SLC 500 Ethernet Processor Communications Configuration SLC 500

SLC 500 Ethernet Processor Communications Configuration

SLC 500 Processors • • • 5/01 DH-485 5/02 DH-485 5/03 DH-485 and serial 5/04 DH+ (PLC 5) and serial 5/05 Ethernet and serial

SLC 5/05 Communications Overview • Setup personal computer IP address and subnet mask. • In your RSLogix 500 project, set up Ethernet channel configuration. • Download using a different driver such as serial if Ethernet IP is different from processor channel configuration. • Use Ethernet driver for future up/downloads or on-line editing.

Create New Project Enter project name. Select your Processor. Select processor station number. Select Ethernet driver you configured.

Configure Ethernet Channel Double-click here.

Select Channel 1 System Tab Click once here to go to Ethernet channel configuration.

Enter IP Address from RSLinx RSLogix 500 channel configuration RSLinx driver configuration

Use Serial Communications to Download New Configuration New IP address will replace current IP.

Go To RSWho and Verify Ethernet Communications You should see your SLC PLC here Double-click on the Ethernet driver.

RSWho Displaying Unrecognized Device

Download Project First click on Comms. Second, click on System Comms.

Select Ethernet Driver and Processor Left click once to select Ethernet driver Click here to download.

Downloading Messages SLC processor Name of project to be downloaded Memory size Name of project currently in processor Click yes to continue Downloading.

Update Driver and Node for Online Tool Bar Current node Current driver

Processor Must Be in Remote Program Mode to Download

Change Processor Back to Run Mode

Go Online with Processor?

Processor Status Tool Bar When online, the ladder will be turning. Processor is in remote run mode. This is the current driver. The current station address
