VMLAB Win AVRCCompiler VMLAB CCompiler Win AVR http
VMLAB 설치 • Win. AVR(C-Compiler) 설치 • VMLAB 은 어셈블러는 자체 지원 • C-Compiler Win. AVR은 별도 설치해야 함 • http: //sourceforge. net/projects/winavr/files/latest/download 에서 다 운로드 • VMLAB 설치 • http: //www. amctools. com/download. htm 에서 다운로드
VMLAB 실습 예 (TLCD 실습) • Simulation Run • Run Go/Conti nue (F 5)
VMLAB 실습 예 • VMLAB 자체 제공 실습 예 • C: VMLABAVR_demo 에 있음 (어셈블리로 작성되어 있음) 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. lcd. prj : UART 로 받은 문자를 lcd 화면에 출력하는 예제 a 2 d. prj : Analog to Digital converter 데모 COMPAR. PRJ : 비교기 데모 dslope. prj : dual-slope-like 방법으로 8비트 A/D converter 데모 eep. prj : EEPROM access 데모 oscil. prj : Software controlled oscillator 데모 sinewave. prj : Timer 1의 PWM을 사용한 Sinewave generator 예제 데모 softuart. prj : Software UART example 데모 spi. prj : SPI slave example 데모 twi. Prj : TWI example 데모 uart. prj : UART 데모
Thank you~~~~
