1 CHAPTER 4 GROUNDING AND GROUND GRID DESIGN
- Slides: 54
1
CHAPTER 4. GROUNDING AND GROUND GRID DESIGN 1. Defining Design Objective Grounding system Equipment grounding System Grounding Ground rod and Grounding electrode 2. Soil resistivity and Ground Resistance Measurement Soil Characteristic Resistivity Measurement Resistance Measurement 3. Grid substation Grounding 4. Ground Grid Calculation 5. Grid Resistance 6. Computer aided Ground grid design 2
Grounding System (IEEE) as a conducting connection, whether intentional or accidental by which an electric Circuit or equipment is connected to the earth. Bonding is intentional electrical interconnecting of conductive path in order to ensure common electrical potential between the bounded parts. Equipment Grounding is interconnecting all non current carrying metal part (Body) of an electrical power system, and then connecting the interconnected metal parts to the earth. System grounding is the process connecting neutral point of system equipment to ground. 3
The reasons for grounding : • Personal safety by limiting potentials between all non-current-carrying metal parts of electrical power system. • Personal safety and control of electrostatic discharge (ESD) by limiting potentials between all non current-carrying metal parts of an electrical power system and the ground. • To provide a low-impedance fault return path to the power source to facilitate the operation of over current device during the ground fault. 4
System Grounding: • Un Grounded System • Grounded System - Solid grounding - Resistance grounding - Reactance grounding - Ground fault neutralizer - Distribution Transformer, etc There is no one best system grounding method. In choosing among the various options, the designer must consider the requirements for safety, continuity of service, and cost. 5
Equipment Grounding and System Grounding 6
Ungrounded means that there is no intentional Between a current-carrying conductor and ground Solidly grounded means that an intentional zero impedance Connection is made between a current-carrying conductor and ground. Impedance-grounded means that an intentional impedance Connection is made between a current-carrying conductor and ground. 7
Criteria of System Grounding Low Resistance : Ro 2 Xo and IFG = (10% - 25%) I 3Ø High Resistance : Ro • Effective X 0 • Reactance X 0 Xco/3 and IFG is small 3 X 1 ; R o X 1 and IFG > 60 % I 3Ø 10 X 1 and IFG = (25% - 60 % ) I 3Ø 8
Solid Grounded Wye System 9
Ungrounded Delta System 10
The basic reasons for system neutral grounding • To limit over voltage • To limit electric potential difference • To isolate faulty equipment and circuits • To provide low-impedance return path from the Load back to the source and improve fault protection. • To hold system neutral point equal ground point 11
Table Comparison of system Grounding Methods No. Characteristic assuming No Fault Escalation System Grounding Method Solidly Ground ed Ungrounded High resistance 1. Operation of over-current device on First ground fault Yes No No 2. Control of internally generated transient Over-voltage Yes No Yes 3. Control of steady state overvoltage Yes No Yes 4. Flash Hazard No Yes No 5. Equipment damage from arcing ground fault (can be controlled) No Yes No 6. Over-voltage (on un-faulted phases) from Ground L-N Voltage >> L-L Voltage 7. Can serve line to neutral load Yes No No 12
Ground Rod and Grounding Electrode ? Ground rod is an electrode rod buried in the earth for purpose of grounding systems. Grounding conductor is conductor that connect the grounding system to earth for purpose to keep the entire grounding system at the earth potential. Grounding electrode is a conductor can be as wires/rod, strips, plates in intimate contact with the earth for the purpose of providing a connection with the grounding and bonding. 13
Ground rod made of : Ion or steel rods must be at least 5/8 in (15 mm) diameter; Copper-clad stainless-steel, or stainless steel-clad rod must be at least ½ -in (12 mm). Rods should be driven to at least 8 ft (2. 45 m). If a driven rod hits a rock bottom, the depth may < 8 feet. Part of a Ground electrode system available in a facility, • Metal underground water pipe • Metal frame of building or structure • Concrete-encased electrodes. • Ground encircling a building. 14
Ground electrode Resistance Calculations 15
The main factors that influence the resistance are the number of rods (paralel) , resistivity of the soil and the length. Formula resistance of a rod of length L and diameter d, resistivity soil ρ Ohm 16
