Mesh Network Information Arrow. Span Wireless Mesh Network Solutions Sept 2007

Mesh Network Information Arrow. Span Wireless Mesh Network Solutions Sept 2007

ABOUT US The Company Arrow. Span Inc. , was founded in 2005 by Max

ABOUT US The Company Arrow. Span Inc. , was founded in 2005 by Max Lu, a former Cisco employee, who is the President/CEO of Arrow. Span develops and manufactures Wi-Fi mesh network solutions and is headquartered in the heart of Silicon Valley with a branch office in Beijing, China. Arrow. Span’s streamlined design philosophy and manufacturing expertise, makes our Wi-Fi mesh network solutions, the most affordable and reliable solutions on the market. Our products offer users the ability to deploy in both indoor and outdoor environments while providing them with the most cost effective, scalable, and secure Wi-Fi mesh network. Our product portfolio includes the high performance Triple RF Mesh. AP 5100/3100, the Multi. Frequency Mesh. Backhaul 2600, the Dual RF Mesh. AP 1100 Indoor. Mission Statement Our mission is to enable carriers and service providers to expand their existing wireless network to a wider reach. We are dedicated to developing a product that is the best-in-class, but also profitable, economical and easy to install. Arrow. Span is dedicated in providing quality products and customer satisfaction, and we are firm believers that our products will change the way the world goes wireless.

The Value of Arrow. Span Wireless Mesh Network Ü Cost - Arrow. Span Outdoor

The Value of Arrow. Span Wireless Mesh Network Ü Cost - Arrow. Span Outdoor Wireless Mesh Access Points are Low unit price, Industry standard 5 GHz and 2. 4 GHz spectrums, Easily deploy wirelessly. Ü Time - Arrow. Span Wireless Mesh Access Points can usually be setup and working within a couple of hours. Ü Speed - Arrow. Span Wireless Mesh Access Points can create backhaul throughput up to 30+Mbps. Ü Security - Arrow. Span Wireless Mesh Access Points offer a variety of security options; the strongest of which is WPA 2 with AES, but also support WPA/TKIP, MAC authentication, and 64. 128 bit WEP Ü Flexibility - Arrow. Span Wireless Mesh Access Points can be located anywhere wireless coverage is required. Durable weatherproof housings with carrier class temperature range assure reliable operation year round.

Arrow. Span Wireless Mesh Network Solutions Ü Complete Indoor/Outdoor product line covers full range

Arrow. Span Wireless Mesh Network Solutions Ü Complete Indoor/Outdoor product line covers full range of mesh network applications for hot zones, campuses, municipalities, warehousing, enterprise offices, small offices, and home deployments Ü Patent Pending Layer 2. 5 design architecture provides maximum compatibility and user friendly functions Ü Patent Pending POP mesh routing algorithm provides high performance and reliable solutions: Auto-configuration, Auto-discovery, Auto-healing, Auto-balancing Ü Multiple wireless RF design minimizes or eliminates signal interference problems on backhaul and user data wireless networks Ü GPS: Provides physical location of each Mesh. AP and simplifies the maintenance task Ü Single IP Setup for one mesh network (regardless node number). This setup minimizes the complicated IP address setup for each node on the mesh network

Software Features Ü Support up-to 16 SSIDs and VLANs with Single Point Propagation -

