Digital Ultrasonic Diagnostic Imaging System DUS 602013 Edan
- Slides: 29
Digital Ultrasonic Diagnostic Imaging System -- DUS 60(2013) Edan Instruments, Inc. Ultrasonic Imaging System www. edan. com. cn care for. Feb. , 19, 2013 health
General Information DUS 60(2013) Certificate: CE care for health
General Information l l l l 12. 1 inches TFT-LCD screen Net weight is only 7. 1 kg Two transducer connectors Multi-frequency broadband transducer selection PW Doppler function Multi-pseudo-color options Multi-Beam-Forming Phased Inversion Harmonic Compound Imaging IP (Image Processing) function 256 -frame cine loop memory Multi-language function 2 USB ports Built-in rechargeable Li-ion battery (optional) DICOM 3. 0 (optional) Large capacity integrated hard disk(optional) [Products and Solutions] care for health
Features 12. 1 `` LCD monitor 7. 1 Kg light-weight design PW Doppler e. HCI technology 5 -fresuency transducer 8 -segment TGC Built-in rechargeable 320 G built-in hard disk Backlight keyboard lithium battery Multi-Pseudo color care for health
Technologies DUS 60(2013)’s image quality and penetration has been improved significantly by using various of technologies • • Phased Inversion Harmonic Compound imaging Multi-Beam-Forming Synthetic Aperture Dynamic Receiving Focusing Real-time Dynamic Aperture Dynamic Frequency Scanning Dynamic Apodization care for health
Clinic Images With advanced technologies and enhanced support of PW imaging, DUS 60(2013) is able to provide the excellent images and meet the higher diagnostic requirements. care for health
Clinic Images Common Carotid Artery DUS 60(2013) care for health
Clinic Images Tyroid DUS 60(2013) care for health
Clinic Images Liver DUS 60(2013) care for health
Clinic Images Kidney DUS 60(2013) care for health
Transducers DUS 60 (2013) provides superb value across the entire range of applications with varies of transducers. Convex array transducer C 361 -2, Applications: Abdomen, OB, GYN, Urology Frequencies: 2. 5/3. 5/4. 5/H 2. 7 Scanning Angle: 60° Convex array transducer C 341 -2, Applications: Abdomen, OB, GYN Frequencies: 2. 5/3. 5/4. 5/H 2. 7 Scanning Angle: 90° Convex array transducer C 363 -2, Applications: Abdomen, OB, GYN, Urology Frequencies: 2. 5/3. 5/4. 5/H 2. 7 Scanning Angle: 60° care for health
Transducers Linear array transducer L 741 -2 Applications: Small parts Frequencies: 6. 5/7. 5/8. 5/H 4. 7 Scanning Length: 40 mm Linear array transducer L 761 -2, Applications: Musculoskeletal, Vascular, Breast, Orthopedics Frequencies: 6. 5/7. 5/8. 5/H 4. 7 Scanning Length: 60 mm Linear array transducer L 743 -2, Applications: Small parts Frequencies: 6. 5/7. 5/8. 5/H 4. 7 Scanning Length: 40 mm care for health
Transducers Micro-convex array transducer C 611 -2, Applications: Cardiac, Pediatric Frequencies: 5. 5/6. 5/7. 5/H 4. 7 Scanning Angle: 90 Transvaginal transducer E 611 -2, Applications: OB, GYN Frequencies: 5. 5/6. 5/7. 5/H 4. 7 Scanning Angle: 155° Endorectal transducer E 741 -2, Applications: Urology Frequencies: 6. 5/7. 5/8. 5/H 4. 7 Scanning Length: 40 mm care for health
Standard Configurations • • • DUS 60(2013)main unit 12. 1” TFT-LCD monitor Two transducer connectors Power Doppler Imaging Multi-pseudo-color Imaging 256 frames cine loop memory 504 MB built-in image storage Two USB ports Measurement & calculation software packages: General, obstetric, small parts, gynecology, orthopedics, cardiology, peripheral vessels, urology • Convex array transducer: C 361 -2 (2. 5/3. 5/4. 5/H 2. 7 MHz) care for health
Other Accessories • • • Needle-guided brackets for transducers Integrated hard disk Video printer Laser printer Inkjet printer Footswitch Li-ion battery Mobile trolley Hand carried bag DICOM 3. 0 UMS 100 workstation software care for health
Parameters • • • Dimensions: 220 mm(L)x 330 mm(W)x 320 mm(H) Net weight: 7. 1 kg Power supply: 100 V-240 V ~ 50 Hz / 60 Hz Lithium battery: Continuous working for 2 hours Imaging mode: B, 2 B, 4 B, B+M, M, and PW Gray scales: 256 Scanning angle: up to 152 degree (depending on transducers) Scanning depth (mm): from 19 to 324 (depending on transducers) Cine loop: 256 frames bidirectional cine-loop Zoom: x 1. 0, x 1. 2, x 1. 4, x 1. 6, x 2. 0, x 2. 4, x 3. 0, x 4. 0 in distance Body mark: >130 types care for health
