Hitachi Inspires IPv 6 Deployment Dec 4 th

Contents 1. Hitachi Activity on IPv 6 Area Overview 2. Products 3. Enhancement for

Hitachi Activity on IPv 6 Area Overview Technology R&D, Trial, Standardization IPv 4 -IPv

Gigabit Router “GR 2000” Series n Many Japanese and worldwide Service Providers, Enterprises are

GR 2000 Hardware Based IPv 6 <High Performance IPv 4 and IPv 6 Dual

New GR 2000 B models n. IPv 4/IPv 6 Dual Stack Router for Broadband

IPv 6 Network Management JP 1/Cm 2/Network topology-manager for IPv 6 can show Topology

IPv 6 Access Gateway “AG 8000” n AG 8000 Enables IPv 6 services to

Enhancement for new Services IPv 6 Multicast Service A B Internet Data Center Fundamental

IPv 6 Multicast Service n IP(v 6) Multicast Service is required for Broadband Access

Next Generation Deployment of IPv 6 n We are getting l Network Products: IPv

Deployment to/from ＩＰｖ６ Commodities Technical Issues l. Lightweight IPv 6 Protocols l. System LSI

IPv 6 System LSI (Under Planning) n IPsec Accelerator l IPv 6 LSI Solution

Topic : Toolnet 6 Download Report What is Toolnet 6 ? l. Software Tool

Analysis from Regional viewpoint of Download n. From August 1998 to August 2001 n.

Thank you! All Rights Reserved, Copyright ã 2001, Hitachi, Ltd. 16

Slides: 16

Download presentation

Contents 1. Hitachi Activity on IPv 6 Area Overview 2. Products 3. Enhancement for new Services 4. Next Generation Deployment 5. Topic – Toolnet 6 Download Report All Rights Reserved, Copyright ã 2001, Hitachi, Ltd. 2

Hitachi Activity on IPv 6 Area Overview Technology R&D, Trial, Standardization IPv 4 -IPv 6 NAT, Toolnet 6, KAME, BIS, USAGI, Super-Internet etc. (Many, many, …) Networking Box (Routers, etc. ) NR 60 GR 2000 H/W AG 8000 (New Models) Network Solution Business System Integrated Service Menu Network Management MIB IPv 6 Network Topology IT Appliance Products LSI Always, Hitachi inspires IPv 6 Deployment New Service, New Application All Rights Reserved, Copyright ã 2001, Hitachi, Ltd. 3

Gigabit Router “GR 2000” Series n Many Japanese and worldwide Service Providers, Enterprises are already using GR 2000 IPv 6 l More than 200 units are deployed worldwide n Dual-stack approach l IPv 4 & IPv 6 Available Across All Models & Interfaces n RIPng, BGP 4+, OSPFv 3 supported n Two Types Solution l Software Upgrade - Low cost to start for early adopters l Hardware Based - High Performance Model 2 S 4 S Enterprise Network 6 H 10 H 20 H Carrier/ISP/NSP Network All Rights Reserved, Copyright ã 2001, Hitachi, Ltd. 4

GR 2000 Hardware Based IPv 6 <High Performance IPv 4 and IPv 6 Dual Stack =IPv 6 packet routing and forwarding by dedicated ASIC model – 2 S is currently software based only =Up to 26 Mpps(GR 2000 -20 H) =Up to OC-48 c [2. 4 Gbps] Wire Speed =Hardware Based Qo. S Control (including IPv 6 Diff-Serv) =Hardware Based Packet Filtering =High Speed IPv 6 Tunneling n Released since Sep. 2001 All Rights Reserved, Copyright ã 2001, Hitachi, Ltd. 5

New GR 2000 B models n. IPv 4/IPv 6 Dual Stack Router for Broadband Network u. Enterprise ØBranch Office u. School l. Small-Sized Gigabit Router GR 2000 -1 B ● Ethernet (10/100 Mbs)x 2 ports (Preinstalled) l. Height: 1 U size (44 mm) l. High Performance ● 1 -Option Slot l 1 M Packet / sec l. Hardware-Based Forwarding l. Gigabit Ethernet, ATM-OC 3 GR 2000 -2 B ● Ethernet (10/100 Mbs)x 4 ports (Preinstalled) ● 2 -Option Slot l. Qo. S, Multicast, etc. l. OSPF, BGP 4, etc. l. Release Date: April/2002 in Japan =Overseas: Under Planning All Rights Reserved, Copyright ã 2001, Hitachi, Ltd. 6

IPv 6 Network Management JP 1/Cm 2/Network topology-manager for IPv 6 can show Topology of IPv 6 Logical Network Management Main Screen IPｖ 6 Network Topology Screen Also JP 1 can : l JP 1/Cm 2/Network Node Manager shows IPv 6 MIB l JP 1/Cm 2/LAN Element Manager shows status of IPv 6 router (e. g. GR 2000) Monitor Terminal All Rights Reserved, Copyright ã 2001, Hitachi, Ltd. 7

