The Cosmic Distance Ladder Rung 1 Radar Ranging
- Slides: 16
The Cosmic Distance Ladder
Rung 1: Radar Ranging - Distances in the solar system - Send out radio pulses - Measure how long it takes for them To return - Distance = cy/2
Rung 2: Parallax - The stars within a few hundred light years
Beyond the third rung: Standard Candles d L
Rung 3: Main sequence of clusters as S. C. – Stars in our galaxy
1. Find a star cluster close enough to measure the distance from parallax e. g. Hyades (46 pc) 2. Compare apparent magnitude of MS with cluster farther away (e. g. Pleiades) > distance! Side note: Pleiades 7. 5 times farther away, but more visible? > it’s younger, so its most luminous, massive stars still exist
Rung 4: Cepheid variables as S. C. – Works up to 10 s of millions of parsecs away
CVs: (population I) -Pulsating yellow supergiants (F 6 -K 2), periods days-months, -Driven by doubly-ionized He; at dimmest part of the cycle, the stars radiation heats He III in the outer layers > expansion (increase in L) > cooling and recombination (He III > He) > contraction
Mean luminosity depends on the period of pulsation!
Mean luminosity depends on the period of pulsation! Determine this relation for nearby Cepheids (for which distance, hence luminosity, is known) and use it to calculate distance to more distant ones
Rung 5: The Tully-Fisher relation – Works up to billions of parsecs away
Rung 5 take II: Type Ia supernovae as standard candles White dwarf accretes matter from companion star OR two white dwarfs merge > thermonuclear explosion from runaway Carbon burning results when its mass is tipped over the Chandrasekhar limit
Technically, Type Ia SNe are standardisable candles: use the width of the lightcurves to calibrate to a single, intrinsic brightness
Rung 6: Hubble’s law – works out to the edge of the known universe • Galaxies are moving away from us at a speed proportional to their distance V=H×d • H is called Hubble’s constant
The Cosmic Distance Ladder