Peripheral port • • USB port: 2 S-video output: 1 Footswitch port: 1 Ethernet port: 1 VGA output: 1 Video output: 1 Remote control: 1 care for health
Competition Analysis Domestic Competitors • Mindray: DP 50, DP 30, DP 6900 • Sono. Scape: A 6 care for health
Competition Analysis DP 30 DP 6900 care for health
Competition Analysis Brand EDAN Mindray Model DUS 60(2013) DP 30 DP 6900 12. 1 inch LCD 10 inch non-interlaced 2 standard 1 standard, 2 optional General Monitor Transducer Connector Transducers Transducer Frequency 2. 5 -8. 5 MHz, H 2. 5 -4. 7 2. 0 -10 MHz Convex Yes Yes Linear Yes Yes Micro-convex Yes Yes Endovaginal Yes Yes Endorectal Yes Yes THI Yes TSI Yes Yes No No Backlight Keyboard Yes Yes Video output Yes Yes S-Video output Yes No No VGA output Yes Yes USB port Yes Yes DICOM 3. 0 Yes Yes Hard Disk Digital Technology e. HCI, m. BEAM, Synthetic aperture, speckle suppression Others Function PW Pseudo color Others Yes, 320 G Yes, 80 G Biospy guide Yes Yes Footswitch Yes Yes Mobile Trolley Yes Yes Hand Carried Bag Yes Yes Battery Yes Yes care for health
Competition Analysis Strength Item DUS 60(2013) DP 30 Description PW-mode Yes No Doppler function Pseudo-color Yes no More color to choose S-Video output Yes No Avoid image distortion during Video signal transmission Weakness Item DUS 60(2013) DP 30 12. 1'' LCD Angle adjustable Description Monitor 12. 1'' LCD Net Weight 7. 1 Kg 5. 5 Kg Heavier Intraoperative T-shape Transducer No Yes Less options for transducer Not adjustable care for health
Competition Analysis Strength Item DUS 60(2013) DP 6900 Description PW-mode Yes No Doppler function Pseudo-color Yes no More color to choose Storage 504 Mb built-in 320 G optional 400 Mb built-in 80 G optional More storage S-Video output Yes No Avoid image distortion during Video signal transmission Monitor 12. 1'' LCD 10'' non-interlaced Wider view Net Weight 7. 1 Kg 11 Kg Easier to carry Weakness Intraoperative T-shape Transducer DUS 60(2013) DP-6900 Description No Yes Less options for transducer care for health
Competition Analysis DP 50 care for health
Competition Analysis Brand EDAN Mindray Model DUS 60(2013) DP 50 12. 1 inch LCD 15 inch LCD 2 standard Convex Yes Linear Yes Micro-convex Yes Endovaginal Yes Endorectal Yes No Yes General Monitor Transducer Connector Transducers intraoperative T-shape Digital Technology speckle suppression Others Yes e. HCI, m. BEAM, Synthetic aperture Space compound imaging Function PW Yes No Pseudo color Yes Build-in storage 504 Mb Others Backlight Keyboard Yes Video output Yes S-Video output Yes No VGA output Yes USB port Yes DICOM 3. 0 Yes Hard Disk Yes Biospy guide Yes Footswitch Yes Mobile Trolley Yes Hand Carried Bag Yes Battery Yes care for health
Competition Analysis Strength Item DUS 60(2013) DP 50 Description PW-mode Yes No Doppler function S-Video output Yes No Avoid image distortion during Video signal transmission Weakness Item DUS 60(2013) DP 30 Description Monitor 12. 1'' LCD 15'' LCD Angle adjustable The screen is smaller, and not adjustable No Yes More function as optional No Yes Less options for transducer Trapezoidal imaging, lithotripsy guided function Intraoperative T-shape Transducer care for health
Competition Analysis A 6 care for health
Competition Analysis Brand EDAN Sono. Scape Model DUS 60(2013) A 6 12. 1 inch LCD 12 inch LCD General Monitor Net Weight Transducer Connector 7. 1 Kg 6 Kg 2 standard Transducers Transducer Frequency 2. 5 -8. 5 MHz, H 2. 5 -4. 7 2. 0 -12. 0 MHz Convex Yes Linear Yes Micro-convex Yes Endovaginal Yes Endorectal Yes DBF Yes DRF Yes RDA Yes DFS Yes DRA Yes e. HCI, m. BEAM, Synthetic aperture THI Yes No Digital Technology Others Function PW Pseudo color 7 8 256 -frame 504 Mb >10000 in JPG(45 kb/JPG) >130 >50 Backlight Keyboard Yes Video output Yes VGA output Yes USB port Yes DICOM 3. 0 Yes Hard Disk Yes Battery Yes Cine-loop Build-in storage Body mark Others care for health
Competition Analysis Strength Item DUS 60(2013) A 6 Description PW Yes No Doppler function S-Video output Yes No Avoid image distortion during Video signal transmission Item DUS 60(2013) A 6 Description Monitor 12. 1'' LCD 12'' LCD Angle adjustable Not adjustable Net Weight 7. 1 Kg 6 Kg Heavier Weakness care for health
Thank you care for health
