Pusan National University power PNU 세계로 미래로 Introduction to Computer System 컴퓨터의 이해 2: 폰 노이만 컴퓨터 구조 School of Computer Science and Engineering Pusan National University Jeong Goo Kim
4 power PNU 1 The Stored 세계로 미래로 The Stored Program Computer 1943: ENIAC Presper Eckert and John Mauchly – 최초의 범용 전자 컴퓨터 Hard-wired program – 다이얼과 스위치 조작 1944: Beginnings of EDVAC 프로그램을 메모리에 저장할 수 있는 기능 개선이 이루어짐 1945: John von Neumann “The First Draft of a Report on EDVAC”이라는 문서를 통해 “Stored Program” 개념 발표 Draft에서 설명한 기본 구조 Von Neumann Machine (or Model)로 불림. Von Neumann Machine (or Model) Memory : 명령과 데이터 포함 Processing Unit : 산술 및 논리 연산의 수행 Control Unit : 명령의 해석 For more history, see http: //en. wikipedia. org/wiki/History_of_computing_hardware Advanced Broadcasting & Communications Lab. 1
4 power PNU 2 세계로 미래로 Advanced Broadcasting & Communications Lab. Von Neumann Model 2
세계로 미래로 power PNU 폰 노이만 컴퓨터 구조 ENIAC: Program-controlled Computer(Wired Programming) Advanced Broadcasting & Communications Lab. 3
세계로 미래로 power PNU Memory 0000 0001 0010 0011 0100 0101 0110 1101 1110 1111 Advanced Broadcasting & Communications Lab. 00101101 • • • 10100010 5
세계로 미래로 power PNU Interface to Memory How does processing unit get data to/from memory? MAR: Memory Address Register MDR: Memory Data Register To LOAD a location (A): MAR에 주소 (A)를 쓴다. 메모리로 “read” 신호를 보낸다. MDR에서 값을 읽는다. To STORE a value (X) to a location (A): MDR에 값 (X)를 쓴다. MAR에 주소 (A)를 쓴다. 메모리로 “write” 신호를 보낸다. . Advanced Broadcasting & Communications Lab. 6
4 power PNU 1 0 세계로 미래로 Instruction Processing Fetch instruction from memory Decode instruction Evaluate address Fetch operands from memory Execute operation Store result Advanced Broadcasting & Communications Lab. 10
세계로 미래로 power PNU Homework 유인물 읽기 발표 준비 Advanced Broadcasting & Communications Lab. 12
