Biannual Report 2016 08 16 Gyung Goo Lee
Biannual Report 2016. 08. 16 Gyung. Goo Lee
Proceeded Work list • Hardware -GEM Electronics Make test setup for Cosmic muon count (preparing work) • Software -ROOT Training Learn to Histogram -1 -
GEM Hardware 지난 2월부터 7월까지 참여한 GEM Hardware 작업: - NIM System 중 Low Voltage Module같은 간단한 장비 제작 (2월) - GEM Detector의 분리작업 및 Gain 측정을 위한 HV Setup 제작 (7월) -2 -
NIM system : Low voltage module NIM system에서 Low voltage에 쓰이는 module 4개를 제작 -3 -
GEM Detector GEM Readout board 총 512 channel로 128 channel씩 4개의 connector로 출력 HV GEM Hardware (Single channel readout setup) Channel output 128개의 channel을 하나 로 묶어서 읽음 -4 -
Gain test setup GEM Foil 각 층의 top과 bottom에 하나하나 HV를 인가해 Foil의 gain값 을 측정하기 위한 setup G 2와 G 3에 HV 인가 Drift board와 G 1에 HV 인가 -5 -
Gain test setup HV input line Ground line Input Connector -6 -
Gain test setup GND -7 -
Gain test setup Drift plate 3050 V 600 V G 1 T G 1 B 350 V 2450 V 2100 V G 1 T G 1 B 350 V 600 V HV Set 1 400 V 1700 V 1350 V G 2 T G 2 B 400 V 2950 V 2550 V G 1 T G 1 B G 3 T G 3 B 400 V 750 V HV Set 2 350 V 3300 V 2900 V 600 V 2050 V 1650 V G 2 T G 2 B 500 V 950 V 600 V 4200 V 900 V 500 V 400 V G 3 T G 3 B Drift plate 3700 V 750 V 400 V G 2 T G 2 B HV Set 1부터 Set 3까지 차례로 실험하여 HV인가가 제대로 이뤄지는 것이 확인될 경우, Set 3로 Gain 측정 350 V 2300 V 1900 V 600 V 1150 V 750 V G 3 T G 3 B 350 V 1300 V 900 V HV Set 3 -8 -
Gain test setup Drift plate 3050 V Gain test에 앞서서 HV가 제대로 인가가 되는지를 확인하기 위해 구동 전압을 인가함 600 V G 1 T G 1 B 350 V 2450 V 2100 V 400 V G 2 T G 2 B 350 V 1700 V 1350 V 400 V G 3 T G 3 B 350 V 950 V 600 V HV Set 1 결과: 신호가 잡히지 않고 Noise만 잡힘 HV가 제대로 인가되지 않음 -9 -
Software Work • ROOT Training - Histogram 그리는 방법 학습 - Histogram에 라벨을 붙이는 방법(Tlegend) 학습 -10 -
Histogram example 1 Ex) h 1 ->Set. Line. Color(k. Blue); h 1 ->Set. Fill. Color(k. Blue); Fill the line color of histogram: blue Fill the block color of histogram: blue -11 -
Histogram example 2 Control the y 2 Control the x 2 Code: Leg = new Tlegend(0. 9 , 0. 6, 0. 8, 0. 775) Control the x 1 -axis Control the y 1 -axis position Tlegend를 통해 히스토그램에 라벨을 붙일 수 있음 -12 -
Histogram example 3 Ex) c 1 ->Divide(2, 3); c 1 ->cd(1); h 1 ->Draw(); c 1 ->cd(2); Divide the canvas 2 x 3 First block Draw the histogram first block Next block -13 -
Next Plan of 6 month • Hardware: - GEM Detector test (integrate DAQ system) - Cosmic muon test • Software: - Root Training - Start CMS Software Training -15 -
Hardware: GEM Electronics • Cosmic muon test - Scintillator와 GEM Detector의 muon count를 비교해 GEM Foil의 count efficiency 측정 - Scintillator 대신 GEM Detector를 여러 장 두고 Cosmic muon test - GEM Foil의 Gain 값 측정 2016년 2월 당시의 Cosmic muon test setup Cosmic muon count나 gain test는 DAQ board가 없이도 진행이 가능하므로 학기 중 수업이 없는 날에 가서 진행 가능 -17 -
Hardware: GEM Electronics • Cosmic muon test - Scintillator와 GEM Detector의 muon count를 비교해 GEM Foil의 count efficiency 측정 - Scintillator 대신 GEM Detector를 여러 장 두고 Cosmic muon test - GEM Foil의 Gain 값 측정 2016년 2월 당시의 Cosmic muon test setup Cosmic muon count나 gain test는 DAQ board가 없이도 진행이 가능하므로 학기 중 수업이 없는 날에 가서 진행 가능 -18 -
Hardware: GEM Electronics • Schedule Month Sep Oct Nov Dec DAQ test X X X 작업 시작 Cosmic muon test 수업 없을 시 참여 집중적으로 참여 -19 -
Software Work • ROOT Training - Get, Tgraph, Fitting 등을 Training하여 ROOT로 할 수 있는 작업의 영역을 확대 • Start CMS Software Training - ROOT Programing에 익숙해지는 시점부터 CMS Software를 다루는 법에 대한 Training을 시작하여 Analysis 작업에 필요한 기능을 학습 -20 -
Software Work • Schedule Month Sep Oct Nov Dec ROOT Training Get Training Tgraph Training Fitting Training Continue CMS Software X X X Start Training -21 -
