Phase camera development for gravitational wave detectors Kazuhiro Agatsuma Martin van Beuzekom, David Rabeling, Guido Visser, Hans Verkooijen, Wilco Vink, Jo van den Brand 4 th/June/2014 TIPP at Amsterdam 2014/June/4 TIPP@Amsterdam 1
Contents Phase camera is prepared for Advanced VIRGO • Background – – Gravitational waves GW detector VIRGO Marginally stable power recycling cavity • Phase camera – Principle – Setup plan in Ad. V • Prototype experiment at Nikhef • Selection of components • Summary and plan 2014/June/4 TIPP@Amsterdam 2
Gravitational waves Predicted by A. Einstein (1916) Nobody detect it directly yet Gravitational waves Indirect evidence ¨Hulse and Taylor pulsar (1974) => Nobel prize (1993) ¨BICEP 2 (2014 in discussion) Direct observations will make a new method to observe universe ¨Binary neutron star ¨Black hole ¨Super nova ¨Inflation ¨Unknown source ¨etc… z y x ¨General relativity ¨Beginning of universe 2014/June/4 TIPP@Amsterdam 3
Gravitational wave detector Michelson Interferometer Fabry-Perot Michelson Interferometer Power recycled Fabry-Perot Michelson Interferometer Dual recycled Fabry-Perot Michelson Interferometer Laser x Power recycling BS mirror EOM fp Signal recycling mirror Input Mode Cleaner Modulation-Demodulation (Pound–Drever–Hall technique) is used to operate IFO (control position and angle) 2014/June/4 y Fabry-Perot Cavity Output Mode Cleaner Photo detector TIPP@Amsterdam 4
VIRGO Nikhef contributes to VIRGO (Collaboration between France, Italy, Netherlands, Poland Hungary) Upgrade VIRGO => advanced VIRGO (Ad. V) (Italy, Pisa) [http: //www. ego-gw. it/public/about/welcome. aspx] Worldwide competition to the first detection ¨LIGO (USA) ¨KAGRA (Japan) After the first detection World competition => World corroboration 2014/June/4 TIPP@Amsterdam 5
Marginally stable recycling cavity VIRGO uses marginally stable recycling cavity Þ Degeneration of higher order modes (HOMs) ITM (Sideband power reduction can easily happen by aberration of mirrors) Aberrations ¨Thermal lens ¨Substrate inhomogeneities ¨Surface shape errors Þ Control becomes unstable PRM Wave front sensor CO 2 laser BS ITM Pick-off Solution: Thermal Compensation System (TCS) Sensor: Phase camera, Actuator: CO 2 laser with compensation plate 2014/June/4 TIPP@Amsterdam 6
Phase Camera Frequency selective wave front sensor ¨Heterodyne detection ¨Pin-hole scanning IFO (Pick-off mirror in IFO) PM for IFO EOM fp AOM f. H BS Reference beam (Frequency shift by f. H) Scanner Test beam (with PM: fp) Demodulation f. H, f. H+fp, f. H-fp I Q Pin-hole Mapping of amplitude and phase 2014/June/4 TIPP@Amsterdam 7
Setup plan in Ad. V Phase camera will be placed on three ports PC 1: Input beam [f 1 - f 5] PC 2: Power recycling cavity [f 1, f 4] PC 3: Output beam [f 2] PC 1 PC 2 CO 2 laser EOM IMC : Arm cavity control (common) PC 3 : SRC : PRC OMC : Support for f 1 : Input MC Five sidebands will be used 2014/June/4 TIPP@Amsterdam 8
Setup plan in Ad. V Frequency shifter: Fiber coupled AOM PC 1: Input beam (Injection bench) PC 2: Power recycling cavity (B 4) PC 3: Output beam (B 1 p) 2014/June/4 TIPP@Amsterdam 9
Prototype test at Nikhef - Current setup • • • Test beam: Phase modulator (EOM): DC -> 250 MHz Reference beam: Frequency shift (AOM): 80 MHz Scanner: Galvanometer (GVS 012) Photo-detector : New focus 1811 (125 MHz) DSP: – LAPP fast ADC/FPGA board (400 MHz Clock) – Ad. V Real-time system signal processing 2014/June/4 TIPP@Amsterdam Each sideband is selective 10
Prototype test at Nikhef Laser EOM AOM Galvanometer PD 2014/June/4 TIPP@Amsterdam 11
Mapping result (preliminary) Carrier • Test beam: 10 MHz PM • Power ratio (test beam and reference beam) is not optimized here Test Reference => Calculation of SNR using actual parameters is in progress USB • The phase between carrier and sidebands should be identical in the ideal IFO => Subtraction of those shows aberration map! 2014/June/4 TIPP@Amsterdam 12
Scanning pattern (Archimedes' spiral) 32 x 32 pixels: 16 Hz 128 x 128 pixels: 64 Hz 256 x 256 pixels: 128 Hz In the case of the total acquisition time of 1 second to make one pattern (According to a simulation, a total acquisition time of at least 2 -5 s [0. 03 s] is necessary in order to keep sufficient precision of the phase measurement) Standard aperture diameter: 5 mm Test beam size: w = (2. 5) / 3 = 833 um Quickest acquisition is 0. 25 s (128 x 128 pixels, 256 Hz) with our scanner (Requirement: 100 x 100 pixels) 2014/June/4 TIPP@Amsterdam 13
Scanner (PZT scanner) ~300 Hz 5 mm PD 20 cm Tilt angle range: 50 mrad (± 25 mrad) Þ to scan 5 mm range, a half a maximum voltage is necessary with 20 cm distance ÞThe quickest operation is 300 Hz 2014/June/4 TIPP@Amsterdam 14
Photodiode board New PD has been developed at Nikhef (close to completion) Flat response up to 700 MHz • • FCI-In. Ga. As-55 Active area diameter = 55 mm (pin-hole) NEP 2. 66 e-15 W/rt. Hz Flat window, AR coated (VIR-0439 A-13) 2014/June/4 • • DC output and RF TIA: HITTITE 799 LP 3 E 10 k. Ohm DC – 700 MHz 46 n. V/rt. Hz output noise (spec) = 4. 6 p. A/rt. Hz input referrred Shot noise limited if Idiode > ~66 u. A TIPP@Amsterdam 15
Digital demodulation board 11 x ‘DFT-slice’ I PD in ADC atan fh +/- f 1. . f 5 power to DAQ block Q sample clock Hann* cosine LUT 16 k cntr 0. . N-1 Hann* sine LUT 16 k Df I fh f 1. . f 5 ADC atan fh +/- f 1. . f 5 Q • • • Digital Demodulation at 11 (fixed) frequencies (fh+/f 1. . f 5) in parallel 14 bit ADC at 500 MS/s + Xilinx Virtex-7 FPGA Measure phase (and power) using 16 k samples per ‘pixel’ – can measure 32 k ‘pixels’ per second, frequency resolution ~30 k. Hz • Best resolution when using external ref. frequencies (i. e. diff. phase measurement) – (VIR-0439 A-13) s = ~0. 3 m. Rad at 211 MHz 2014/June/4 TIPP@Amsterdam 16
Optical layout design (PC 1) z=0 (※) preliminary design Optical layout is in progress 2014/June/4 TIPP@Amsterdam 17
Summary and Plan Summary • Phase camera can observe wave fronts for each PM sideband => Useful monitor for TCS in Virgo • Prototype experiment is on going – Component selection has done – High speed PD and digital board are being prepared at Nikhef Plan (in progress) • SNR calculation using actual parameters • Optical layout drawings 2014/June/4 TIPP@Amsterdam 18