IPv 6 Access Gateway “AG 8000” n AG 8000 Enables IPv 6 services to the Internet Access Network Providers and Service Providers l x. DSL, FTTx, CATV, etc. n Migration Path to IPv 6 l IPv 6 BAS(-B) and Broadband Address Translator(-T) l IPv 6 & IPv 4 Dual-stack, and PPP for IPv 6/IPv 4 -B Broadband Access Server IPv 6 User Support PPP for IPv 6/IPv 4 RADIUS, Billing, AAA, etc. IPv 4／IPv 6 Dual Stack i. DC Client router IPv 6 Access Network -B IPv 6 Network (x. DSL, FTTx, CATV, etc. ) IPv 4 User IPv 4 Access Network Local Contents Server New Model: -T Contents Delivery Server IPv 4 Network SNMP Manager(JP 1) IPv６⇔IPv４ Translator Release Date: 1 Q/2002 All Rights Reserved, Copyright ã 2001, Hitachi, Ltd. 8

Enhancement for new Services IPv 6 Multicast Service A B Internet Data Center Fundamental requirement System-oriented requirement • High speed IPv 6 packet forwarding • High speed IPv 6 Qo. S • High speed and high density of line interface • etc. • Hi speed load balance • High speed encryption/decryption • Discarding malicious heavy traffic • etc Internet Automobile Mobile IP telephone Game computer All Rights Reserved, Copyright ã 2001, Hitachi, Ltd. PC TV 9

IPv 6 Multicast Service n IP(v 6) Multicast Service is required for Broadband Access Application Service l TV Conference l Remote Education, Remote Seminar l Stock Information Service l Software Update Service l Streaming Contents Delivery l Motion Picture Distribution (B to B) l Supply Chain Management (B to B) etc. n GR 2000 will support Hardware based IPv 6 Multicast l Release Date: 1 Q/2002 in Japan =Overseas: There might be delay depending on regulatory issue All Rights Reserved, Copyright ã 2001, Hitachi, Ltd. 10

Next Generation Deployment of IPv 6 n We are getting l Network Products: IPv 6 Ready l Internet Service: IPv 6 Ready n What is Next ? l How can we get “Peer to Peer” Service ? l How can we get new business style ? All Rights Reserved, Copyright ã 2001, Hitachi, Ltd. 11

Deployment to/from ＩＰｖ６ Commodities Technical Issues l. Lightweight IPv 6 Protocols l. System LSI Technologies IPv 6 on Chip (LSI) Network Products • Full suit of Protocols • Downsizing • Stable Implementation • Cost Reduction Low Cost ! Mass Production Home IT Appliances, New Style Network Low Cost ! New Style Business （for Enterprises） All Rights Reserved, Copyright ã 2001, Hitachi, Ltd. PDA, ITS, NAVI, Sensors, Vending Machines etc. 12

IPv 6 System LSI (Under Planning) n IPsec Accelerator l IPv 6 LSI Solution for Ubiquitous and Secured Communication l For Peer to Peer services SSL Authentication (Public key) IPsec Authorization Core (Hash Function） Encryption/ Decryption RSA Ellipse Curve Application Core SHA-1 IPSec Accelerator MD 5 IPv 6 Protocol Core DES/3 DES Multi 2 All Rights Reserved, Copyright ã 2001, Hitachi, Ltd. M 6 DES: Data Encryption Standard MD 5: Message Digest #5 SHA: Secure Hash Algorithm SSL: Secure Socket Layer 13

Topic : Toolnet 6 Download Report What is Toolnet 6 ? l. Software Tool For Existing Windows® Applications Over IPv 6. l. Enhancement For Network Interface Card Driver Software l. Free distribution from Hitachi home page u http: //www. hitachi. co. jp/Prod/comp/network/pexv 6 -e. htm l. RFC 2767(Bump-in-the-Stack) IPv 4 applications (Telnet, Ftp, Mail, Web…. . ) OS TCPv 4 IPv 4 6 Bone IPv 4/v 6 Windows PC IPv 6 Server Toolnet 6 Windows 98 Windows NT IPT DNS IPv 6 Network Card Driver NIC All Rights Reserved, Copyright ã 2001, Hitachi, Ltd. 14

Analysis from Regional viewpoint of Download n. From August 1998 to August 2001 n. Total Amount of Download Requests : 4373 l. Excludes Duplicate Requests or Requests with Invalid Information JAPAN Domestic Overseas n. Requests from Overseas (2282) Europe North America Latin America Africa Asia Unknown All Rights Reserved, Copyright ã 2001, Hitachi, Ltd. 15
