Sistemi Diagnostici per Tomografia Tridimensionale con Raggi X

Sistemi Diagnostici per Tomografia Tridimensionale con Raggi X - TTRX Coordinator: Prof. Franco Casali Participants: Ø Ø Ø Franco Casali, Centro Fermi Maria Pia Morigi, Department of Physics and Astronomy, University of Bologna Fauzia Albertin, Centro Fermi Rosa Brancaccio, Department of Physics and Astronomy, University of Bologna Matteo Bettuzzi, Department of Physics and Astronomy, University of Bologna Maria Giovanna Belcastro, Bi. Ge. A, University of Bologna Place of Work: Ø Department of Physics and Astronomy, University of Bologna Collaborations: Ø INFN TT_CHNet Ø INFN CNAF & INFN _TTLab Ø Sistema Museale di Ateneo, Università di Bologna Fauzia Albertin Museo Storico della Fisica e Centro Studi e Ricerche “Enrico Fermi”

Project main goals CT systems: New tomographic system - for View. Lab @ Centro Fermi New CT techniques CT Applications: Anthropological and Archaeological artifact analysis Works of Art analysis Outreach: New dissemination tools –e. g. 3 D Holographic displays and 3 D Printer European Researchers’ Night 2018

2018 Activities Cultural Heritage investigations 2018 Ancient Etruscan remains analysis in collaboration with Prof. Belcastro

Bones (of child or animal) found near a wall of a temple on the Etruscan site of Marzabotto (ancient town near Bologna). Bad state of preservation of skeletal findings. Acquired from a "block of ground ” technique. Our group, together with Giovanna Belcastro (UNIBO), is studying for a 3 D reconstruction of the skeleton image. Roma, March 2018 - PTA 4

2018 Activities Cultural Heritage investigations 2018 Pre-Colombian Ceramics in collaboration with MIC - International Museum of Ceramics in Faenza Exhibition: Aztec, Maya, Inca and the Cultures of the Ancient America, 11 th November to 28 th April 2019 http: //www. micfaenza. org * These images cannot be used without explicit consent of MIC - International Museum of Ceramics in Faenza

2018 Activities Cultural Heritage investigations 2018 Pre-Colombian Ceramics in collaboration with MIC - International Museum of Ceramics in Faenza Exhibition: Aztec, Maya, Inca and the Cultures of the Ancient America, 11 th November to 28 th April 2019 http: //www. micfaenza. org * These images cannot be used without explicit consent of MIC - International Museum of Ceramics in Faenza

2018 Activities Cultural Heritage investigations 2018 Analysis of an Egyptian cat-shaped sarcophagus and two cat mummies in collaboration with the Archaeological Museum of Bologna Axial section * These images cannot be used without explicit consent of the Archaeological Museum of Bologna

2018 Activities Cultural Heritage investigations 2018 Analysis of an Egyptian cat-shaped sarcophagus and two cat mummies in collaboration with the Archaeological Museum of Bologna Axial section * These images cannot be used without explicit consent of the Archaeological Museum of Bologna

Mummia di falco

2018 Activities Milestone 1: Hardware upgrade of the mobile CT system for large-scale objects; Milestone 2: Development of innovative methodologies for 3 D tomography reconstruction, analysis, rendering and dissemination - including 3 D printers; Milestone 3: Completion of the CT facility of the View. Lab; Milestone 4: Acquisition of a 3 D holographic pyramid to visualize the CT analyses of works of art.

2018 Activities Milestone 1: Hardware upgrade of the mobile CT system for large-scale objects Implementation of similar carbon fibers translational axes is strongly discouraged. An ex-novo design is required.

