Pure. Storage Installer’s Guide
‘Single phase – 5 & 10 k. Wh’ Simple installation process 1. 2. 3. 4. Mount the unit Connect the CT Clamps Connect the cables to the unit Set up the portal
Pure. Storage Installer’s Guide 1. Mount the Unit (Wall) a) Fix the wall mounting bracket 964 mm above the floor b) Lift the enclosure and hook the 3 connectors on the unit to their corresponding slots on the bracket 3 slots on bracket 3 connectors on rear of unit
Pure. Storage Installer’s Guide 2. Connect the CT Clamps There are 2 off CT clamps. - One off must be installed between the distribution board and the Public Grid. - One off must be installed between the distribution board and the solar PV inverter, (just the positive wire, not the whole cable). The Arrow must follow the flow of energy – i. e. toward the distribution board. Grid PV
Pure. Storage Installer’s Guide 3. Connect the cables to the unit To remove the side panel and gain access to the cable termination plate unscrew the screws Unscrew the cable termination plate with a 2. 5 mm Allen key
Pure. Storage Installer’s Guide 3. Connect the cables to the unit Pull out the cable termination plate to access the terminals Wire in the AC power cable and CT cables to the terminals. Also plug in communication cable as per the following diagram
Pure. Storage Installer’s Guide 3 a. Terminal Connection wiring diagram
Pure. Storage Installer’s Guide 4. Set up the Portal Videos in Installer Portal
