DRYMIX Index Company Overview Drymix Products References 1

DRYMIX Index Ø Company Overview Ø Drymix Products Ø References 1

COMPANY OVERVIEW • • • Introduction Ownership structure Sister Companies Production Facility Quality Control / R&D Lab 2

INTRODUCTION Drymix Egypt is the one of the largest producers in Middle East and Africa for pre-mixed, ready to use cement based mortars delivered in dry form. 3

Founded in 6 th of October city 25 Km west of Cairo Total factory area 30, 000 m² Drymix Nominal Bulk Capacity: 240, 000 tons / Year Technical Know How from M-Tec/ Maxit Germany All products comply to DIN, ASTM, ANSI, EN standards 4

OWNERSHIP STRUCTURE Drymix is 100% owned by United Holding Company (S. A. E) 56. 5% 43. 5% 41% Eng. Ali Moussa & Family 2. 5% Eng. Badr Sednaoui & Family 5

SISTER COMPANIES AND OWNERSHIP 50% UHC - 50% BASF The world’s leader in concrete admixtures, concrete repair, water proofing, and heavy-duty flooring products. Market leaders in Egypt. 50% UHC - 50% BPB World’s largest producer of gypsum and market leader in Egypt 60% Asian Paints - 40% UHC One of the top 5 paint companies in Egypt. Asian paints is one of the top ten decorative paint companies worldwide. 50% UHC - 50% Unitech Issam Kabbani & Partners The largest waterproofing contractor in the Middle East 100% UHC Middle East Sealants and Adhesives 6

PRODUCTION FACILITY Tower Height: 33. 5 m Level 4: Sand Sieving Level 3: Silos Level 2: Dosing / Weighing Level 1: Mixer and Control Room Level 0: Packing / Bulk Loading 7

Level 4: Sand Sieving Machine Benefits of Factory controlled sieved sand: – Pre-sieved sand is quality control inspected to ensure that it is free from salts and other similar contaminants. – Exact granulometry and moisture content are quality controlled. 8

Level 3: Raw Materials and Additives Silos 14 silos 120 ton each for storing bulk raw materials 16 silos 2. 5 ton each for storing additives 9

Level 2: Dosing and Weighing Computerized Weighing & Dosing Machines (i. e. load cells) to ensure the exact components of each product. 10

Level 1: Mixer and Control Room A 1, 500 Liter mixer especially designed for mortars Fully computerized control room connected by hot line with M-Tec/ Maxit Germany Mixer has three agitators that ensure homogenous grinding of materials and additives Computerized manufacturing to ensure consistency and repeatability of the products 11

Level 0: Packing / Bulk Loading 600 Bag/hour packing machine that can handle bags from 10 Kgs – 50 Kgs Outlet for bulk loading (50 ton banana truck can be filled with dry mortar in 75 minutes) 12

Bulk Delivery Silos 13

QUALITY CONTROL / R&D LAB All the incoming materials & final products are tested in our labs according to specifications & international standards to ensure their conformities Common tests include: Granulometry Blaine test Moisture content Color comparisons Slump test Dry and wet density tests Air content Adhesion test Flexural and compressive strength Abrasion and absorption test Open time & pot life Shrinkage and expansion 14

Quality Control / R&D Lab Drier used for moisture content testing Lab shaker for sieving test 15

Quality Control / R&D Lab Flow Table Test Adhesion test using pull-off apparatus 16

DRYMIX PRODUCTS SURFACE PREPRATION PRODUCTS DRY PUTTY DRY PLAST COLORED DECORATIVE RENDERS & COATING DRY DECOR ADHESIVE MORTARS &TILE GROUT DRY FIX FLOORING PRODUCTS DRY FLOOR BONDING PRODUCTS DRY BOND SEALER PRODUCTS DRY SEAL DRY GROUT 17

SURFACE PREPRATION PRODUCTS Products For Putting & smoothing of walls & ceiling Products for Plastering & Leveling of Substrates made of masonry block , concrete…. etc Dry Putty 101 Dry Plast 201 Dry Putty 103 Dry Plast 202 Dry Putty 111 Dry Plast 203 Dry Plast 204 Dry Plast 208 18

