Agilent U 8903 A Audio Analyzer Fast and accurate multi-channels audio analysis made affordable

Agilent U 8903 A Audio Analyzer Fast and accurate multi-channels audio analysis made affordable (Replacement of the HP 8903 B) Basic Instruments Division Page 1 Agilent Confidential

Why should you consider migrating your existing HP 8903 B to the new Agilent

Why should you consider migrating your existing HP 8903 B to the new Agilent U 8903 A? Existing platform: HP 8903 B 1. Higher cost of ownership: • 2. Longer operation time, higher operation cost: • • 3. Limited functions and features Does not support new interfaces such as LAN and USB. Does not support modern SCPI commands. Usage and application limitations: • • 5. Older platform with older user interface which make it harder to use. System integration limitation • • 4. Existing functions cannot be upgraded for latest and future measurements and applications. Only single channel available. Customize measurement and function not available. Will no longer be orderable since 2002. Basic Instruments Division Page 2 Agilent Confidential

What are the migration benefits? New platform: U 8903 A 1. Low cost of

What are the migration benefits? New platform: U 8903 A 1. Low cost of ownership: • • 2. Full support of GPIB, LAN, USB interfaces offering full integration flexibility. Support modern SCPI commands. 2 Channels with future upgradable options up to 8 channels User Customized option available through the USB interface (Arbitrary Waveform, Additional Filters) Additional NEW features: • • 6. 4 x more accurate and 7 x Faster measurement speed. Versatile platform: • • 5. New intuitive easier to user interface with color LCD display. System ready platform • • 4. Financial solution to get easy and fast access to the new units: Easy Buy, Easy Rent, Easy Lease… www. microlease. com/agilent Shorter operation time, lower operation cost: • • 3. 40% off** for trade in of HP 8903 B units FFT, Scope, Cross-Talk Noise Generation, Wider Frequency Already available for purchase ** - 40% is based on total maximum combined discounts - Discount based on first come first serve basis for limited allocated units Basic Instruments Division Page 3 Agilent Confidential

New U 8903 A Audio Analyzer Replacing the Popular HP 8903 B Audio Analyzer

New U 8903 A Audio Analyzer Replacing the Popular HP 8903 B Audio Analyzer Fast and accurate multi-channels audio analysis made affordable The new U 8903 A Audio Analyzer has: u 5. 7” Color Display u Softkey for easy function selection u One button quick access menu u USB/LAN/GPIB connectivity u Dual-channel generator outputs and analyzer inputs with XLR connectors u Fast and accurate measurement and analysis on essential audio parameters u High quality test signals generator u Next generation capabilities and replaces HP 8903 B Basic Instruments Division Page 4 Agilent Confidential

See the improvements for yourself! U 8903 A and HP 8903 B Outlook Comparison

See the improvements for yourself! U 8903 A and HP 8903 B Outlook Comparison One-button access to: √ Analyzer √ Generator √ Sweep √ Graph – FFT or Time dom. 5. 7 inch color display Localized Help function Softkeys for easy function selection Two DB-25 connectors for multi-channel connections Plug and play USB 2. 0 Dual-channel generator outputs and analyzer inputs with XLR connectors Six additional input and output channels Front Panel Rear Panel USB/LAN/GPIB Interface Full Spec to Spec Comparison Table Basic Instruments Division Page 5 Agilent Confidential

Key Benefits U 8903 A Feature Scalable Structure Description “Main box + 3 plug-in

Key Benefits U 8903 A Feature Scalable Structure Description “Main box + 3 plug-in card slots” structure standard main box consist of 2 channels Benefits/Value Upgradable in future – additional analog input/ output. Support digital audio in future. User-friendly GUI Easy function selections. Simple Generator/ Analyzer/ Graph/ Sweep mode within a press of a button. Graphical view for FFT analysis and sweep functions. Extensive selections of filters Contains standards: LP, HP and Weighting filters. User defined filter can be transfer to U 8903 A through USB port. Designed for convenience – easy to operate See measurement results at a glance. Easily upload special filters via the USB port. High measurement accuracy. Accurate and Versatile Low inherent distortion and noise (-101 d. B) Offers various selections of detectors and measurement parameters High quality test signals Sine/ Multitones/ Square/ Arbitrary/ Noise/ IMD/ DFD with low inherent distortion and flatness Include user define waveform capability via the use of the USB port Give accurate characterization of audio frequencies. Provides reliable and customizable test signal sources for DUT. Basic Instruments Division Page 6 Agilent Confidential

Target Applications CE Audio and Pro Acoustic Amplifier, MP 3, TV, STB, Walkie-Talkie, Sound

