Effortless Platform Services Integration in Oracle Cloud CON 4445 Jeff Kiely Principal Product Manager

Effortless Platform Services Integration in Oracle Cloud CON 4445 Jeff Kiely Principal Product Manager Oracle October 02, 2017 Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |

Safe Harbor Statement The following is intended to outline our general product direction. It

Safe Harbor Statement The following is intended to outline our general product direction. It is intended for information purposes only, and may not be incorporated into any contract. It is not a commitment to deliver any material, code, or functionality, and should not be relied upon in making purchasing decisions. The development, release, and timing of any features or functionality described for Oracle’s products remains at the sole discretion of Oracle. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 3

Program Agenda 1 Model 300 Overview 2 Model 300 Networking 3 Connecting to Other

Program Agenda 1 Model 300 Overview 2 Model 300 Networking 3 Connecting to Other OCI Classic Services 4 Summary Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 4

Dedicated Compute Capacity - SPARC Model 300 Service Overview • SPARC M 7 Compute

Dedicated Compute Capacity - SPARC Model 300 Service Overview • SPARC M 7 Compute Nodes – 300 OCPU (300 SPARC M 7 Cores) – Each Customer Domain has 30 SPARC cores • 10 Customer Domains per SPARC Model 300 • 442 GBs of memory available for customer workloads – Single Customer Domain per server (Dom U) runs Solaris 11. 3 • Support for native Oracle Solaris zone, Oracle Solaris kernel zone, and Solaris 10 branded nonglobal zones • Integrated ZFS Storage Appliance – 60 TB+ of usable capacity on integrated ZFS Storage Appliance for Virtual Machines and application or database storage – Clustered controllers in a No Single Point of Failure configuration for storage availability Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 5

Program Agenda with Highlight 1 Model 300 Overview 2 Model 300 Networking 3 Connecting

Program Agenda with Highlight 1 Model 300 Overview 2 Model 300 Networking 3 Connecting to Other OCI Classic Services 4 Summary Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 6

Connectivity for SPARC Model 300 Inbound and Outbound Connections Public IP’s 1 Customer Site

Connectivity for SPARC Model 300 Inbound and Outbound Connections Public IP’s 1 Customer Site Hardware VPN over Public Internet Hardware IPsec VPN 2 Customer Site 3 IPsec VPN Gateway Hardware VPN over Leased Line or MPLS Fast. Connect Router Software IPsec VPN t o N d e t r o p p u S Remote Application User Software IPsec VPN 4 Remote Cloud Administrator Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 7

Connectivity for SPARC Model 300 Setting Up Connectivity to/from Customer Data Center • Initial

Connectivity for SPARC Model 300 Setting Up Connectivity to/from Customer Data Center • Initial configuration handled by activation form – Standup of compute and storage questions – VPN configuration questions • No self service portal – All changes need to be done via Service Request Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 8

Connectivity for SPARC Model 300 Setting Up External/Public Network Connectivity • Specify internal IP

Connectivity for SPARC Model 300 Setting Up External/Public Network Connectivity • Specify internal IP address • Specify connection type – Type: Inbound – Type: Outbound • Destination target/address (optional) • Allowed services/ports Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 9

Connectivity for SPARC Model 300 External Connectivity: Inbound Public IPs • Persistent 1: 1

Connectivity for SPARC Model 300 External Connectivity: Inbound Public IPs • Persistent 1: 1 NAT of internal IP address to public IP address • 16 inbound public IPs available by default • Allows outside users to connect to specific Model 300 IPs • Additional inbound public IPs can be requested Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 10

Connectivity for SPARC Model 300 External Connectivity: Oubound Public IPs • Pool of 8

Connectivity for SPARC Model 300 External Connectivity: Oubound Public IPs • Pool of 8 outbound public IPs available by default • For non-persistent connections to public internet • Less of a security concern • Additional outbound public IPs can be requested Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 11

Connectivity for SPARC Model 300 External Connectivity: Outbound Public IPs Source IP of VM/Zone

Connectivity for SPARC Model 300 External Connectivity: Outbound Public IPs Source IP of VM/Zone 10. 1. 1. 5 pkg. oracle. com 129. 157. 248. 123 129. 157. 248. 124 129. 157. 248. 125 129. 157. 248. 126 129. 157. 248. 127 129. 157. 248. 128 129. 157. 248. 130 Outbound Public IP Pool Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | cloud. oracle. com www. anything. com 12

Program Agenda with Highlight 1 Model 300 Overview 2 Model 300 Networking 3 Connecting

Program Agenda with Highlight 1 Model 300 Overview 2 Model 300 Networking 3 Connecting to Other OCI Classic Services 4 Summary Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 13

Connecting to Other Services Oracle SPARC Model 300 to Oracle Cloud Infrastructure – Compute