PUTTIES FOR SMOOTHENING OF WALLS & CEILINGS Dry Putty Comply with DIN 18550 Dry Putty 101 Dry Putty 103 (skim coat) Dry Putty 111 Cement based, polymer modified one component putty smoothening internal and external surfaces prior to painting and coating applications. Cement based, polymer modified, one component ready mixed skim coat mortar. Cement based, ready mixed one component putty for smoothening internal and external surfaces prior to painting and coating applications. 19

PUTTIES FOR SMOOTHENING OF WALLS & CEILINGS Characteristics of Dry Putty Easy to use and apply. Excellent mixing and workability characteristics. Extreme temperature resistance from -30˚C to +70˚C. Excellent bonding characteristics to fair face concrete. Breathable, allows the substrate to breath without delimination. Excellent resistance to extreme weather conditions. 20

21

22

PLASTER FOR LEVELING CONCRETE & MASONRY SUBSTRATES Dry Plast 203 Cement based, polymer modified spatter dash and cosmetic repair mortar on fair face concrete substrate. Applied prior to the applications of Dry Plast 201, 202 & 204. Dry Plast 208 Cement based, ready mixed, spatter dash mortar for plastering on masonry blocks and concrete substrates. Applied prior to the application of Dry Plast 201, 202 & 204. 23

PLASTER FOR LEVELING CONCRETE & MASONRY SUBSTRATES Dry Plast 201 Cement based, ready mixed, smooth finish plastering mortar on concrete and masonry surfaces. Dry Plast 202 Cement based, ready mixed, coarse finish plastering mortar Dry Plast 204 Cement based, ready mixed plastering mortar on concrete and masonry surfaces. 24

COLORED DECORATIVE RENDERS & COATING Dry Decor Dry Décor 301 Dry Décor 302 Dry Décor 304 Dry Décor 307 Dry Décor 313 25

COLORED DECORATIVE FAÇADE RENDERS AND COATINGS Dry Decor 301 Cement based, ready mixed, colored decorative (smooth finish) façade render, suitable for extreme weather conditions (internal & external applications). Dry Decor 302 Cement based, ready mixed, colored decorative (medium groove of graviatto surface texture) façade render, suitable for extreme weather conditions (internal & external applications). 26

COLORED DECORATIVE FAÇADE RENDERS AND COATINGS Dry Decor 304 Cement based, ready mixed, colored decorative (artificial stone finish) façade render, suitable for extreme weather conditions (internal & external applications). Dry Decor 307 Cement based, ready mixed, colored decorative façade coat for extreme weather conditions, can be applied by roller or brush (internal & external applications). Dry Decor 313 Cement based, ready mixed, colored decorative mortar, one coat application façade render (mono coat). 27

28

COLORED DECORATIVE FAÇADE RENDERS AND COATINGS 29

COLORED DECORATIVE FAÇADE RENDERS AND COATINGS 30

COLORED DECORATIVE FAÇADE RENDERS AND COATINGS 31

TILES ADHESIVE MORTARS & TILES GROUTS Dry Fix Adhesive mortar & Tile Grout Dry Grout Adhesive mortars for fixing ceramics, mosaic, porcelain, granite and marble tiles (walls & floors) Tiles Grouts (colored joints grouting mortars) 32

ADHESIVE MORTARS FOR FIXING CERAMICS, PORCELAIN & MARBLE TILES Dry Fix 400 Cement based, ready mixed thick bed tile adhesive mortar. Ideal for fixing ceramic & mosaic tiles (floors & walls). Cement based, ready mixed multi purpose tile adhesive mortar. Dry Fix 401 Ideal for fixing marble, ceramic & mosaic tiles, especially in wet areas such as bathroom, shower room & kitchen. 33

ADHESIVE MORTARS FOR FIXING CERAMICS, PORCELAIN & MARBLE TILES Cement based, ready mixed, flexible thin set tile adhesive mortar. Dry Fix 402 Ideal for submerged areas (i. e. swimming pools, water tanks & bathroom). Suitable for fixing heavy weight marble, porcelain, ceramic and mosaic tiles, thin bricks up to 50 Kg/m² weight. 34

