생산 제품 www. iautogen. com 자동차 및 자동차부품 제조의 전문기술 승용차 및 SUV에서의 개발 및 생산 경험(GMDAT, 쌍용차) 4 Products 5 3 2 6 1 7 8 12 9 13 10 11 1. FENDER APRON & FRONT SIDE MBR ASS’Y 2. FRONT FLOOR ASS’Y 3. FRAME SUN ROOF 4. TRUNK HINGE 5. CENTER PILLAR ASS’Y 6. R/F A-REAR PILLAR 7. W/HOUSE REAR ASS’Y 8. DOOR STRIKER 9. LONGI FLOOR LWR ASS’Y 10. R/F ROCKER ASS’Y 11. DOOR HINGE 12. HEAT SHIELD 13. HOOD HINGE 8

선행 경쟁력 www. iautogen. com 대형제품 생산을 위한 프레스 라인 효율적인 라인 운영 (3 Press Lines, Blanking Line) → 로봇 시스템으로 전자동화 된 1, 500 T, 1, 000 T, 600 T 라인 Line Designation # 1 Press Line # 2 Press Line M/C & Equipments Maker Q’ty ㆍ1, 500 Ton Press ㆍ800 Ton Press ㆍ500 Ton Press ㆍ400 Ton Press ㆍRobot ㆍDestacking System ㆍDelivery Conveyor KOMATSU, Japan SIMPAC, Korea YASKAWA, Japan Korea 1 1 5 1 1 ㆍ1, 000 Ton Press ㆍ400 Ton Press ㆍ500 Ton Press ㆍRobot ㆍDestacking System ㆍDelivery Conveyor SIMPAC, Korea YASKAWA, Japan DOOSAN, Korea 1 2 1 6 1 1 Remarks 11

www. iautogen. com Line Designation # 3 Press Line Blanking Line Other Equipments M/C & Equipments Maker Q’ty JEIL, Korea YASKAWA, Japan Korea 1 3 5 1 1 ㆍ400 Ton Blanking Press ㆍCoil Feed System SIMPAC, Korea 1 1 ㆍ15 Ton O/H Crane ㆍ10 Ton Semi Gantry Crane ㆍBlank Bundle Turn Over Device SAMKWANG, Korea 3 2 ㆍ600 Ton Press ㆍ400 Ton Press ㆍRobot ㆍDestacking System ㆍDelivery Conveyor Remarks 1 12

www. iautogen. com 1, 000 Ton Press Line 1, 500 Ton Press Line 400 Ton Blanking Line 13

www. iautogen. com Panel Handling by Robot Destacking System 14

www. iautogen. com 100% 자동화 된 용접 라인 효율적인 생산운영 시스템 → 적기 공급 대응 M/C & Equipments Maker Q’ty YASKAWA, Japan 79 ABB, Sweden 14 FANNC, Japan 32 HYUNDAI, Korea 5 YASKAWA, Japan 3 Spot Welding Jig Korea 34 Multi Welding Jig Korea 32 Chowel, Korea 28 Korea 3 Spot Welding Robot Equipment Sealing Robot Projection Welding M/C Sealant Feed System Area 시 화 공 장 5, 000 ㎡ 인 주 Remarks 공 장 4, 800 ㎥ 15

www. iautogen. com C-100. RR WHEEL HOUSE Line C-100. ROCKER Line 16

www. iautogen. com W-200. FRONT FLOOR ASS’Y Line W-200. FENDER APRON & FRONT SIDE MBR ASS’Y Line 17

www. iautogen. com 금형 제작 능력 ▶ 년 제작능력 : 1, 500 Ton (5 Ton기준, 300 set) ▶ 금형 제작 및 M/C 설비 M/C & Equipments - 500 ton Hydraulic Press Large CNC Milling M/C Medium CNC Milling M/C Small Machinery Milling M/C, Lathe, Radial Drilling M/C, etc. - Blank Shearing M/C - CMM - O/H Crane (15/5 ton, 10 ton) Maker Q’ty Remarks KAWASAKI, Japan OKUMA, Japan Korea 2 1 1 1 MB Size : 2, 000 x 3, 000 Bed Size : 2, 400 x 4, 000 Bed Size : 1, 600 x 2, 000 AMADA, Japan WENZEL, Germany YOUJIN, Korea 1 1 6 ▶ 소프트웨어 Bed Size : 4, 000 x 1, 600 x 2, 100 Computer System Software EA - CATIA / IBM RISC 6000 - UG SYSTEM - AUTO CAD - MODVIEW 2 3 6 2 TOTAL 13 18

www. iautogen. com ▶ 금형 Try Out 및 Sample Panel 생산 Die Try out In the beginning 500 ton Hydraulic Press Sample Panel Production Final ㆍ1, 500 ton Mechanical Press Line ㆍ1, 000 ton Mechanical Press Line ㆍ600 ton Mechanical Press Line ▶ 관련실적 Year 2005 2006 2007 2008 2009 Model T-250 V-250 C-105 T-255 C-100 T-200 Tag. AZ R-155(Tag. AZ) C-100(Tag. AZ) Vs-300(GMDAT) Y-300(SYMC) Part Name ROCKER L/RH & Others CTR INR L/RH & Others ROCKER & Others CTR PLR L/RH & Others ROCKER L/R & Others FRAME W/S INR L/R FLOOR SIDE L/R W/HSE OTR L/R & Others DECK FLR & Others DASH UPR & Others R/F CTR PLR & Others FRT FLR & Others SUZUKI OKIHARA T 300(5 HB) CAMACO YP 6 L/RH & Others CTR INR UPR LH & Others R/F CTR PLR LH/RH & Others SEAT PAN & Others Q’ty Remarks 32 Passenger Car 40 SUV 54 Passenger Car & SUV 100 Passenger Car & SUV 140 Passenger Car 19

www. iautogen. com ▶ 금형제작 실적 제품 젠트라 CTR INR 윈스톰 ROCKER 윈스톰 CTR PLR 젠트라 ROCKER INR 20

www. iautogen. com Tag. AZ - W/HOUSE OTR L/RH CAMACO – SEAT PAN CAMACO – UPPER CROSS MEMBER Tag. AZ - W/HOUSE INR L/RH CAMACO – SIDE PANEL BRACKET 21

www. iautogen. com #20 Large CNC Milling M/C #15 Large CNC Milling M/C 22

www. iautogen. com WENZEL 3 D CMM (Coordinate Measuring Machine) (Bed size : 4, 000 x 1, 600 x 2, 100) 24

www. iautogen. com Bench Work View 25
