Descriptive Mineralogy Halides: Minerals with Halogen Anions

Descriptive Mineralogy Halides: Minerals with Halogen Anions

Classification of the Minerals • Non-Silicates – Native Elements – Halides – Sulfides –

Classification of the Minerals • Non-Silicates – Native Elements – Halides – Sulfides – Oxides – Hydroxides – Carbonates – Sulfates – Phosphates • Silicates – Orthosilicates – Sorosilicates – Cyclosilicates – Chain Silicates – Layer Silicates – Tektosilicates

Halides: Minerals with halogen anions • Halite (Na. Cl) and Sylvite (KCl): Evaporites •

Halides: Minerals with halogen anions • Halite (Na. Cl) and Sylvite (KCl): Evaporites • Fluorite (Ca. F 2) Low temperature hydrothermal • Cryolite (Na 3 Al. F 6): Pegmatite

Halite Cube

Halite Cube

Halite Na. Cl Crystal System Cubic Point Group 4/m-32/m Space Group Fd 3 m

Halite Na. Cl Crystal System Cubic Point Group 4/m-32/m Space Group Fd 3 m Optical isotropic 1. 51 Color colorless Luster Vitreous Hardness 2 Density 2. 1 g/cm 3

Halite Na. Cl Occurrence: Evaporites, Salt Domes Uses: Table salt, De-icing, Nuclear waste host

Halite Na. Cl Occurrence: Evaporites, Salt Domes Uses: Table salt, De-icing, Nuclear waste host rock?

Halite has low density and deforms plastically

Halite has low density and deforms plastically

Sylvite KCl Crystal System Cubic Point Group 4/m-32/m Space Group Fm 3 m Optical

Sylvite KCl Crystal System Cubic Point Group 4/m-32/m Space Group Fm 3 m Optical isotropic 1. 45 Color colorless Luster Vitreous Hardness 2 Density 1. 99 g/cm 3 Occurrence EVP

Potash Ponds near Moab

Potash Ponds near Moab

Fluorite Ca. F 2 Crystal System Cubic Point Group 4/m-32/m Space Group Fm 3

Fluorite Ca. F 2 Crystal System Cubic Point Group 4/m-32/m Space Group Fm 3 m Optical isotropic 1. 43 Color violet, green Luster Vitreous Hardness 4 Density 3. 18 g/cm 3 Occurrence LTH

Fluorite Veins in Granite

Fluorite Veins in Granite