Target Applications CE Audio and Pro Acoustic Amplifier, MP 3, TV, STB, Walkie-Talkie, Sound system, Mobile phone… Analog IC and Component Amplifier, Speaker, DAC, Microphone, MEMS, … Broadcasting and Network Operating Transmission, repair, maintenance, installation U 8903 A Audio Analyzer Auto Infotainment Radio, Car AV/GPS System, … Authority Test Lab Calibration, Certification , Compliance Test… Military and Defense Military Radio, Calibration Lab Basic Instruments Division Page 7 Agilent Confidential

Application Examples Radio Transmitter HW Test Two-way radio (microphone) Modulated signal out from antenna

Application Examples Radio Transmitter HW Test Two-way radio (microphone) Modulated signal out from antenna MXA Spectrum analyzer Generator output Test Procedure Connect DUT (microphone) to Audio Analyzer (generator output) Connect DUT (antenna) to Spectrum Analyzer (input) The test result are showed on LCD display or, Test report is generated at PC and print a hardcopy Set the Spectrum Analyzer frequency same as DUT’s transmits frequency. Start the test, acquire the test result Report Generation from PC and print out a hard copy MXA Browser on PC Basic Instruments Division Page 8 Agilent Confidential

Application Examples Radio Receiver HW Test ESG Signal generator Modulated signal input to the

Application Examples Radio Receiver HW Test ESG Signal generator Modulated signal input to the antenna GPIB Two-way radio (speaker) Generator output Analyzer input Test Procedure Connect Audio Analyzer (generator output) to Signal Generator (external input) Level, Frequency Response, THD+N, SINAD Connect Signal Generator (output) to DUT (antenna) Connect DUT‘s speaker output to AA (analyzer input) Set the Signal Generator frequency same as DUT’s transmits frequency. Start the test, acquire the test result. Adjust the Signal Generator carrier power to achieve the SINAD = 12 d. B (Audio Analyzer). USB/GPIB Converter (82357 B) The test result are showed on LCD display or, Test report is generated at PC and print a hardcopy Report Generation from PC and print out a hard copy Basic Instruments Division Page 9 Agilent Confidential

Application Examples Cell Phone Hand Set (Audio) Testing Test Procedure Audio Analyzer (generator) output

Application Examples Cell Phone Hand Set (Audio) Testing Test Procedure Audio Analyzer (generator) output 1 k. Hz tone to the N 4010 A (audio input). Audio In Audio Out Bluetooth signal + audio signal output from N 4010 A antenna. The bluetooth signal detected and recieved by DUT (cell phone). Connect DUT (cell phone) to 8960 for GSM connection. THD+N, Frequency level, Amplitude, SINAD Tap the audio 1 k. Hz tone from 8960 back to Audio Analyzer (analyzer input). Measure THD+N, Frequency level, amplitude and SINAD. Basic Instruments Division Page 10 Agilent Confidential

U 8903 A Product Options Product Description U 8903 A-200 2 channels Audio Analyzer

U 8903 A Product Options Product Description U 8903 A-200 2 channels Audio Analyzer U 8903 A-101 U 8903 A-104 Male XLR to Female XLR, 2 m, 150 ohm, black Male BNC to Male BNC cable, 2 m, 50 ohm, black U 8903 A-108 Male BNC to Male RCA cable, 2 m, black U 8903 A-908 U 8903 A-ABJ Rack mount kit Japanese User Guide Price from $12000 (USDDP) ** Price indicated in US dollar, it may be different from country to country and change without prior notification, please contact Agilent to obtain the local price. Basic Instruments Division Page 11 Agilent Confidential

HP 8903 B Commands VS Equivalent U 8903 A SCPI Commands Migration guide :

HP 8903 B Commands VS Equivalent U 8903 A SCPI Commands Migration guide : http: //cp. literature. agilent. com/litweb/pdf/5990 -4135 EN. pdf The HP 8903 B employs a simple, instrument specific command set (R 2 D 2) for remote programming due to limited processing power at that time. The new U 8903 A uses the modern SCPI command where it is easier to use and common in the industries. Unsupported and Equivalent Commands 8903 B commands that are not supported on the U 8903 A are generally for features that are obsolete and therefore not supported on the U 8903 A. Refer to the migration guide for more details. The 8903 B commands that are fully supported by equivalent commands on the U 8903 A are also listed in migration guide. Basic Instruments Division Page 12 Agilent Confidential

Resources for U 8903 A Data sheet: http: //cp. literature. agilent. com/litweb/pdf/5990 -3831 EN.