Software Features Ü Support up-to 16 SSIDs and VLANs with Single Point Propagation - Single point propagation easily sets the entire mesh network with an identical SSID/VLAN set for each node on the mesh network via Mesh Manager node. Ü Support Https/Http - Allows GUI access via both “Http” and “Https” to enhance network management security. Ü User Controllable Tx Output Power for 5 GHz Radios (Optional) - Add the ability for administrators to adjust Tx Output power for the 5 GHz radios. Ü Enable/Disable RTS/CTS Mode - RTS/CTS mode improves throughput in high collision environment caused by hidden terminals. Ü Always Connect – Every Node on the Mesh Network will be Reachable Intelligent protocol enables each node to associate with another node even under noisy environmental conditions. Throughput may be reduced to assure node can be reached remotely. Ü Diagnostic Tool to Display Link Speed, SNR, Noise, and Error Rate - Newly added Diagnostic page allows Administrators to analyze each link’s Link Speed, Signal Noise Ratio, Noise, and Error Rate. Ü Smart Remote Firmware Update with Single Point Propagation - Enable firmware updates to all nodes on the mesh network via Mesh Manager unit. Once the Mesh Manager is updated with the new firmware: the new, updated firmware will propagate to every node on the mesh network. Ü Backup Link Redundancy for Manual Mode - Enhances the reliability of the Manual mode connection by allowing two uplinks to be selected. (This feature also enables a backup link in the Point-to-point setting.

Mesh Network Design Architecture Layer 2 Mesh Network design benefits: Ü Fast packet switching

Mesh Network Design Architecture Layer 2 Mesh Network design benefits: Ü Fast packet switching design to minimize latency Ü Fast speed on QOS and service authentication implementation Ü Compatible with all existing routers, gateways, access servers Layer 3 design to offer user friendly (HTTP) and standard (SNMP) compliant network management support Data Packet Management Packet Network Data Link Physical

Patented POP (Predictable Optimum Path) patented routing algorithm generates mesh network structure with smart

Patented POP (Predictable Optimum Path) patented routing algorithm generates mesh network structure with smart intelligence Ü Auto-configuration/discovery: automatically discover and configure interconnect Mesh Link among stations Ü Auto-healing: automatically resolve various network problems by rerouting mesh link to heal the down station in real time Ü Non-interference: Multiple wireless RF design minimizes or eliminates signal interference problem on backhaul and user data wireless networks Ü GPS: Location information of each station for maintenance and enabling physical location related new service

Patented POP (Predictable Optimum Path) Self-sustain, Auto-configuration, and Auto-healing POP routing Internet auto-healing :

Patented POP (Predictable Optimum Path) Self-sustain, Auto-configuration, and Auto-healing POP routing Internet auto-healing : Virtual link : Mesh link Mesh. AP station Mesh. AP configured as Mesh Manager of this Mesh Network Broken Mesh. AP station

Patented POP (Predictable Optimum Path) Automatic Re-Routing upon new bandwidth insertion Internet Insertion of

Patented POP (Predictable Optimum Path) Automatic Re-Routing upon new bandwidth insertion Internet Insertion of new bandwidth Internet Intern et

True Multi-Radio Design Cost-effective Dual Radio Backhaul network: Ü No co-channel interference problem for

True Multi-Radio Design Cost-effective Dual Radio Backhaul network: Ü No co-channel interference problem for high performance Ü Enable high hop count and long distance mesh network deployment Ü Maintain the same throughput at each node in whole mesh network Ü Design with cost-effective and in-band hardware to increase product margin Ü Throughput is 3 x TROPOS and 5 X Nortel Dual Radio, full-duplex backhaul traffic Single Radio, half-duplex backhaul traffic

Auto & Manual Routing Protocol Point-to-point and Point-to-multi-point with one click Flexible Auto and

Auto & Manual Routing Protocol Point-to-point and Point-to-multi-point with one click Flexible Auto and Manual routing protocol capability: Ü Simple, easy, and convenient Mesh. AP field installation with auto mesh link routing function Ü Maximum flexibility of allowing user to specify specific routing path using manual mode Auto Link Manual Link Auto Link

Node-to-node Interconnection Mesh. AP 3100 – Dual 5 GHz / Single 2. 4 GHz

Node-to-node Interconnection Mesh. AP 3100 – Dual 5 GHz / Single 2. 4 GHz Wireless Mesh Access Point Up Link To Mesh k M Client Link h es k in L Down Link To Mesh in h. L s Me Backhaul Mesh Link: Dual 5 GHz AP: Single 2. 4 GHz

Arrow. Span Mesh Network Operation Mesh. AP based on Hop Counts and Signal Strength

