PVSS SCADA SYSTEMS USED DURING HCC OVERVIEW OF THE NEW FEATURES 23. 09. 2009

PVSS SCADA SYSTEMS USED DURING HCC OVERVIEW OF THE NEW FEATURES 23. 09. 2009 MP 3 - Frédéric BERNARD 1

Outline The PVSS systems involved in the hardware commissioning The Circuit Synotics with CRYO

Outline The PVSS systems involved in the hardware commissioning The Circuit Synotics with CRYO data The QPS & n. QPS applications The PIC application 23. 09. 2009 MP 3 - Frédéric BERNARD 2

PVSS applications overview CMW TOP / HWC / Circuit Synoptic PVSS CIRCUIT Clients TOP

PVSS applications overview CMW TOP / HWC / Circuit Synoptic PVSS CIRCUIT Clients TOP / LHC Control / LHC Machine Interlocks / PIC - Powering Interlocks system CCM LHCOP PVSS PIC Clients TOP / HWC / Cryogenics CIRCUIT PVSS Server PVSS CRYO Clients CRYO PVSS Servers QPS & n. QPS PVSS Servers PIC PVSS Server QPS OK CRYO PLCs FGC FECs QPS FECs PIC PLCs … 23. 09. 2009 MP 3 - Frédéric BERNARD 3

Sequencer - PVSS applications • Close switch • Snapshot • Zero calibrate • Reset

Sequencer - PVSS applications • Close switch • Snapshot • Zero calibrate • Reset CIRCUIT PVSS Server • Global Lock from SIS • Monitor CIP status + Cmd • DQAMGA test mode • Monitor agent status 8 QPS & 8 n. QPS PVSS Servers PIC PVSS Server QPS FECs PIC PLCs … 23. 09. 2009 MP 3 - Frédéric BERNARD 4

Circuit synoptics - New features n. QPS data compatible: In the Powering Subsector view

Circuit synoptics - New features n. QPS data compatible: In the Powering Subsector view In the Circuit views In the World. Fip views Access Control with NICE accounts CRYO data in the Circuit Synoptics 23. 09. 2009 MP 3 - Frédéric BERNARD 5

Circuit synoptics - CRYO data Get the essential cryogenic signals for each electrical circuit

Circuit synoptics - CRYO data Get the essential cryogenic signals for each electrical circuit to make available all information required for circuit powering in one single application. It will provide: For each electrical circuit (monitoring only): Cryo Start status Cryo Maintain status CV 891 valve sensor for each current lead TT 893 for each current lead = temperature at top of CL TT 891 A for each current lead = temperature at bottom of CL Liquid level LT 83 x of the DFB Pressure PT 83 x inside the DFB Temperature TT 83 x inside the DFB Online trends and correlations of FGC data vs QPS, PIC & CRYO Cryo equipment information (e. g. thresholds etc…) 23. 09. 2009 MP 3 - Frédéric BERNARD 6

Circuit synoptics - CRYO data CMW TOP / HWC / Circuit Synoptic PVSS CIRCUIT

Circuit synoptics - CRYO data CMW TOP / HWC / Circuit Synoptic PVSS CIRCUIT Clients TOP / LHC Control / LHC Machine Interlocks / PIC - Powering Interlocks system CCM LHCOP PVSS PIC Clients TOP / HWC / Cryogenics CIRCUIT PVSS Server PVSS CRYO Clients BE-CO DM Databases Circuit names Cryo Equipments CRYO PVSS Servers QPS & n. QPS PVSS Servers PIC PVSS Server QPS OK CRYO PLCs FGC FECs QPS FECs PIC PLCs … 23. 09. 2009 MP 3 - Frédéric BERNARD 7

Circuit synoptic - CRYO data t n e m p o vel De 23.

Circuit synoptic - CRYO data t n e m p o vel De 23. 09. 2009 MP 3 - Frédéric BERNARD 8

QPS & n. QPS - Features QPS: Only Deadband on LSB for U_QS 0

QPS & n. QPS - Features QPS: Only Deadband on LSB for U_QS 0 and U_RES -> more data flow in QPS PVSS servers (need more time to retrieve data from trends, LHCLogging etc…) (around 4 Hz) Other data: around 0. 1 Hz (based on the run in september 08) n. QPS: DQAMG type S S 12 - S 23 – S 45 - S 56 - S 78 Only Deadband on LSB for U_RES and U_MAG: around 4 Hz Other data: around 0. 1 Hz Data available from the World. Fip views + Profile Graph (2 Hz) U_RES and U_MAG from DQQBS available from PVSS and store in LHCLogging at 0. 1 Hz Expert commands (GTW): no yet RBAC EN-ICE and TE-MPE are working on a strategy Will be discussed with BE OP before implementation Macro: Close switch + Reset system Zero Calibrate On (DQAMGS only) Snapshot (DQAMC MB and MQ) 23. 09. 2009 MP 3 - Frédéric BERNARD = idem the last year -> available for the Sequencer in October 9

QPS & n. QPS – World. Fip view 23. 09. 2009 MP 3 -

QPS & n. QPS – World. Fip view 23. 09. 2009 MP 3 - Frédéric BERNARD 10

n. QPS - Trends The trend parameters have to be defined 23. 09. 2009

n. QPS - Trends The trend parameters have to be defined 23. 09. 2009 MP 3 - Frédéric BERNARD 11

PIC – Features New permission definition (remove the interlock generic accounts) RBAC configuration (Sequencer

PIC – Features New permission definition (remove the interlock generic accounts) RBAC configuration (Sequencer + SIS + Timing) Masking of signals (e. g. CRYO_START, QPS_OK etc…) Post Mortem from PIC PVSS PIC Super-locks Summary of Locking/Super-locking Global Locking/Unlocking of circuits Automatic Locks from SIS PP 60 A 23. 09. 2009 MP 3 - Frédéric BERNARD 12

PIC PVSS – main panel 23. 09. 2009 MP 3 - Frédéric BERNARD 13

PIC PVSS – main panel 23. 09. 2009 MP 3 - Frédéric BERNARD 13

PIC PVSS – PP 60 A panel 23. 09. 2009 MP 3 - Frédéric

PIC PVSS – PP 60 A panel 23. 09. 2009 MP 3 - Frédéric BERNARD 14

PIC PVSS – Locks list 23. 09. 2009 MP 3 - Frédéric BERNARD 15

PIC PVSS – Locks list 23. 09. 2009 MP 3 - Frédéric BERNARD 15

PIC PVSS – Masks list 23. 09. 2009 MP 3 - Frédéric BERNARD 16

PIC PVSS – Masks list 23. 09. 2009 MP 3 - Frédéric BERNARD 16

PIC PVSS – Global commands 23. 09. 2009 MP 3 - Frédéric BERNARD 17

PIC PVSS – Global commands 23. 09. 2009 MP 3 - Frédéric BERNARD 17

PIC – Post Mortem 23. 09. 2009 MP 3 - Frédéric BERNARD 18

PIC – Post Mortem 23. 09. 2009 MP 3 - Frédéric BERNARD 18

Next developments ? nt e m lop e v De Circuit synoptics Split the

Next developments ? nt e m lop e v De Circuit synoptics Split the Circuit view to distinguish the PIC, QPS and Power Converters status QPS RBAC for the Sequencer PIC Panel to display the history of the Super-locks 23. 09. 2009 MP 3 - Frédéric BERNARD 19

PVSS applications in DIAMON 23. 09. 2009 MP 3 - Frédéric BERNARD 20

PVSS applications in DIAMON 23. 09. 2009 MP 3 - Frédéric BERNARD 20
