Emulating MUL How multiplication of unsigned integers can

Emulating ‘MUL’ How multiplication of unsigned integers can be performed in software

Hardware support absent? • The earliest microprocessors (from Intel, Zilog, and others) did not implement the multiplication instructions – that operation would have had to be done in software • Even with our Core-2 Quad processor, there is an ultimate limit on the sizes of integers that can be multiplied using the processor’s built-in ‘multiply’ instructions

Multiplying with Base Ten • Here’s how we learn to multiply multi-digit integers using ordinary ‘decimal’ notation 8765 x 4321 ---------8765 17530 26295 + 35060 ---------37873565 multiplicand multiplier partial product product

Analogy with Base Ten • When multiplying multi-digit integers using ‘binary’ notation, we apply the same idea 1001 x 1011 ---------1001 0000 + 1001 ---------1100011 multiplicand (=9) multiplier (=11) partial product product (=99)

Some observations… • With ‘binary’ multiplication of two N-digit values, the product can require 2 N-digits • Each ‘partial product’ is either zero or is equal to the value of the ‘multiplicand’ • Succeeding partial products are ‘shifted’ • So if we want to ‘emulate’ multiplication of unsigned binary integers using software, we must implement these observations

8 -bit case • The smallest case to consider is using the ‘mul’ instruction to compute the product of 8 -bit values, say in registers AL and BL. section number 1: number 2: product: . section mov mul mov . data. byte. word 100 200 0 . text number 1, %al number 2, %bl %ax, product

Doing it by hand 100 = 0 x 64 = 01100100 (binary) 01100100 AL 200 = 0 x. C 8 = 11001000 (binary) 11001000 BL 00000000 11001000 + 0000 ------------------010011100000 (BL x 0) (BL x 1) (BL x 0) 20000 = 0 x 4 E 20 = 010011100000 (binary) 01001110 00100000 AX

Using x 86 instructions. section. text softmulb: push %rcx # save caller’s count-register sub mov nxbit 8: rcr jnc add noadd 8: loop sub %ah, %ah $9, %rcx $1, %ax noadd %bl, %ah nxbit 8 %ah, %cl # zero-extend AL to (CF: AH: AL) # number of bits in (CF: AH) # next multiplier-bit to Carry-Flag # skip addition if CF-bit is zero # else add the multiplicand # go back to shift in next CF-bit # set CF-bit if 8 -bits exceeded %rcx # recover caller’s count-register pop ret

Visual depiction ROR $1, %AX CF 0 AH AL 0000 multiplier 17 -bit value gets ‘rotated’ 1 -place to the right BL multiplicand then multiplicand is added to AH (unless CF =0)

Exhaustive testing • We can insert ‘inline assembly language’ in a C++ program to construct a loop that checks our software multiply operation against every case of the CPU’s ‘mul’ • Our test-program is names ‘multest. cpp’ • You can compile it like this: $ g++ multest. cpp softmulb. s -o multest

In-class exercises • Can you write a ‘software’ emulation for the CPU’s 16 -bit multiply operation? mul %bx • Can you write a ‘software’ emulation for the CPU’s 32 -bit multiply operation? mul %ebx