Arrow. Span Mesh Network Operation Mesh. AP based on Hop Counts and Signal Strength to associate with each other Station 1 Station 3 Mesh Manager Station 4 Station 2 Press “Spacebar” to begin (Slide Show view to Play)

Long Distance Node-to-node Connection Directional Antenna Setup * Based on 23 d. Bi Directional

Long Distance Node-to-node Connection Directional Antenna Setup * Based on 23 d. Bi Directional Antenna 10 km (3. 1 miles) Length: 5 km (3. 1 miles) with -57. 7 d. Bm [54 Mbps] Ü Ü Mesh. AP 3100 is set in Manual mesh link mode. Mesh. AP “B” is manually set to link on to the Mesh. AP “A”. 18 d. Bm (54 Mbps output power) + 23 d. Bi antenna = 41 d. Bm 41 – 121. 7 (5 km 5. 8 GHz open space loss) + 23 (receiving antenna gain) = -57. 7 d. Bm Link sensitivity: -67 d. Bm for 54 Mbps

Arrow. Span Wireless Mesh Network Solutions

Arrow. Span Wireless Mesh Network Solutions

Mesh. AP 3100 - Outdoor Carrier Class Multi-Radio Wireless Mesh Network Access Point Features

Mesh. AP 3100 - Outdoor Carrier Class Multi-Radio Wireless Mesh Network Access Point Features Ü Supports two 5. 3/5. 8 GHz 802. 11 a and single 2. 4 GHz 802. 11 b/g Ü Hardware-enhanced WEP/WPA AES, and MAC filtering AP security Ü (2) detachable 5. 3 – 5. 8 GHz 8 d. Bi Omni-directional antennas Ü (1) detachable 2. 4 GHz 8 d. Bi Omni-directional antenna or adjustable 90 -180 degree 12 d. Bi patch antenna Ü (1) GPS antenna provides location information Ü (1) 4. 9 GHz antenna for licensed band (optional) Ü Layer 2 mesh routing, POP (Predictable Optimum Path) intelligent routing algorithm, fast packet switching on mesh link traffic Ü (1) 10/100 Ethernet Port to connect with existing network infrastructure (3 rd-party router/gateway/access server/application server) Ü Web server and SNMP management Ü Po. E (power over Ethernet) support (on WAN port) Ü Typical power consumption = 15 W Ü Level pole, vertical pole, and wall mounting Ü IP 66 waterproof certification Ü Industrial grade operating temperature -40°F to 131°F (-40°C to 55 °C)

Arrow. Span Wireless Mesh Network Mesh. AP 3100 GPS Antenna N-type Antenna Connector (2.

Arrow. Span Wireless Mesh Network Mesh. AP 3100 GPS Antenna N-type Antenna Connector (2. 4 GHz Client) Membrane Vent Cap IP 67 RJ-45 Connector N-type Antenna Connector (5 GHz Backhaul)

Mesh. Backhaul 2600 - Outdoor 5 GHz Full-Duplex Wireless Mesh Backhaul Access Point Features

Mesh. Backhaul 2600 - Outdoor 5 GHz Full-Duplex Wireless Mesh Backhaul Access Point Features Ü Support Dual 5 GHz 802. 11 a Backhaul function Ü Hardware-enhanced WEP, WPK security Ü (2) detachable 8 d. Bi antennas Ü GPS provides location information Ü Layer 2 mesh routing, POP (Predictable Optimum Path) intelligent routing algorithm, fast packet switching on mesh link traffic Ü (1) 10/100 Ethernet interface to connect with existing network infrastructure and 3 rd-party router/gateway/access server/application server Ü Web server and SNMP management Ü POE (power over Ethernet) support (on WAN port) Ü Level pole mounting support Ü IP 66 waterproof certification Ü Operating temperature -40 C to +50 C