ADHESIVE MORTARS FOR FIXING CERAMICS, PORCELAIN & MARBLE TILES Cement based, ready mixed, flexible thin set tile adhesive mortar. Dry Fix 405 Ideal for submerged areas (i. e. swimming pools, water tanks & bathroom). Suitable for fixing heavy weight marble, granite, porcelain, ceramic and mosaic tiles, thin bricks up to 70 Kg/m² weight. 35

36

TILES GROUTS (COLORED JOINTS GROUTING MORTARS) Dry Grout Cement based, ready mixed, colored wide joints grouting Dry Grout 413 mortar. It provides smooth dense and durable joints grout with joint’s width 4 mm to 15 mm (applicable for walls & floors). Cement based, ready mixed, colored narrow joints grouting Dry Grout 414 mortar. It provides smooth dense and durable joints grout with joint’s width up to 5 mm (applicable for walls & floors). 37

FLOORING PRODUCTS Cement based, polymer modified, self-leveling Dry Floor 601 SL underlayment floor screed. Excellent leveling properties and provide very smooth surface. Dry Floor 602 S Cement based, ready mixed, polymer modified floor screed. Excellent bonding characteristics, provide smooth surface. 38

FLOORING PRODUCTS Dry Floor 603 Dry shake concrete floor surface hardener. Applied by dry shake technique over freshly poured concrete floor to produce hard wearing and abrasion resistant surface. 39

FLOORING PRODUCTS Dry Floor 603 CH Dry shake concrete floor surface color hardener. Ideal floor hardener for stamped concrete. Dry Floor 603 RA Release agent for stamped concrete applications. Should be spread after the application of Dry Floor 603 CH. 40

BONDING PRODUCTS Cement based, highly polymer modified, flexible thin set adhesive mortar. Dry Bond 4000 Dry Bond 4001 Fixing polyurethane decorative molding products (cornices, ceiling centers and door frames) to concrete, cementitious plastered walls & ceilings, bricks and block walls. Fixing glass block walls. Cement based, highly polymer modified, flexible thin set adhesive mortar. Fixing expanded polystyrene thermal insulation boards to different (concrete, cementitious plastered walls & ceilings). Fixing external insulation and finish system (EIFS). 41

BONDING PRODUCTS Bonding agent, based on Poly Vinyl Acetate Copolymer (PVA). Dry Bond 511 Used for the following applications (as a mixture): Spatter dash, plaster & rendering mortar. Floor screed. Bonding new screeds. Bonding agent, based on Styrene Butadiene Rubber (SBR). Used for the following applications ( as a mixture): Dry Bond 540 Spatter dash mortar & bonding new to old concrete. Floor screed & cement based tile adhesive. Waterproof plaster (swimming pools & water tanks). 42

SEALER PRODUCTS High quality, semi-gloss, colorless, acrylic-based copolymer, Dry Seal 801 used as impregnating sealer for stamped concrete systems. High penetration characteristics and excellent abrasion resistance. High quality, colorless silane-siloxane impregnating primer Dry Seal 802 and water repellent seller. Ideal for sealing mineral and highly alkaline substrates. 43

SEALER PRODUCTS High quality acrylic copolymer emulsion sealer for porous Dry Seal 860 Dry Seal 444 substrates. Highly impregnated into porous substrate. It strengthens weak substrates. High performance additive, that can be mixed with Dry Grout 413 & 414 for excellent antibacterial properties. 44

PROOF PRODUCTS Cement based, two components flexible waterproofing slurry. Dry Proof 507 Suitable for internal and external waterproofing applications. Ideal for water retaining structures such as swimming pools and potable water tanks. Cement based, polymer modified one components waterproofing slurry. Dry Proof 517 Suitable for internal and external waterproofing applications. Ideal for water retaining structures such as swimming pools and potable water tanks. 45

46

47

48

49

50

51

52

53

54

55

56

57

58

Thank You 59