Resources for U 8903 A Data sheet: http: //cp. literature. agilent. com/litweb/pdf/5990 -3831 EN. pdf User’s guide: http: //cp. literature. agilent. com/litweb/pdf/U 8903 -90002. pdf Programmer’s guide: http: //cp. literature. agilent. com/litweb/pdf/U 8903 -90027. pdf Quick Start Guide: http: //cp. literature. agilent. com/litweb/pdf/U 8903 -90006. pdf Migration guide : http: //cp. literature. agilent. com/litweb/pdf/5990 -4135 EN. pdf. Where to Find the Details? • Website: www. agilent. com/find/audioanalyzer For support: Contact your local Agilent office http: //www. home. agilent. com/agilent/contact. Information. jspx? cc=US&lc=eng&nid=11143. 0&page. Mode=HB&tmprop=TM Basic Instruments Division Page 13 Agilent Confidential

“Why Buy Agilent U 8903 A Audio Analyzer? ” Fast and accurate audio measurements

“Why Buy Agilent U 8903 A Audio Analyzer? ” Fast and accurate audio measurements in a single box! 1. Protect your long term investment: • • • Versatile solution (source and measure, user define filters and output waveforms, multiple test functions, frequency and time domain…) Scalable platform with up to 8 independent input/output channels for future upgrades Built on Agilent proven record of excellent quality and reliability standard of previous HP 8903 B Audio Analyzer 2. Reduce time to market: • • Parallel testing with each independent channel 4 X more accurate and 7 X Faster than HP 8903 B • • • One box solutions with slot-in modules for various applications. Trade in your old HP 8903 B a 40% discount** on your U 8903 A purchase. Financial solutions: Easy Buy, Easy Rent, Easy Lease… www. microlease. com/agilent 3. Reduce cost of ownership ** - 40% is based on total maximum combined discounts and applicable for ATPs only - Discount based on first come first serve basis for limited allocated units Basic Instruments Division Page 14 Agilent Confidential

Appendix

Appendix

Specifications and Features Comparison U 8903 A and HP 8903 B Features Agilent U

Specifications and Features Comparison U 8903 A and HP 8903 B Features Agilent U 8903 A HP 8903 B Channels (Input/ Output) 2/ 2 (upgrade to 8/ 8) 1/ 1 Display 5. 7 inch TFT Color LCD display Annunciators Display I/O interface GPIB/ LAN/ USB GPIB Connectors BNC (unbalanced), XLR (balanced) BNC (unbalanced) Unbal: 50 , 600 Audio Generator: Impedance Bal: 100 , 600 Frequency: - Range 5 Hz to 80 k. Hz 20 Hz to 100 k. Hz - Accuracy 5 ppm (0. 0005%) 0. 3% Output Level: 0 V to 16 Vrms (balanced) - Range 0 V to 8 Vrms (unbalanced) 0. 6 m. V to 6 Vrms (unbalanced) - Accuracy ± 1% Better then 3% Waveform Generation Sine, Dual Sine, Variable Phase, Square, Arbitary, IMD, DFD Sine Product specifications and appearance in this document are subject to change without notice. © Agilent Technologies Inc. , 2009 Page 16 Basic Instruments Division Agilent Confidential

Specifications and Features Comparison U 8903 A and HP 8903 B - Continue Features

Specifications and Features Comparison U 8903 A and HP 8903 B - Continue Features Agilent U 8903 A HP 8903 B Audio Generator: Noise Generation Gaussian and Rectangular PDF Multitones Generation 60 tones Bal: 200 k Bal: 100 k Audio Analyzer: Impedance Unbal: 100 k Frequency - Range 10 Hz to 100 k. Hz 20 Hz to 100 k. Hz - Accuracy 5 ppm (0. 0005%) 0. 004% - AC measurement range < 1 V to 140 Vrms 0. 3 m. V to 300 Vrms - AC accuracy ± 1% ± 4% - DC measurement range 0 to ± 200 V 4 V to 300 V - DC accuracy ± 1% THD+N/ SINAD (20 Hz to 20 k. Hz) -101 d. B -80 d. B Input Level: Product specifications and appearance in this document are subject to change without notice. © Agilent Technologies Inc. , 2009 Page 17 Basic Instruments Division Agilent Confidential

Specifications and Features Comparison U 8903 A and HP 8903 B - Continue Features

Specifications and Features Comparison U 8903 A and HP 8903 B - Continue Features Agilent U 8903 A HP 8903 B Audio Analyzer: Audio filters: 15 k. Hz, 20 k. Hz, 30 k. Hz, 80 k. Hz - Low pass filter 20 Hz, 100 Hz, 400 Hz - High pass filter - Weighting filter A-Weighting, C-Message, CCIR-468, CCIR-ARM, CCITT A-Weighting, C-Message, CCIR 468, CCIR-ARM, CCITT - User-defined filter AC level detection RMS, Peak-to-Peak, Quasi Peak RMS IMD and DFD measurement Phase measurement Cross Talk measurement FFT Analyzer: Up to 32768 points - Size/ Acquisition length - Window Rectangular, Hann, Hamming, Blackman. Harris, Rife-Vincent 1 and 3, Flattop Sweep Capability Mode: Frequency/ Amplitude level Mode: Frequency Price USD 12, 000 (US list price) USD 7000 Product specifications and appearance in this document are subject to change without notice. © Agilent Technologies Inc. , 2009 Page 18 Basic Instruments Division Agilent Confidential