Mesh. AP 1100 - Indoor 2. 4 GHz Full-Duplex Wi-Fi Mesh Network Access Point

Mesh. AP 1100 - Indoor 2. 4 GHz Full-Duplex Wi-Fi Mesh Network Access Point Features Ü Dual 2. 4 GHz 802. 11 g Radios Design Ü Hardware-enhanced WEP security Ü (1) External 4 d. Bi Omni-directional antenna Ü (1) Built-in 4 d. Bi Omni-directional antenna Ü Layer 2 mesh routing, POP (Predictable Optimum Path) intelligent routing algorithm, fast packet switching on mesh link traffic Ü (1) 10/100 Ethernet Port to connect with existing network infrastructure and 3 rd-party router/gateway/access server/application server Ü LEDs to indicate AP and Mesh status Ü LED door Ü Web server management Ü Factory-default button Ü Support IEEE 802. 3 af POE (power over Ethernet)

Total Wireless Mesh Solutions Make & Model Mesh. AP 3100 Mesh. Backhaul 2600 Mesh.

Total Wireless Mesh Solutions Make & Model Mesh. AP 3100 Mesh. Backhaul 2600 Mesh. AP 1100 WLAN Technology (2) 802. 11 a + (1) 802. 11 b/g (2) 802. 11 a (2) 802. 11 g Security Features 64/128 bit WEP, Local MAC address filtering, WPA/WPA 2 64/128 bit WEP Range Up to 200 m@54 Mbps 1 km@6 Mbps Up to 80 m@54 Mbps Yes Yes (2) External 8 d. Bi 802. 11 a, (1) External 8 d. Bi 802. 11 b/g (2) External 8 d. Bi 802. 11 a (2) Built-in 4 d. Bi 802. 11 b/g Yes/Proprietary Yes -40 ºF to 131ºF (-40ºC to 55ºC) 32°F to 113°F (0°C to 45 °C) Point-to-point Bridging Yes Yes Point-to-Multipoint Bridging Yes Yes Warranty 3 Yr 3 yr List Price $1, 999 $1, 499 $600 Access Point Antenna Support Po. E Support Operating Temp

Accessories & Add-on Solutions

Accessories & Add-on Solutions

Horizontal Pole Mount Kit Mesh. AP 3100/2600 Arrow. Span Mesh. AP Series Pole-Mount Kit

Horizontal Pole Mount Kit Mesh. AP 3100/2600 Arrow. Span Mesh. AP Series Pole-Mount Kit Ü Rugged Aluminum rust- proof material Ü Hardware for mounting the Mesh. AP 3100/2180 Series Access Point to the top of a horizontal pole

5 GHz 8 d. Bi Omni-directional Antenna Mesh. AP 5100/3100/2600 Ü 5 GHz 8

5 GHz 8 d. Bi Omni-directional Antenna Mesh. AP 5100/3100/2600 Ü 5 GHz 8 d. Bi Omni-directional Antenna Technical Specifications Frequency 5100 - 5900 MHz Gain 8 d. Bi VSWR < 1. 5 Polarization Vertical Beam Width 15° Horizontal Beam Width 360° Impedance 50Ω Max. Input Power 100 watts Weight . 39 lbs (178 g) Length 14. 76 inches (37. 5 cm) Connector N - Male Material White Fiberglass Mounting Direct Attachment Wind Survival 100 mph (160. 9 km/h) Temperature -40° F to 176° F (-40° to 80° C)

2. 4 GHz 8 d. Bi Omni-directional Antenna Mesh. AP 5100/3100 Ü 2. 4

2. 4 GHz 8 d. Bi Omni-directional Antenna Mesh. AP 5100/3100 Ü 2. 4 GHz 8 d. Bi Omni-directional Antenna Technical Specifications Frequency 2400 - 2485 MHz Gain 8 d. Bi VSWR < 1. 5 Polarization Vertical Beam Width 15° Horizontal Beam Width 360° Impedance 50Ω Max. Input Power 100 watts Weight . 39 lbs (178 g) Length 18. 50 inches (47 cm) Connector N - Male Material White Fiberglass Mounting Direct Attachment Wind Survival 100 mph (160. 9 km/h) Temperature -40° F to 176° F (-40° to 80° C)
