Lift Trucks for Ports Terminals Industries Handling of

  • Slides: 23
Download presentation
Lift Trucks for Ports, Terminals & Industries Handling of containers, steel, aluminium, pipe, wood,

Lift Trucks for Ports, Terminals & Industries Handling of containers, steel, aluminium, pipe, wood, paper, concrete, waste… 10 -32 T

Lift Trucks for Ports, Terminals & Industries Handling of containers, steel, aluminium, pipe, wood,

Lift Trucks for Ports, Terminals & Industries Handling of containers, steel, aluminium, pipe, wood, paper, concrete, waste… 33 -60 T

Fork Lift Trucks 28 -33 tons Models: SMV 28 -1200 B SMV 32 -1200

Fork Lift Trucks 28 -33 tons Models: SMV 28 -1200 B SMV 32 -1200 B Wheelbase: 4500 mm 4750 mm SMV 33 -1200 B* 4750 mm Engines (Can. Bus) 28/33 -1200: Volvo (Std) TAD-722 -VE (180 k. W / EU 2) Option TAD-760/DC-9/QSB-6, 7 (EU 3 a) TAD-762 -VE (185 k. W/3 b) Engines (Can. Bus) 32/33 -1200: Scania (Std) DI-12 -54 A (222 k. W / EU 2) Option DC-12, TAD-12, QSM-11 (EU 3 a) Automatic Transmission (Can. Bus): DANA TE-17312 (3+3 speed) DANA TE-27418 (4+4 speed) ZF 4 WG-191 (3+3 speed) EU st 3 b ZF 4 WG-261 (4+3 speed) EU st 3 b Drive axle (Wet Disc Brakes): Kessler D 91 -B (80 T / W=3440 mm) 16. 00 x 25”/PR 28 (28 -1200… 32 -1200) 16. 00 x 25”/PR 32 (33 -1200) Pumps: Parker LS-pumps (105+75 cc) 4 hydraulic servo levers (4 functions) All lift trucks has full capacity up to 9000 mm lift height 28/33 -1200 32/33 -1200 28/33 -1200

Fork Lift Trucks 60 -70 tons Models: Wheelbase: SMV 60 -1500 B SMV 64

Fork Lift Trucks 60 -70 tons Models: Wheelbase: SMV 60 -1500 B SMV 64 -1200 B* 6000 mm* * New & other models on request ! Engines (Can. Bus): Scania DI-12 -55 A (294 k. W / EU 2) Option DC-12 -56 A (294 k. W / EU 3 a) Option (new) DC-13 -074 A 2 (294 k. W / EU 2) DC-13 -077 A 2 (294 k. W / EU 3 b) Automatic Transmission (Can. Bus): STD: TE-32418 (4+4) OPT: ZF 4 WG-311 (4+3) only EU st 3 b Drive axle (Wet Disc Brakes): Kessler D 111 (140 T / W=4, 60 m / 21. 00 x 35”) Pumps: Parker LS-pumps (105+75+60 cc) STD 52 -54 Parker LS-pumps (2 x 105+60 cc) STD 60 -64 Full capacity up to 6000 mm lift height

Fork Shaft System (FSS) - forks, coil rams, clamps, spreaders… 13, 6 T +

Fork Shaft System (FSS) - forks, coil rams, clamps, spreaders… 13, 6 T + Bale Clamp 16 T + Dual Roll Clamp 45 T + Coil ram/forks (Pin) 20 T + End Lift 508 45 T + Coil ram/forks (Hook) 25 T + Coil ram/Fork 45 T + Inverted forks & Spreader

SMV 52 -1200 Model 2010 / Scania 12 L + Dana TE-27 + Kessler

SMV 52 -1200 Model 2010 / Scania 12 L + Dana TE-27 + Kessler D 106 + 18 x 33”/ EMC

SMV 12 -1200 / Saw mill truck / Fork levelling fork / 4 packages

SMV 12 -1200 / Saw mill truck / Fork levelling fork / 4 packages

SMV 13, 6 -600 / Paper bale trucks / 8 T in clamp /

SMV 13, 6 -600 / Paper bale trucks / 8 T in clamp / Raised cab / EMC

SMV 13, 6 -600 / Paper bale trucks / 8 T in clamp /

SMV 13, 6 -600 / Paper bale trucks / 8 T in clamp / Raised cab / Freelift mast / EMC

SMV 16 -1200 / Paper rolls / 12 T in clamp / 180 D

SMV 16 -1200 / Paper rolls / 12 T in clamp / 180 D rotator seat / Raised cab +500 / EMC

SMV 12 -1200 / Scrap handling truck / 180 deg rotator carriage / Raised

SMV 12 -1200 / Scrap handling truck / 180 deg rotator carriage / Raised cabin 500 mm

SMV 45 -1200 / Steel handling / Fork shaft system (quick-change) / Forks &

SMV 45 -1200 / Steel handling / Fork shaft system (quick-change) / Forks & Coil ram

SMV 16 -1200 / Steel pipe truck / Grab attachment

SMV 16 -1200 / Steel pipe truck / Grab attachment

SMV 18 -1200 / Steel grab truck / Raised cab 1200 mm

SMV 18 -1200 / Steel grab truck / Raised cab 1200 mm

SMV 52 -1200 / Steel slab handling / Forks or Magnet / Hydraulic generator

SMV 52 -1200 / Steel slab handling / Forks or Magnet / Hydraulic generator / 40 T slabs

SMV 52 -1200 / Steel slab handling / Forks or Magnet / Hydraulic generator

SMV 52 -1200 / Steel slab handling / Forks or Magnet / Hydraulic generator / 40 T slabs

SMV 45 -1200 / Steel slabs / 4 forks - 1200 C / 2

SMV 45 -1200 / Steel slabs / 4 forks - 1200 C / 2 forks + Magnet - 400 C / 38– 45 T slabs

SMV 37 -1200 / Concrete handling truck / wide carriage / 4 forks /

SMV 37 -1200 / Concrete handling truck / wide carriage / 4 forks / raised side cabin

SMV 42/45 -1200 / Rock handling trucks / Dusty conditions / Pin-type forks

SMV 42/45 -1200 / Rock handling trucks / Dusty conditions / Pin-type forks

SMV 18/25 -1200 / Forks + Spreader on FSS / End stacking & container

SMV 18/25 -1200 / Forks + Spreader on FSS / End stacking & container repair

SMV 37 -1200 / General cargo truck / Fork shaft system (forks & coil

SMV 37 -1200 / General cargo truck / Fork shaft system (forks & coil ram)

SMV 42 -1200 / 3 high 9’ 6” / ELME 815 (20 -40 ft)

SMV 42 -1200 / 3 high 9’ 6” / ELME 815 (20 -40 ft) / Inverted Forks

SMV 16/25 -1200 / Boat loading / Double fork levelling - stroke 800 mm

SMV 16/25 -1200 / Boat loading / Double fork levelling - stroke 800 mm / Long forks