Soil Resistivity Soil resistivity is one of the most important factors, in designing, grounding system of a substation. The characteristic of the soil resistivity are primarily affected by: • Soil type (size, variability and density), • Moisture • Temperature • Salt content • Compactness 17
Table Average Resistivity of Various Soils Resistivity (Ohm-m) Type of soils Wet organic soil 10 Moist soil 100 Dry soil 1, 000 Bed-rock 10, 000 18
Effect of salt, moisture, and temperature on Soil resistivity 19
Soil Resistivity Measurement • Wenner Method • Schlumberger-Palmer Method i). Wenner arrangement (Equally Spaced). • Spaced a distance of a meters apart. • Driven rod to a depth not normally exceeding 0. 1 a (about 0. 3 meters) • Outer probes are connected to the current terminal (C 1 and C 2) • Inner probes to the potential terminals (P 1 and P 2). 20
The Wenner soil resistivity measurement arrangement (d<<a), then the apparent resistivity : ρ = 2 a. R 21
ii) Schlumberger-Palmer (Unequally-spaced). Similar to Wenner, except that the inner (voltage) probe spacing is varied independently of the current probe spacing. If the depth of burial of the electrodes b is small compared to their separation d and c, Measured resistivity can be calculated 22
23
Ground Resistance Measurement. Normally using The fall of potential method is the most common the three-point technique. 24
Resistance of a rod of length L (m) and diameter d (m) in uniform soil of resistivity ρ (ohm-m) Ohm Grid Substation Grounding Two main design goals to be achieved • To provide means to dissipate electric currents into the earth without exceeding any operating and equipment limits. • To assure that a person in the vicinity of grounded facilities is not exposed to the danger of critical electric shock. 25
The arrangement of the grounding grid with 72 meshes. 26
There are two conditions that person within or round the substation may be experience • Touch voltage • Step voltage A touch voltage is normally considered a hand to foot or a hand to hand contact; A step voltage creates a path through the legs from one foot to the other. 27
Exposure to touch voltage Touch voltage, Etouch = Ib (RB + Zth ) The resistance of two feet in parallel Zth = Rf / 2 = 1. 5 s Touch voltage Circuit Equivalent 28
Exposure Step voltage The step voltage Estep = Ib( RB +Zth) Thevenin equivalent Impedance for 2 feet Zth = 2 Rf = 6 ρS Step voltage Circuit Equivalent 29
Permissible Body Current Limit Dalziel concludes of all men could withstand, without ventricular fibrillation, A IB : rms magnitude of the current through the body, A ts : duration of the current exposure, sec k : 0. 116 for a 50 kg person and 0. 157 for a 70 kg person. based on test in the range of 0. 03 to 3. 0 second duration 30
Table limitations of the electric currents flow through the body 31
Permissible Step and Touch Voltages (Volt) Step voltage for the body 50 kg and 70 kg, respectively If no protective surface layer is used, then Cs =1 and ρs = ρ. 32
Touch voltage for the body 50 kg and 70 kg, respectively : Soil resistivity at the surface, Ohm-m Cs : reduction factor for derating the nominal value of ts : Fault clearing time, seconds. 33
Steps of grid calculation analysis: • Investigation of soil characteristics • Determination of maximum ground fault current • Preliminary design of the ground system • Calculation of resistance of the ground system • Calculation of step voltage at periphery • Calculation of internal step and touch voltages • Refinement of preliminary design. 34
The maximum grid current IG. IG = Sf If where IG : Symmetrical ground fault current (3 I 0), A If : Rms value of symmetrical fault current, A Sf : Ratio of grid current to fault current. The maximum grid current IGM = Df IG Df is the decrement factor for the fault duration. 35
A single line to ground fault, A double line to ground fault, X 1, X 2 and X 0 are Positive sequence reactance, Negative and Zero, respectively. 36
Selection of Conductors are used for grounding system, grid conductors, connections, connecting lead, and all primary electrodes must be adequate criteria as below; i). Have sufficient conductivity ii). Resist fusing and mechanical deterioration under short circuit. iii). Be mechanically reliable and rugged to a high degree. iv). Be able to maintain its function even exposed to corrosion or physical abuse 37
