FTP - File Transfer Protocol CISC 856 – Fall 2012 University of Delaware Ayush Dusia adusia@udel. edu (many slides courtesy of: Brian Lucas, Umakanth Puppala, William Boyer, Vikram Rajan, Michael Haggerty, Shriram Ganesh, Bo Xu and Prof Amer) Computer & Information Science

Outline File Transfer Protocol (RFC 959) • Why FTP? • FTP’s connections • FTP in action • FTP commands/responses • Internationalization of FTP (RFC 2640)

History of FTP RFC 542 RFC 354 - Remarkably similar to today’s FTP RFC 765 RFC 114 - Overall Communication Model - Still based on NCP- FTP over TCP/IP - before TCP and IP existed - Used NCP to do FTP on ARPANET April 1971 July 1972 August 1973 June 1980 Time

Why do we need a FTP service? Purpose: To transfer files between two computers Goals of FTP Service • Promote sharing of files (programs and/or data) • Encourage indirect/implicit use of remote computers • Shield users from variations in file storage among hosts • Transfer data safely, reliably and efficiently

Problems of file transfer • At first, file transfer may seem simple • Heterogeneous systems use different: – – Operating Systems Character Sets Directory Structures File Structures and Formats • FTP needs to address and resolve these problems

FTP’s “ 2” Connections client User Interface data *Non-persistent Persistent connection *Server Insulates users from “raw” is listening on port 21 * Routes “raw” FTP commands connection command andrequests reply commands for. FTP connection * Receives server’s replies *Server uses port 20 for data connections server User Control Process User Data Transfer Process Control Connection 21 Server Control Process Server Data Transfer Connection(s)20 Process

FTP’s “ 2” Connections - Establishment ftp> open ftp. udel. edu client User Interface Connected to ftp. udel. edu 220 FTP server ready. 331 Password req for anonymous. Password: 230 User anonymous logged in. ftp> PASS USERxyz@udel. edu anonymous server Control Process Control Connection Control Process Data Transfer Process Data Connection(s) Data Transfer Process

FTP’s “ 2” Connections – Data Transfer client ls server 1. txt -rw-r--r-- lucasb server 1. txt User Interface 128. 4. 40. 17 (19× 256)+137 128. 4. 40. 17: 5001 226 Data Connection LISTClosing server 1. txt 128. 4. 40. 17 19, 137 PORT 200 Port 128, 4, 40, 17, 19, 137 Command Sucessful 150 Data Connection will be open shortly server User Control Protocol Process Interpreter Control Connection Server Control Protocol Process Interpreter Passive open on Port 5001 Data Transfer Process Data Connection(s) Establish Data Connection Data Transfer Process

FTP’s “ 2” Connections – Connection Closing client User Interface bye 221 Service Closing QUIT server Control Process Data Transfer Process Control Connection Data Connection Control Process Data Transfer Process

FTP Connection Server Client ftp> OPEN ftp. udel. edu Eph SYN+ACK 21 ACK 220 Service Ready ACK ftp> USER anonymous ACK 331 User OK, password? ACK ftp> PASS xyz@udel. edu ACK 230 User login OK

FTP – Data transfer (get command) Server Client RETR server 1. txt Eph REPLY+ACK 21 200 Command Successful SYN+A CK 20 Active Open Command REUSEADDR 5001 ACK server 1. txt <CIP, 5001, SIP, 21> <CIP, 5001, SIP, 20> 150 Data Connection will be open shortly FIN Connection 21 Data Connection 20 Eph Control 5001 Eph = FIN+ACK 5001 ACK 226 Closing Data Connection

FTP – Data transfer and WAIT STATE Server Client RETR server 1. txt Eph 5001 REPLY+ACK 21 200 Command Successful SYN+A CK 20 Active Open ACK server 1. txt <CIP, 5001, SIP, 21> <CIP, 5001, SIP, 20> 150 Data Connection will be open shortly FIN Eph = FIN+ACK 5001 RETR server 2. txt (all attempt to open TCP connection will fail) 5001 SYN REPLY+ACK Time Wait State 2 MSL <CIP, 5001, SIP, 20> 200 Command Successful <CIP, 5001, SIP, 20>

FTP – Data transfer with PORT Command Client RETR server 1. txt Server PORT 128, 4 , 40, 1 7, 29, 137 Eph REPLY+ACK RETR+ACK 7561 ACK SYN+A C 21 200 Command Successful 20 K ACK 150 Data Connection will be open shortly ACK Date Transfer and FIN RETR server 2. txt Eph. PORT 128, 4, 40, 1 7, 29, 138 REPLY+ACK RETR+ACK = 7560 ACK SYN 7562 SYN+A CK ACK 21 200 Command Successful <CIP, 7561, SIP, 20> (WS) <CIP, 7562, SIP, 20> 20 Command REUSEADDR 150 Data Connection will be open shortly