Connecting to Other Services Oracle SPARC Model 300 to Oracle Cloud Infrastructure – Compute Classic • Request SPARC Model 300 and Compute Cloud Service to be co-located in the same location/region • Use public IPs – On SPARC Model 300, open SR via support. oracle. com • Request type: inbound/persistent public IP – Provide SPARC Model 300 internal IP to NAT • Open correct service ports (Ex: port 22 for ssh) • Specify destination/target public IP(s) on the hosts on the Oracle Compute Cloud Service side – Configure correct ports on Oracle Compute Cloud Service via Cloud Portal • Create appropriate security rules, security lists, and security IP lists Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 14

Connecting to Other Services Oracle SPARC Model 300 to Oracle Cloud Infrastructure – Compute

Connecting to Other Services Oracle SPARC Model 300 to Oracle Cloud Infrastructure – Compute Classic Public Internet Oracle Cloud Internal Oracle Public Cloud Core M 300 FW 1: 1 NAT 10. 147. 254 <- -> 129. 140. 11. 20/32 Open Ports: 22 X 86 Instance Public IP: 129. 15. 180. 6/32 SPARC Zone/VM Net 0: 10. 147. 254 Security Rule: Application: ssh Source: public-internet or specific IP Destination: default Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 15

Connecting to Other Services Oracle SPARC Model 300 to Oracle Cloud Infrastructure Object Storage

Connecting to Other Services Oracle SPARC Model 300 to Oracle Cloud Infrastructure Object Storage Classic • Request SPARC Model 300 and Oracle Object Storage service to be colocated in the same location. • Use public IPs – On SPARC Model 300, open SR via support. oracle. com • Request type: outbound public IP – Provide SPARC Model 300 internal IP to NAT • Open correct service port (443 for https) • Specify destination/target URL on the hosts on the Oracle Object Storage Classic service side – Ex: https: //id. storage. oraclecloud. com • Can use Object Storage web UI or File Transfer Manager (FTM) CLI to manage storage Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 16

Connecting to Other Services Oracle SPARC Model 300 to Oracle Cloud Infrastructure Object Storage

Connecting to Other Services Oracle SPARC Model 300 to Oracle Cloud Infrastructure Object Storage Classic Public Internet Oracle Cloud Internal Oracle Public Cloud Core M 300 FW Public IP Pool 129. 140. 11. 15 129. 140. 11. 16 129. 140. 11. 17 129. 140. 11. 18 https: //id. storage. oraclecloud. com/… SPARC Zone/VM Net 0: 10. 147. 254 Oracle Storage Cloud Service Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 17

Connecting to Other Services Oracle SPARC Model 300 to Oracle Database Backup Service •

Connecting to Other Services Oracle SPARC Model 300 to Oracle Database Backup Service • Request SPARC Model 300 and Oracle Database Cloud Backup Service to be co-located in the same location • Use public IPs – On SPARC Model 300, open SR via support. oracle. com • Request type: outbound public IP – Provide SPARC Model 300 internal IP to NAT • Open correct service port (Port 443 for https) • Specify destination/target URL(s) – https: //<id>. storage. oraclecloud. com/ – Note: Oracle Database Cloud Backup Service Module requires additional access to https: //usoracleinter 76305. storage. oraclecloud. com Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 18

Program Agenda with Highlight 1 Model 300 Overview 2 Model 300 Networking 3 Connecting

Program Agenda with Highlight 1 Model 300 Overview 2 Model 300 Networking 3 Connecting to Other OCI Classic Services 4 Summary Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 19

Checklist on Connecting Services • Order services co-located in the same region/location • Inbound/persistent

Checklist on Connecting Services • Order services co-located in the same region/location • Inbound/persistent vs outbound/non-persistent pool • Specify source IP • Service ports • Target URLs and/or IPs • Configure other service security if required Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 20

Don’t Miss What ID Time Topic Demo SOA 097 Session CON 6296 Monday, Oct

Don’t Miss What ID Time Topic Demo SOA 097 Session CON 6296 Monday, Oct 2 5: 45 pm – 6: 30 pm Lift and Shift Your Oracle Solaris Workloads to the Oracle Cloud Session CON 2202 Tuesday, Oct 3 3: 45 pm – 4: 30 pm Run your Applications in a Maximum Security and Efficiency Environment Session CON 6301 Wednesday, Oct 4 4: 30 pm – 5: 15 pm Modern and Fast: A New Wave of Database and Java in the Cloud Session CON 6197 Wednesday, Oct 4 5: 30 pm – 6: 15 pm Real-World Examples of Migration to the Oracle Cloud Moscone West Secure and Efficient Platform for Enterprise Computing Monday - Wednesday Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 21

Passport to the Cloud Analytics Monday’s Word Of The Day Remember this word and

Passport to the Cloud Analytics Monday’s Word Of The Day Remember this word and return to the reception desk in the IT Infrastructure area in Moscone West left rear to have your Passport stamped. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | Oracle Confidential – Internal/Restricted/Highly Restricted 22

Summary – Q&A Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |

Summary – Q&A Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 23