Conductor materials may be used: • Cooper is used for grounding. • Copper–clad steel is used for underground rods and occasionally for grid conductors, especially where theft is a problem. • Aluminum is used for ground grids less frequently. • Steel can be used for ground grid conductor and rods. 38
The calculation tolerable Step, and mesh voltage based up on IEEE standard 80 -1986. Vstep = KS Ki (IG / L) Ki = 0. 172 N + 0. 656 N = number of grid conductors 39
L = Lc + 1. 15 LT (with ground grid and rods) LC : total length of the ground conductor, m LT : total length of the ground rods, m D : spacing between parallel conductors, m h : depth of the ground grid conductors, m Number of conductors in horizontal Nx = (Lx/D + 1) Number of conductors in vertical Ny = (Ly/D + 1) Length total in horizontal = 40
The mesh voltage tends to be highest in the mesh rectangle nearest to the perimeter. d : diameter of the grid conductor, m. h : depth of grid 41
The ground resistance of grounding grid, R : substation ground resistance, : soil resistivity, A : area of the grounding grid m 2 42
According to Laurent and Nieman According to Svarack Equation, or 43
The calculation tolerable Step, and mesh voltage based up on IEEE standard 80 -2000. Mesh Voltage Km = the geometrical factor Ki = a corrective factor, 44
For grids with no ground rods or grids with only a few ground rods, none located in the corners or on the perimeter. 45
Step Voltage Ks = The geometrical factor, Ki = The corrective factor, For grids with or without ground rods, the effective buried conductor length, LS, is 46
47
The required data for the program for analysis/design • The soil resistivity at the substation location • Fault duration Current division factor • System impedance • Line to line voltage at worst-fault location • Crushed rock resistivity • Thickness of crushed rock surface • Depth of grid • Span distance of conductor • Available ground area • Conductor type in use • Fault Clearing 48
Improving The Performance of The Grounding Grids • Increasing the grounding area; the most effective way to decrease ground resistance is by increasing the area occupied by the grid. • Improvement of gradient control; If mesh voltage is higher than the allowed touch voltage, a modified grid can be designed by subdividing the meshes. • Addition of a relatively high resistance surface layer. A layer of crushed rock can be added on the surface of the substation to increase the resist. in series with the body. • The available fault current magnitude may be reduced by connecting overhead ground wires of transmission lines. • Limiting of short-circuit current to the ground grid. 49
Fig. Mesh voltage for different grid area 50
a modified grid can be designed by subdividing the meshes 51
Assignment A grid substations have parameter are given as below Number of parallel conductor, n = 16 Soil resistivity, ρ = 750 ohm-m ρ S = 3, 000 ohm-m Fault current, IG = 1, 200 A and clearing time, t = 0. 75 sec. Total length of conductor, L = 1, 600 m Conductor spacing in parallel, D = 4 m Conductor diameter, d = 0. 016 m Depth of grid conductor, h = 0. 8 m Body resistance is 1, 000 ohm (i) Calculate mesh voltage and step voltage (ii) Calculate allowable step voltage and touch voltage 52
Example 1. A grid substations have parameter are given as below Number of parallel conductor, n = 16 Soil resistivity, ρ = 750 ohm-m ρ S = 3, 000 ohm-m Fault current, IG = 1, 200 A and clearing time, t = 0. 75 sec. Total length of conductor, L = 1, 600 m Conductor spacing in parallel, D = 4 m Conductor diameter, d = 0. 016 m Depth of grid conductor, h = 0. 8 m For the above condition, the values of factors such as Km = 0. 3695, Ki = 3. 042 , and Ks = 0. 4014. Body resistance is 1, 000 ohm (i) Calculate mesh voltage and step voltage (ii) Calculate allowable step voltage and touch voltage 53
Assignment , A grid substations have parameter are given as below Available grounding area =100 x 100 m square Soil resistivity, ρ = 750 ohm-m. Crushed rock resistivity, ρS = 3, 000 ohm-m Thickness of crushed rock surfacing, hs = 20 cm Depth of grid conductor, h = 0. 8 m Line to line voltage 115 k. V, duration fault, tf = 0. 5 s Fault current = 1200 A. Conductor spacing in parallel, D = 5 m Conductor diameter, d = 0. 016 m Assume body resistance is 1, 000 ohm and body weight 70 kg. Using Std. IEEE 86 and 2000, determine (i) a. Calculate mesh voltage and step voltage b. Calculate allowable step voltage and touch voltage (ii) Repeat above question if grid with ground rod : Length and number of ground rod are 5 m and 20 pieces, respectively. (iii). Grounding resistance for two above conditions according Nieman and also Sverack. 54