FTP – Data transfer (put command) Server Client PORT 128, 4, 40, 17, 29, 139 Eph REPLY+ACK STOR client. txt 7563 ACK SYN+A C 21 200 Command Successful 20 K ACK client. t xt Eph 7563 Control Connection 21 Data Connection 20 150 Data Connection will be open shortly FIN+ACK ACK 226 Closing Data Connection

FTP – Control Connect Closing Client Eph SYN+ACK Server 21 ACK …… The client request close ns …… Request: QUIT Actio Response 221: goodbye ACK Eph Control Connection 21 FIN+ACK Closed

FTP Client Commands (issued by user interface) Command Description get filename mget filename* put filename Retrieve file from server mput filename* open server bye / close / exit ls / dir Copy multiple local files to server lcd cd rhelp / remotehelp Change local directory Retrieve multiple files from server Copy local file to server Begin login to server Logoff server List files in current remote dir on server Change remote directory Lists commands the server accepts *Server sends list of matching files to client, Client protocol interpreter asks the user for operation on each matching file.

A-PDU FTP Commands Command Description LIST [filelist ] USER username PASS password List files or directories (ls / dir) PORT h 1, h 2, h 3, h 4, p 1, p 2 Client IP and port number RETR filename STOR filename NLIST *. * Retrieve (get) filename Send username to server Password on server Store (put) filename To retrieve (mget) mutliple files

FTP Response Format Reply 1 yz Description x 2 z Positive preliminary reply. The action is being started but expect another reply before sending another cmd. Positive completion reply. A new cmd can be sent. Positive intermediate reply. The cmd has been accepted but another cmd must be sent. Transient negative completion reply. The requested action did not take place but can be sent later Permanent negative completion reply. Cmd not accepted and should not be reissued. Syntax Information Connections. Replies referring to control or data connections. x 3 z Authentication and accounting x 4 z Unspecified Filesystem status 2 yz 3 yz 4 yz 5 yz x 0 z x 1 z x 5 z

Example FTP Responses • 120 Service will be ready shortly • 200 Command OK • 230 User login OK • 331 User name OK; password is needed • 421 Service not available • 530 User not logged in • 552 Requested action aborted; exceeded storage allocation

Summary of FTP Connections • FTP has 2 connections - Control (persistent connection) - Server issues a passive open on well-known 21 - Client uses an ephemeral port to issue active open - Server ultimately closes control connection - The connection is designed for minimum delay - Data (ephemeral connection) - Client issues passive open on an ephemeral port - Client sends this port to server via PORT command - Server receives the port number and issues active open using its well-known 20 to the received ephemeral port - The connection is designed for maximum throughput

Data Connection • PORT does not always work…why? • Instead, use PASV command – Client sends PASV command to server – Server chooses ephemeral port: passive open – Server responds with IP, Port in reply (227) – Client issues active open to server’s port • Ultimately, the data sender closes connection

FTP Passive Data Transfer client ls server 1. txt -rw-r--r-- lucasb server 1. txt User Interface 226 Closing Data Connection LIST server 1. txt 227 PASV Entering Passive Mode 150 Data Connection will (128, 4, 40, 42, 20, 5) be open shortly server User Control Protocol Process Interpreter Data Transfer Process Control Connection Server Control Protocol Process Interpreter Passive open on Port 5125 Data Transfer Connection Process Establish Data Connection

Active Mode vs Passive Mode ACTIVE PASSIVE

Internationalization of FTP • The File Transfer Protocol use 7 bit ASCII and 8 bit EBCDIC • Cannot support wide range to characters • Need for single character sets understandable by all systems • RFC 2640 recommends the use of character set ISO/IEC 10646: 1993 and the UTF-8 encoding • UTF-8 consistent with ASCII character set

UTF-8 byte sequence(binary) • UTF-8 encoding represents each UCS character as a sequence of 1 to 6 bytes in length • For all sequences of one byte the most significant bit is ZERO • The number of ONE bits in the first byte indicates the number of bytes used in the UTF-8 sequence • A beneficial property of UTF-8 is that its single byte sequence is consistent with the ASCII character set 0 xxxxxxx 110 xxxxxx 1110 xxxxxx 11110 xxxxxx 10 xxxxxx 111110 xxxxxx 10 xxxxxx 1111110 x 10 xxxxxx 10 xxxxxx
