Megadyne Medical Products MEGA Soft® Family of Products

Megadyne Medical Products MEGA Soft® Family of Products

MEGA Soft® Reusable Patient Return Electrode What is It? • Reusable Electrosurgical Grounding Pad-unlimited

MEGA Soft® Reusable Patient Return Electrode What is It? • Reusable Electrosurgical Grounding Pad-unlimited use for 2 years Placa de aterramento eletrocirurgica reutilizável – uso ilimitado por 2 anos • Replaces Sticky Pads. Substitui as placas descartáveis.

MEGA Soft® Reusable Patient Return Electrode What is It? • Easy to Use- for

MEGA Soft® Reusable Patient Return Electrode What is It? • Easy to Use- for the surgeon and the nursing staff. Facil de usar – para médicos e enfermeiras. • Safely Exits Current from Patient and Returns it Back to the Generator-but not through the pad. A corrente sai com segurança do paciente e retorna ao gerador - mas não atráves de uma placa

MEGA Soft Innovation • Improve patient safety Melhorar a segurança do paciente • 50

MEGA Soft Innovation • Improve patient safety Melhorar a segurança do paciente • 50 million procedures with 0 pad site burns. 50 milhões de procedimentos com 0 queimaduras. • Safer than REM! Mais seguro do que REM!

MEGA Soft Innovation • Improve the clinical outcome Melhorar o resultado clínico • Prevents

MEGA Soft Innovation • Improve the clinical outcome Melhorar o resultado clínico • Prevents pressure ulcers and skin irritation/tears Previne úlceras de pressão e irritação na pele

MEGA Soft Innovation • It is simple and easy to use - As easy

MEGA Soft Innovation • It is simple and easy to use - As easy as making the bed É simples e fácil de usar - Tão fácil como fazer a cama • Offers superior value 2 products in one, can usually save hospitals $$$. Oferece um valor superior - dois produtos em um, economia para os hospitais.

MEGA Soft- What is It? • SAFER than Monitoring Style Pads Mais seguro que

MEGA Soft- What is It? • SAFER than Monitoring Style Pads Mais seguro que as placas de monitoramento • Capacitive Pad --- Relies on “Contact”-the larger the area and closer to the pad, the better the coupling. Placa Capacitiva --- se baseia no "Contato", quanto maior a área e mais perto da manta, melhor o acoplamento.

MEGA Soft- What is It? • Limits Current Flow Limita o fluxo de corrente

MEGA Soft- What is It? • Limits Current Flow Limita o fluxo de corrente • if small patient area in “contact” with pad, current flow is decreased to a level such that burns do not occur Se a área do paciente em "contato" com a manta é pequena, o fluxo de corrente é reduzido a um nível onde não ocorram queimaduras. • if current flow is limited, surgeon will see diminished effect at active electrode Se o fluxo de corrente é limitado, o cirurgião vai ver a redução na potencia do eletrodo ativo

How does the MEGA Soft work? • It is a capacitive pad not a

How does the MEGA Soft work? • It is a capacitive pad not a conductive pad. Trata-se de uma placa capacitiva e não uma placa condutora. • A capacitor is defined as 2 conductors separated by an insulator. Um capacitor é definido como dois condutores separados por uma camada isolante.

How does the MEGA Soft work? • Current is induced through CLOSE CONTACT with

How does the MEGA Soft work? • Current is induced through CLOSE CONTACT with the pad. Corrente é induzida através de contato íntimo com a almofada. • Heat does not build up and no pad site burns occur. O calor não se acumula e as queimaduras não ocorrem.

How does it work?

How does it work?

What do I need to know? • Limit layers-the closer the pad to the

What do I need to know? • Limit layers-the closer the pad to the patient, the better it works. Camadas-limite quanto mais próximo a placa do paciente, melhor ele funciona. • Maximize contact, especially with small patients. Portions of the patient not on the pad can impact the performance. • Maximizar o contato, principalmente com os pequenos pacientes. Parcelas do paciente sem estar em contato com a placa pode afetar o desempenho.

What do I need to know? • Current limiting technology prevents heating, NO PAD

What do I need to know? • Current limiting technology prevents heating, NO PAD SITE BURNS! Tecnologia de limitação de corrente impede aquecimento, SEM QUEIMADURAS!

The “Classic” • 0800 -Our original pad, launched back in 1999. 0800 -Nossa placa

The “Classic” • 0800 -Our original pad, launched back in 1999. 0800 -Nossa placa original, lançado em 1999. • 18 months of use. 18 meses de uso

The “Classic” • Requires a sheath that is changed daily. Requer um revestimento que

The “Classic” • Requires a sheath that is changed daily. Requer um revestimento que é alterado diariamente. • No pressure reduction pad. Nenhum coxim de redução de pressão

MEGA Soft® - Overview • Catalog #0830 Catalogo #0830 • Combines capacitive coupling technology

MEGA Soft® - Overview • Catalog #0830 Catalogo #0830 • Combines capacitive coupling technology with a pressure reduction pad. Combina a tecnologia do eletrodo capacitivo e a redução de pressão de uma placa.