2018 Activities Milestone 2: Innovative methodologies for 3 D tomography reconstruction, analysis, rendering and dissemination - including 3 D printers Use and distribution of 3 D open-source rendering software easily accessible for restorers and museums 3 D Printed tomographic results - in collaboration with the Mechanical Workshop of INFN (Bologna). Now in exhibition at Faenza: Aztec, Maya, Inca and the Cultures of the Ancient America, 11 th November to 28 th April 2019

2018 Activities Milestone 3: Completion of the CT facility of the View. Lab Instruments characteristics defined X-ray Tube v v 90 -320 KV 1 -6 m. A 60 x 40 beam angle 2. 5 x 2. 5 mm focal spot Cabinet characteristics to be defined by the qualified expert in radiation protection X-ray Detector XRD 1622 by Varian (now Varex) v v 41 x 41 cm 200 µm pixel 14 bit 1 fps X-ray Cabinet v Up to 200 k. V v mm Pb to be defined

2018 Activities Milestone 4: Acquisition of a 3 D holographic pyramid to visualize the CT analyses of works of art 3 D holographic pyramid ordered and soon available European Researchers’ Night 2018 - Bologna

Publications 2018 Papers 2018 - Colombo A. , Stephens N. , Tsegai Z. J. , Bettuzzi M. , Morigi M. P. , Belcastro M. , & Hublin, J. -J. , Analyse microarchitecturale du développement de la marche bipède chez le jeune enfant. , Bulletins et Mémoires de la Société d'Anthropologie de Paris. BMSAP, 30(Suppl. 1), 13 -13, 2018. - M. P. Morigi and F. Casali, Radiography and Computed Tomography for Works of Art, in Handbook of X-ray Imaging: Physics and Technology, 1185 -1210, Editor P. Russo, Boca Raton: CRC Press. Conferences 2018 - F. Albertin, M. Bettuzzi, R. Brancaccio, M. P. Morigi, F. Casali, Indagine tomografica di antiche maschere teatrali giapponesi, 104° Congresso Nazionale della Società Italiana di Fisica - SIF 2018. - F. Albertin, M. Bettuzzi, R. Brancaccio, M. P. Morigi, F. Casali, D. Picchi, La tomografia X di oggetti di grandi dimensioni in situ: il sarcofago egizio di Unmontu, 104° Congresso Nazionale della Società Italiana di Fisica - SIF 2018. - F. Albertin, Manuscripts X-ray Digitization, Time Machine Conference 2018 – Invited Talk. - F. Albertin, Virtual X-ray reading of fragile ancient manuscripts: from closed testaments to books , Technology, digital tools and manuscript heritage: opportunities, issues, questions 2018 – Invited Talk.

Plan of Activities 2019 -2021 Milestones Milestone 1: Hardware upgrade of the mobile CT system for large-scale objects: ex-novo design of the translational axes and Hexapod motors for automatic alignment • • Ex-novo design of the translational axes Purchase of an hexapod motor for automatic alignment Milestone 2: Completion and fully operability of the CT facility of the View. Lab • Once the cabinet characteristics will be defined by the qualified expert in radiation protection we will proceed to the instruments purchase and installation

Plan of Activities 2019 -2021 Milestones Milestone 3: Development of a new project, in collaboration with the “Museo Archeologico Regionale Lilibeo – Marsala”, for scientific investigation and dissemination of the Museum collection • Tomographic investigation (in situ and in Bologna) of a selected part of the collection; • Development of innovative systems for dissemination of scientific investigations, such as holograms of 3 D-CT renderings and 3 D printed objects; • Development of innovative systems for historical information dissemination as informative videos and animations– where appropriate in collaboration with external partners Milestone 4: Research and development of different tomographic techniques to be developed for in situ Cultural Heritage investigations • Dual Energy Tomography: designed to increase the visibility of low absorbing materials (e. g. soft tissue) and minimize metal artifact; it is now available only for medical applications; • Possible collaboration with private companies.

Plan of Activities 2019 -2021 Milestones 2019 Milestone 1: Ex-novo design of the translational axes Milestone 2: Completion of the CT facility of the View. Lab Milestone 3: Starting of the new collaboration with the Lilibeo Museum and first CT measurement campaigns both in Bologna and in situ Milestone 4: Study and development of Dual Energy CT for Cultural Heritage objects

Plan of Activities 2019 -2021 In situ CT analysis of a celestial globe by Vincenzo Coronelli at Biblioteca Nazionale Marciana - Venice Starting in February - March 2019 In collaboration with: INFN CHNet 19

Expected funding 2019 -2021 Ø Request of funding to Centro Fermi Ø Grant: 1 for 2019 -2021 Ø Specific Consumables: 15 k€ per year Ø Travel expenses (including transfer of equipment on-site): 30 k€ Ø Potential external funding Ø INFN CHNet: 20 k€
