Wireless Music Player Designed By Fadi Neirat Fadi
Wireless Music Player Designed By : Fadi Neirat Fadi Ne’irat Mohammad Barham
Content � Introduction � Device parts � Working procedures � Problems � Future Plans
Introduction Our wireless music player allows the user to listen to uncompressed digital audio streamed over a wireless link. The music player reads uncompressed audio data from an SD card in an immobile "base station. " A pair of Xbee transceiver modules are used to stream data and control signals between the base station and a portable module.
Overview � Why using wireless ? ü Wider range : approximately 100 m ü • Separated Controller Why use of file with. wav extention
Consist of Tow Parts q MAIN q STATION PORTABLE STATION
Audio Stream Main Station Portable Station Control Signals
Main Station Begin • Start SPI • Initialize SD-Card q Initialize FAT file System q. Get First File Buffer 2 KB of data Data Request Chek for and implement file skip request, or stop command Transmit Data
Portable Station Begin Initialize SPI (DAC) Initialize USART, with receive interrupt Initialize timer 2 with 8 Khz interrupt Yes Request Data Buffer low? No Button pressed? Command No Send Halt palyback if Yes pause or stop
Processing request and send packets as needed Send This Command controller for play(as must be ready example) Initialize List all files And Initialize read first packet File System SD-CARD from first Read packet file(2 KB) and send it to DAC
Problems � SD card Initialization � File System � Sensitivity of XBEE � XBEE communication � DAC output
Future Plans � Develop our project to work on clientserver application using PIC � Increase sound resolution to get a sound with better quality
