Clamp On Utvikling Omstilling i nedgangstider Tittel Anja

Clamp. On – Utvikling & Omstilling i nedgangstider Tittel Anja Bilsbak – Area Sales Manager GCE Subsea – VNR Oktobertreff 05. Oktober 2016 av Navn Name of presenter

This presentation includes: • • • Clamp. On The future Development 1994 New products Summary 2016

Clamp. On Today

Clamp. On • Head Office – Bergen – 100 employees • Clamp. On Inc, Houston TX, establ. 1997 – 10 employees • Local agents in approx. 30 countries • Approx. 3000 travel days per year • Deliveries to 40 countries per year • Equipment and service in all parts of the world where there is oil & gas activities

The future? • The day after tomorrow • Tomorrow – Downstream • Today – Upstream

The beginning – Particle Monitor

PIG Detector

… Leak Detector

Same equipment - Subsea

New topside stand-alone • • • Battery powered Four weeks operation Re-chargeable Remote wells Fits in standard bracket

Well Collision Detector

Vibration Monitor o Multiphase flow causing vibration to flow lines, flex loops, well jumpers etc. o Medium frequency, typically 2 -50 Hz

CEM® - Corrosion – Erosion Monitor

New Products 2016 • Clamp. On Crack Monitor • Clamp. On Corrosion Under Insulation

Clamp. On Crack Monitor § Condition monitoring tool § Based on Acoustic Emission (AE) § Continuous, real time monitoring § Health monitoring – CRACK – § Covers a large area – 200 m § Non-intrusive, non-destructive § Permanent/Retrofit

Clamp. On DSP Crack Monitor Typical sources could be • • • Crack Growth Corrosion Erosion Leaks Turbulence in fluids

System properties Condition Monitoring Tool • Measures the AE events and “count” the activity • The system will consist of: – – Sensor Wiring Power supply Software • The sensitivity of crack detection is better then 0, 01 mm !!

Clamp. On Corrosion Under Insulation (CUI) • Cost-effective solution to the detection of water & rust particles in thermal insulation pipeline • Long range inspection capability also in the presence of pipe supports and bends • Provide exact location of water and rust volumes • Sensitive to water vapor and rust particles (corrosion products)

Clamp. On Corrosion Under Insulation (CUI) • • Damaged cladding allows water ingress Insulation traps water next to pipe Corrosion initiates on the outer surface of the pipe High pipe temperature and temperature cycling accelerate corrosion

Antenna Installation • No need for removal of cladding • The antennas can be inserted through small holes. • The antennas are permanently installed on the pipeline

Field operation By using a portable microwave analyzer, the inspector plugs the analyzer into the antennas already installed on the pipeline and takes a reading. The signal is acquired in a few seconds and the inspector is ready to move to the next set of antennas. Portable microwave analyzer

CUI Monitoring Concept Install rings, run Baseline data. The recorded data show a clean insulation and will be a good Baseline for further monitoring. N. Aplitude 0. 6 Baseline 0. 5 0. 4 0. 3 0. 2 0. 1 0 0 10 20 30 40 50 60 Inpection length (m) 70 80 90 100 Logging #21

CUI Monitoring Concept Install rings, run Baseline data. The new measurement has indicated that there is 3 areas that we would need to look further into. The CUI monitoring system can’t tell if it is Water or Corrosion. 3 months later, run Measurement #1 ( Water and corrosion product detected) Baseline 0. 5 M#1 0. 4 0. 3 0. 2 0. 1 90 80 70 100 Inpection length (m) 60 50 40 30 20 10 0 0 N. Aplitude 0. 6 Logging #21 -M 1

CUI Monitoring Concept Install rings, run Baseline data. 3 months later, run Measurement #1 ( Water and corrosion product detected) The new measurement is interesting – we now only have 2 areas that we would need to look further into. This time only the corrosion product is present and that means water has dried up. 6 months later, run Measurement #2 ( Water dried out only corrosion product detected) Baseline 0. 5 0. 4 M#1 0. 3 M#2 0. 1 90 80 70 100 Inpection length (m) 60 50 40 30 20 10 0 0 N. Aplitude 0. 6 Logging #21 -M 2

Some of our goals! • Main market: Oil and Gas • Open for new markets; Refinery & petrochemistry etc. • Develop solutions that is needed in the oil and gas industry - Crack Monitor Corrosion Under Insulation • Focus on delivering quality instruments to the industry • Try to be cost efficient in a difficult market situation • Continue to provide the service/support that our customers need • Be the most valuable supplier for our customers

Thank you for your attention! Any questions? Anja Bilsbak Area Sales Manager anja. bilsbak@clampon. com Clamp. On www. clampon. com
