Introduction to Distributed Systems and Networking Announcements Homework

Introduction to Distributed Systems and Networking

Announcements • Homework 4 due today • Attempting to schedule Prelim II for Thursday, April 26 th 2

Goals for today • Introduction to Distributed Systems • Introduction to Networking 3

Centralized vs Distributed Systems Server Client/Server Model Peer-to-Peer Model • Centralized System: System in which major functions are performed by a single physical computer – Originally, everything on single computer – Later: client/server model • Distributed System: physically separate computers working together on some task – Early model: multiple servers working together • Probably in the same room or building • Often called a “cluster” – Later models: peer-to-peer/wide-spread collaboration 4

Distributed Systems Definition: Loosely coupled processors interconnected by network • Distributed system is a piece of software that ensures: – Independent computers appear as a single coherent system • Lamport: “A distributed system is a system where I can’t get my work done because a computer that I’ve never heard of has failed” 5

Why use distributed systems? • These are now a requirement: – – – Economics dictate that we buy small computers Cheap way to provide reliability We all need to communicate It is much easier to share resources Allows a whole set of distributed applications A whole set of future problems need machine communication • Collaboration: Much easier for users to collaborate through network resources (such as network file systems) – … 6

Distributed Systems: Issues • The promise of distributed systems: – Higher availability: one machine goes down, use another – Better durability: store data in multiple locations – More security: each piece easier to make secure • Reality has been disappointing – Worse availability: depend on every machine being up • Lamport: “a distributed system is one where I can’t do work because some machine I’ve never heard of isn’t working!” – Worse reliability: can lose data if any machine crashes – Worse security: anyone in world can break into system • Coordination is more difficult – Must coordinate multiple copies of shared state information (using only a network) – What would be easy in a centralized system becomes a lot more difficult 7

Distributed Systems Goals • Connecting resources and users • Transparency: the ability of the system to mask its complexity behind a simple interface – – – Location: Can’t tell where resources are located Migration: Resources may move without the user knowing Replication: Can’t tell how many copies of resource exist Concurrency: Can’t tell how many users there are Parallelism: System may speed up large jobs by splitting them into smaller pieces – Fault Tolerance: System may hide various things that go wrong in the system • Openness: portability, interoperability • Scalability: size, geography, administrative • Transparency and collaboration require some way for different processors to communicate with one another 8

Software Concepts System Description Main Goal Distributed OS Tightly coupled OS for multiprocessors and homogeneous m/cs Hide and manage hardware resources Networked OS Loosely coupled OS for heterogeneous computers, LAN/WAN Offer local services to remote clients Middleware Additional layer atop NOS implementing general-purpose services Provide distribution transparency Machine C Machine B Machine A Distributed Applications Middleware Local OS 9 Network

Some Applications • • Air traffic control Banking, stock markets Military applications Health care, hospital automation Telecommunications infrastructure E-commerce, e-cash … 10

Few Challenges • No shared clocks – How to order events • No shared memory – Inconsistent system state • • Scalability Fault tolerance – Availability, recoverability • • • Consensus Self management Security 11

Networking • Middleware gives guarantees not provided by networking • How do you connect computers? – Local area network (LAN) – Wide area network (WAN) • Let us consider the example of the Internet 12

Internet: Example • Click -> get page • specifies - protocol (http) - location (www. cnn. com) 13

Internet: Locating Resource • www. cnn. com – name of a computer – Implicitly also a file (index. html) • Map name to internet protocol (IP) address – Domain name system (DNS) cnn. com? host com local a. b. c. d 14

Internet: Connection • Http (hyper-text transport protocol) sets up a connection – TCP connection (transmission control protocol) – between the host and cnn. com to transfer the page • The connection transfers page as a byte stream – without errors: flow control + error control Host www. cnn. com Connect OK Get page Page; close 15

Internet: End-to-end • Byte stream flows end to end across many links/switches: – routing (+ addressing) • That stream is regulated and controlled by both ends: – retransmission of erroneous or missing bytes; flow control 16

Internet: Packets • The network transports bytes grouped into packets • Packets are “self-contained”; routers handle them 1 by 1 • The end hosts worry about errors and pacing – Destination sends ACKs; Source checks losses 17

Internet: Bits • Equipment in each node sends packets as string of bits • That equipment is not aware of the meaning of the bits • Frames (packetizing) vs. streams 18

Internet: Points to remember • Separation of tasks – – – send bits on a link: transmitter/receiver [clock, modulation, …] send packet on each hop [framing, error detection, …] send packet end to end [addressing, routing] pace transmissions [detect congestion] retransmit erroneous or missing packets [acks, timeout] find destination address from name [DNS] • Scalability – routers don’t know full path – names and addresses are hierarchical 19

Internet : Challenges • • • Addressing ? Routing ? Reliable transmission ? Interoperability ? Resource management ? Quality of service ? 20

Concepts at heart of the Internet • • • Protocol Layered Architecture Packet Switching Distributed Control Open System 21

Protocol • Two communicating entities must agree on: – Expected order and meaning of messages they exchange – The action to perform on sending/receiving a message • Asking the time 22

Layered Architectures • Human beings can handle lots of complexity in their protocol processing. – Ambiguously defined protocols – Many protocols all at once • How computers manage complex protocol processing? – Specify well defined protocols to enact. – Decompose complicated jobs into layers; • each has a well defined task 23

Layered Architectures • Break-up design problem into smaller problems – More manageable • Modular design: easy to extend/modify. • Difficult to implement – careful with interaction of layers for efficiency 24

Layered Architecture network users Applications Web, e-mail, file transfer, . . . Middleware Reliable/ordered transmission, QOS, security, compression, . . . Routing Physical Links End-to-end transmission, resource allocation, routing, . . . Point-to-point links, LANs, radios, . . . 25

The OSI Model • Open Systems Interconnect (OSI) – standard way of understanding conceptual layers of network comm. – This is a model, nobody builds systems like this. • Each level – provides certain functions and guarantees – communicates with the same level on remote notes. • A message – generated at the highest level – is passed down the levels, encapsulated by lower levels – until it is sent over the wire. • On the destination – Encapsulated message makes its way up the layers – until the high-level message reaches its high-level destination. 26

OSI Levels Node A Application Presentation Session Transport Network Data Link Physical Network Node B 27

OSI Levels • Physical Layer – electrical details of bits on the wire • Data Link Layer – sending “frames” of bits and error detection • Network Layer – routing packets to the destination • Transport Layer – reliable transmission of messages, disassembly/assembly, ordering, retransmission of lost packets • Session Layer – really part of transport, typ. Not impl. • Presentation Layer – data representation in the message • Application – high-level protocols (mail, ftp, etc. ) 28

Internet protocol stack network users Application Transport Network Physical HTTP, SMTP, FTP, TELNET, DNS, … TCP, UDP. IP Point-to-point links, LANs, radios, . . . 29

Air travel Passenger Origin Passenger Destination Ticket (purchase) Ticket (complain) Baggage (check) Baggage (claim) Gates (load) Gates (unload) Runway (take off) Runway (landing) Airplane routing 30

Summary • Network: physical connection that allows two computers to communicate – Packet: unit of transfer, sequence of bits carried over the network • Protocol: Agreement between two parties as to how information is to be transmitted • Internet Protocol (IP) – Used to route messages through routes across globe – 32 -bit addresses, 16 -bit ports • Reliable, Ordered, Arbitrary-sized Messaging: – Built through protocol layering on top of unreliable, 31
