DEKRA Material Testing Inspection DEKRA tradition Slide 2

DEKRA Material Testing & Inspection

DEKRA - tradition Slide 2 © 2011 DEKRA

DEKRA reached the 2 -bn. -threshold in 2011 organic: 4, 6 % acquisitions: 3, 2 % Sales (kons. in Mio. EUR) 2, 249 1, 178 2005 1, 311 2006 1, 439 2007 1, 596 2008 1, 710 2009 1, 859 2010 2, 007 2011 2, 164 2012* 2013 B

DEKRA proofs again to be an attractive employer

Ranking 2012 * Revenue 2011 Growth rates are based on local currencies Source: Berenberg Bank “Testing, Inspection and Certification” as of 22. 05. 2012. Annual Reports of companies, Press Releases, Intertek 2012 Rev. is Thomson One est. , Applus 2012 Rev. is DEKRA est.

Group Structure with a Focus on Stakeholder Value DEKRA e. V. DEKRA SE DEKRA AUTOMOTIVE DEKRA INDUSTRIAL DEKRA PERSONNEL Seite 6 © 2011 DEKRA

Focus on international business fields DEKRA e. V. DEKRA SE AUTOMOTIVE SERVICES INDUSTRIAL SERVICES PERSONNEL SERVICES Vehicle testing Industrial services Qualification Expertise Material testing & inspection Temporary work Used car managememt Product testing & -certification Homologation & Typ Approval System Certification Claims handling Consulting International activities

Examples for succesful integrations 2008 2009 2010 2011 Inspection 2012 2013 Czech Republic Finland Sweden Czech Republic Lithuania Germany NDT/DT Germany Turkey Kazakhstan Azerbaijan Germany South Africa

DEKRA Material Testing & Inspection – International DEKRA Industrial in Czech Republic Phone: +420. 466. 310354 www. dekra-industrial. cz DEKRA Industrial in Finland Phone: +358. 9. 878020 www. dekra-industrial. fi DEKRA Industrial in France Phone: +33. 472. 900230 www. dekra-industrial. fr DEKRA Industrial in Germany Phone: +49. 2065. 99740 www. dekra-industrial. de DEKRA Industrial in Lithuania Phone: +370. 386. 31608 www. dekra-industrial. lt DEKRA Industrial in Sweden Phone: +46. 10. 455. 1000 http: //www. dekra-industrial. se DEKRA Industrial in Turkey DEKRA Raysonics in South Africa Phone: +90. 216 537 07 60 http: //www. dekra-industrial. com. tr Phone: +27. (0) 13 243 3177 http: //www. raysonics. cp. za 9

Our international network – The solution for your international projects =We can help our clients to manage their cross country projects with one local interface (language, cultural base, fast and easy communication) = We can support our clients with know how of country – specific rules and regulations = We know the country specific authorities which are from importance for big projects = We have a wide service scope, which are from high importance for big international projects = Presence in a lot of the countries, direct or via partners

DEKRA Material Testing & Inspection Seite 11 © 2011 DEKRA

Examples for Special Services Seite 12 © 2011 DEKRA

DEKRA Material Testing & Inspection Corrosion Monitoring §Digital radiographic and Isotope - based methods enables us to detect any kind of corrosion related indications §These methods enable a corrosion monitoring without the time and cost consuming disassembling of the insolatio §The Lixi Profiler utilises a Gadolinium 153 isotope, it can also be used for the identification of welds or blockages in piping systems Seite 13 © 2011 DEKRA

DEKRA Material Testing & Inspection Tankfarm Services § Condition monitoring of flat bottom storage tanks § Floor – Scanning corrosion monitoring by different methods MFL/EC § Wall thickness measurement for the tank walls § Inspection of the tank farms based on waterand explosion - protection regulations of the different countries Seite 14 © 2011 DEKRA

DEKRA Material Testing & Inspection Mobile Metallographic Methods § Components exposed by high temperature and high stresses will deteriorate in service due to creep § By Mobile Metallography (Replica Technique) the actual condition can be monitored directly on – site § Other applications are microstructures of weldings and heat treatment procedures Seite 15 © 2011 DEKRA

DEKRA Material Testing & Inspection EMAT-Thickness measurement of boiler and pipes FST-GAGE is a testing equipment that can be used on all electrically conductive specimens, when rapid and accurate analysis of the wall thickness is required § High-temperature thickness measurement § Rapid inspection of large areas § Inspection under supports and on air-to-soil interfaces using guided waves § Non-contact measurement, a coupling medium is not required § Measurement of Stress, Bolt-Load and Nodularity § Clearer and more meaningful report for a permanent tracking of periodic inspections § Information on A, B, C and Line Scan formats. Seite 16 © 2011 DEKRA

DEKRA Material Testing & Inspection Guided Wave UT (long range) § Effective scanning method to analyze damage or corrosion in long pipe systems or similar structures § Especially in the area of insulated pipes an economic analysis of the critical areas without completely removing of the insulation is possible § 100% of the tube circumference is checked § This test method is more and more requested in an international environment Seite 17 © 2011 DEKRA

Laser 3 D Scanning Volume Calculation, Deformations, Containment • Calculates volumes of vertically positioned storage tanks • Indicates deformations in storage tank walls • Calculates tank storage containment • Laser precision 0, 5 mm • Measuring range max 120 m Page 18 © 214 DEKRA

DEKRA Material Testing & Inspection R 8 N crawlers The R 8 N crawler has a four-wheel-drive and was developed for the inspection of steel, concrete and plastic pipes § The data is transmitted with a kevlar reinforced fiber and stretches to 1000 m. The control is carried out by a computer or an i. Phone / i. Pad § The R 8 N can with a plurality of various probes to be fitted as follows: - X-ray tubes - Visual Systems - Ultrasonic Systems - 3 D Laserscan Seite 19 © 2011 DEKRA

DEKRA Material Testing & Inspection Acoustic Eye § Acoustic Eye is based on Acoustic Pulse Reflectometry (APR) § For the internal inspection of tubes id 8 – 104 mm and length up to 20 m of heat exchangers, boilers, etc made of ferrous and non ferrous metals and plastics § Less than 10 seconds per tube § Detected defects tube size. 8 mm to 63, 5 mm: § Holes min diameter 1 mm § Blockages min 1% of cross section § Erosion min 5 % of wall thickness Seite 20 © 2011 DEKRA

DEKRA Material Testing & Inspection Mechanized / Automated Testings Ultrasonic, Eddy Current, Visual & Dye Penetrant Tests Seite 21 © 2011 DEKRA

References in the field of Energy, Chemistry, Oil and Gas Seite 22 © 2011 DEKRA
