EE 4237 Lecture-3 Induction Motor – Constant Flux Control Dr. Habibullah, Sep. 2019 EE 4237 - Special Machines and AC Drives 1

Constant Airgap Flux Control Constant V/f control employs the use of variable frequency voltage source inverters (VSI) Constant Airgap Flux control employs variable frequency current source inverters or currentcontrolled VSI Provides better performance compared to Constant V/f control with Slip Compensation airgap flux is maintained at rated value through stator current control Dr. Habibullah, Sep. 2019 EE 4237 - Special Machines and AC Drives 2

Speed response similar to equivalent separatelyexcited dc motor drive but torque and flux channels still coupled Fast torque response means: High-performance drive obtained Suitable for demanding applications Able to replace separately-excited dc motor drives Above only true is airgap flux remains constant at rated value Dr. Habibullah, Sep. 2019 EE 4237 - Special Machines and AC Drives 3

Constant Airgap Flux Control • Constant airgap flux in the motor means: Assuming small voltage drop across Rs and Lls • For ag to be kept constant at rated value, the magnetising current Im must remain constant at rated value • Hence, in this control scheme stator current Is is controlled to maintain Im at rated value Controlled to maintain Im at rated Rs Lls Is Llr’ + + Lm Vs – Ir’ maintain at rated Dr. Habibullah, Sep. 2019 E 1 V s Rr’/s Im – EE 4237 - Special Machines and AC Drives 4

Constant Airgap Flux Control • From torque equation (with ag kept constant at rated value), since s s = sl and ignoring Rs and Lls, • By rearranging the equation: Te sl can be varied instantly instantaneous (fast) Dr. Habibullah, Sep. 2019 EE 4237 - Special Machines and AC Drives 5 Te response

Constant Airgap Flux Control Constant airgap flux requires control of magnetising current Im which is not accessible From equivalent circuit: (1) From equation (1), plot Is against sl when Im is kept at rated value. Dr. Habibullah, Sep. 2019 EE 4237 - Special Machines and AC Drives 6

Drive is operated to maintain Is against sl relationship when frequency is changed to control speed. Hence, control is achieved by controlling stator current Is and stator frequency: Is controlled using current-controlled VSI Control scheme sensitive to parameter variation (due to Tr and r) Dr. Habibullah, Sep. 2019 EE 4237 - Special Machines and AC Drives 7

Constant Airgap Flux Control Implementation Current Controlled VSI 3 -phase supply Rectifier C Current controller options: • Hysteresis Controller • PI controller + PWM r * + PI - IM Current controller slip |Is| i*a i*b + s r + Dr. Habibullah, Sep. 2019 Voltage Source Inverter (VSI) i*c r EE 4237 - Special Machines and AC Drives Equation (1) (from slide 6) 8

Current-Controlled VSI Implementation • Hysteresis Controller i*a i*b i*c + Voltage Source Inverter (VSI) + + Motor Dr. Habibullah, Sep. 2019 EE 4237 - Special Machines and AC Drives 9

Current-Controlled VSI Implementation • PI Controller + Sinusoidal PWM i*a + i*b i*c PI + PWM PI + Voltage Source Inverter (VSI) PWM PI PWM • Due to interactions between phases (assuming balanced conditions) actually only require 2 controllers Dr. Habibullah, Sep. 2019 EE 4237 - Special Machines and AC Drives Motor 10

Current-Controlled VSI Implementation • PI Controller + Sinusoidal PWM (2 phase) i*a id* i*b abc dq PI dq abc iq* PI PWM Voltage Source Inverter (VSI) i*c iq id abc dq Motor Dr. Habibullah, Sep. 2019 EE 4237 - Special Machines and AC Drives 11

References Krishnan, R. , Electric Motor Drives: Modeling, Analysis and Control, Prentice-Hall, New Jersey, 2001. Bose, B. K. , Modern Power Electronics and AC drives, Prentice. Hall, New Jersey, 2002. Trzynadlowski, A. M. , Control of Induction Motors, Academic Press, San Diego, 2001. Rashid, M. H, Power Electronics: Circuit, Devices and Applictions, 3 rd ed. , Pearson, New-Jersey, 2004. Nik Idris, N. R. , Short Course Notes on Electrical Drives, UNITEN/UTM, 2008. Ahmad Azli, N. , Short Course Notes on Electrical Drives, UNITEN/UTM, 2008. Courtesy: http: //kaliasgoldmedal. yolasite. com/resources/SSD/Induction%20 Motor%20%20 Scalar%20 Control. ppt Dr. Habibullah, Sep. 2019 EE 4237 - Special Machines and AC Drives 12
