BIOS vulnerability n Enabling auditing n Sending spoofed messages n Scheduling scans & automatic update of scans n Gathering information & displaying using report generator n 8

Features (Contd. . ) n Scripting Language: LANS: LANguard Scripting language ¨ GFI LANguard contains its own scripting editor ¨ Allows users to create custom script which will be executed on the remote host as when accessed ¨ 9

Features (Contd. . ) n Tools: ¨ SNMP Walk By performing SNMP walk potential hackers or malicious users will get lot of information about the system 10

Features (Contd. . ) n Tools (Contd. . ) ¨ Trace ¨ DNS route look up 11

n Tools (Contd. . ) ¨ SNMP Audit SNMP audit allows to detect weak community strings. 12

n Tools (Contd. . ) ¨ MS-SQL Audit 13

n Tools (Contd. . ) ¨ Enumerated Computers 14

Source & Installation Downloaded GFILANguard from www. gfi. com n Minimum requirements as set by vendor n ¨ OS: Win 2000/2003/XP ¨ IE 5. 1 + ¨ Client for Microsoft networks be installed ¨ No personal firewall settings 15

Testing Environment n Setting options: 16

Testing Environment (Contd. . ) 17

Testing Environment (Contd. . ) 18

Results Source IP address : 137. 207. 234. 120 n CASE -1 : n ¨ Destination IP: 137. 207. 234. 138 ¨ Scan parameters: As specified earlier 19

20

Results (Contd. . ) n CASE –II : Sun. Solaris 21

Results (Contd. . ) n Script execution: hostname = "agardel 2" # my desktop computer ¨ // name of the system from which the script is running ¨ ip = dnslookup(hostname) ¨ // using the function dnslookup ¨ if ip <> "" ¨ echo("hostname: " + hostname) ¨ echo("resolved as: " + ip, _color_blue) ¨ # now backwards: ) ¨ hostname = Reverse. Dns. Lookup(ip) ¨ if hostname <> "" ¨ echo("back to: " + hostname, ) ¨ end if ¨ else ¨ echo("unable to resolve " + hostname + " !", ¨ _color_red) ¨ end if 22

Conclusion n GFI LANguard is a very good tool in ¨ detecting and analysis of vulnerabilities ¨ User – defined Scripting language : LANS ¨ Verbose representation of Data ¨ Generating Reports 23

References n www. gfi. com 24