MEGA Soft® - Overview • Pressure Reduction pad is made of a dry viscoelastic

MEGA Soft® - Overview • Pressure Reduction pad is made of a dry viscoelastic polymer called Akton® by Action products. A redução de pressão e feita por um polímero viscoelástico chamado Akton feito pela Action products. • 24 months of use 24 meses de uso.

MEGA Soft Dual Cord • Catalog #0835 Catalogo #835 • Used in procedures that

MEGA Soft Dual Cord • Catalog #0835 Catalogo #835 • Used in procedures that require two separate generators. Usado em procedimentos que requerem dois geradores

MEGA Soft Dual Cord • If only one cord is used, a cap is

MEGA Soft Dual Cord • If only one cord is used, a cap is provided to plug off the additional cord Se apenas uma entrada for usada, uma tampa é fornecida para bloquear a outra entrada.

Benefits over “Sticky” Pads • No more hair clipping at pad site Não é

Benefits over “Sticky” Pads • No more hair clipping at pad site Não é preciso fazer tricotomia • No concerns with implants, tattoos, or scar tissue Sem preocupações com implantes, tattoos ou cicatrizes • Does not damage fragile skin Sem danos a pele frágil • Do not have explain to patient; placement, redness, shaved area, etc. Não precisa explicar ao paciente; vermelhidão, area raspada, etc. • Environmentally friendly-GO GREEN! Amigo do meio ambiente • SAFER! Seguro! • Can Save $$$ Econômico!

MEGA Soft Awareness • Generator restrictions Restrições – Not for use with ground referenced

MEGA Soft Awareness • Generator restrictions Restrições – Not for use with ground referenced generators. – Not for ERBE units with High Cut or Endo Cut modes. Não pode ser usado nos modelos ERBE com modos High Cut e Endo Cut

MEGA Soft Awareness – Not for use with RF Ablation. Não pode ser usado

MEGA Soft Awareness – Not for use with RF Ablation. Não pode ser usado em Radiofrequência • For use on patients greater than 25 lbs. Para pacientes acima de 11 Kg

Pad Details • How do you clean it? Como limpar? • Does it have

Pad Details • How do you clean it? Como limpar? • Does it have latex? Tem latex? • How do you warm it? Como aquece-lo? • What about implants and pacemakers? E sobre implantes e marcapasso? • Patient positioning? Posicionamento do paciente?

MEGA Soft Positioning Chart Andrews Spine

MEGA Soft Positioning Chart Andrews Spine

New on the scene-2009. • Pediatric Mega Soft® – 100’s of pads have already

New on the scene-2009. • Pediatric Mega Soft® – 100’s of pads have already been placed • • John Hopkins St. Jude Shriner’s Boston St. Francis Children’s UCSF Shriner’s Sacramento St. Christopher’s – Launched at AORN! (March 17, 2009)

Pediatric Patient Concerns • Small surface area-where to place “sticky” pad? Pequena área para

Pediatric Patient Concerns • Small surface area-where to place “sticky” pad? Pequena área para colar as placas descartáveis • Delicate skin Pele delicada • Keeping the patient warm Manter o paciente aquecido • Positioning the patientbolsters and rolls Posicionando o paciente – travesseiros e rolos

Pediatric Mega Soft • For use on patients from 0. 8 lbs (350 g)

Pediatric Mega Soft • For use on patients from 0. 8 lbs (350 g) and 50 lbs (22. 7 kg). Usado em pacientes de 350 g a 22, 7 kg. • LIMIT materials-one linen or underbody Bair Hugger between pad and patient. Limite de materiais – apenas uma roupa entre o eletrodo e o paciente

Pediatric Mega Soft • Place position aids (ie. gel rolls, rolled towels, etc. underneath

Pediatric Mega Soft • Place position aids (ie. gel rolls, rolled towels, etc. underneath the pad) Acessórios para posicionamento (rolos em gel, toalhas e etc. debaixo da placa) • Latex free just like our other Mega Soft pads. Latex Free como nossos outros Mega Softs

Megadyne’s claim over REM!

Megadyne’s claim over REM!

Example of edge effect burn

Example of edge effect burn

50 Million Procedures! • 0 Pad Site Burns! 0 queimaduras!

50 Million Procedures! • 0 Pad Site Burns! 0 queimaduras!
