Dr. A. Carlotto – ST Powder Coatings S. p. A. New ST line with high energy saving for ECO applications Optimization of coating processes - New EVO+ product line

Presentation Introduction Experimental part Results and discussions Conclusions Optimization of coating processes - New EVO+ product line

Introduction • The origin of EVO+ product line • Kind of finishes and chemical classes of EVO+ product line • Comparison between standard products and EVO+ products • Chemical-physical properties of EVO+ products Optimization of coating processes - New EVO+ product line

Introduction Energie Verbrauch Optimiert A B C D + EVO Optimization of coating processes - New EVO+ product line

Experimental part Items analyzed in this work ID ARTICLES RAL FINISH CHEMISTRY REACTIVITY M 0 -878 -7035 -003 7035 RIVER TEXTURE EPOXY-POLYESTER 180 °C x 20 min. M 6 EVO+ M 6 -675 -7035 -003 7035 RIVER TEXTURE EPOXY-POLYESTER 150 °C x 20 min. P 0 -878 -7035 -001 7035 RIVER TEXTURE POLYESTER 180 °C x 20 min. P 6 EVO+ P 6 -874 -7035 -001 7035 RIVER TEXTURE POLYESTER 150 °C x 20 min. Optimization of coating processes - New EVO+ product line

Experimental part Curing windows M 6 -675 -7035 -003 M 0 -878 -7035 -003 EVO+ 210 230 210 Cure temperature (°C) 200 190 170 150 190 180 170 160 150 140 130 0 5 10 15 20 25 Cure time (min) 30 35 40 0 5 10 15 20 25 Cure time (min) 30 35 Optimization of coating processes - New EVO+ product line 40

Experimental part Curing windows P 6 -874 -7035 -001 210 200 Cure temperature (°C) P 0 -878 -7035 -001 190 180 170 160 150 140 EVO+ 190 180 170 160 150 140 130 0 5 10 15 20 25 Cure time (min) 30 35 40 130 0 5 10 15 20 Cure time (min) 25 30 Optimization of coating processes - New EVO+ product line 35

Experimental part M 0 -878 -7035 -003 – thickness 50 µm 10 X Magnification Optimization of coating processes - New EVO+ product line

Experimental part M 0 -878 -7035 -003 – thickness 50 µm 300 X – 3 D map Optimization of coating processes - New EVO+ product line

Experimental part M 0 -878 -7035 -003 75 µm 100 µm Optimization of coating processes - New EVO+ product line

Experimental part Comparison between standard product e EVO+ – thickness 50 µm M 0 -878 -7035 -003 M 6 -675 -7035 -003 EVO+ Optimization of coating processes - New EVO+ product line

Experimental part Comparison between standard product e EVO+ – thickness 50 µm M 0 -878 -7035 -003 - 10 X M 6 -675 -7035 -003 - 10 X EVO+ Optimization of coating processes - New EVO+ product line

Experimental part Comparison between standard product e EVO+ – thickness 50 µm M 0 -878 -7035 -003 - 300 X M 6 -675 -7035 -003 - 300 X EVO+ Optimization of coating processes - New EVO+ product line

Experimental part P 0 -878 -7035 -001 – thickness 50 µm 10 X Magnification Optimization of coating processes - New EVO+ product line

Experimental part P 0 -878 -7035 -001 – thickness 50 µm 300 X – 3 D map Optimization of coating processes - New EVO+ product line

Experimental part P 0 -878 -7035 -001 75 µm 100 µm Optimization of coating processes - New EVO+ product line

Experimental part Comparison between standard product e EVO+ – thickness 50 µm P 0 -878 -7035 -001 P 6 -874 -7035 -001 EVO+ Optimization of coating processes - New EVO+ product line

Experimental part Comparison between standard product e EVO+ – thickness 50 µm P 0 -878 -7035 -001 - 10 X P 6 -874 -7035 -001 - 10 X EVO+ Optimization of coating processes - New EVO+ product line

Parte sperimentale Comparison between standard product e EVO+ – thickness 50 µm P 0 -878 -7035 -001 - 300 X P 6 -874 -7035 -001 - 300 X EVO+ Optimization of coating processes - New EVO+ product line

Experimental part Corrosion resistance after 4 days of Salt Spray Test – ISO 9227 M 0 -878 -7035 -003 M 6 -675 -7035 -003 EVO+ Optimization of coating processes - New EVO+ product line

Experimental part Corrosion resistance after 4 days of Salt Spray Test – ISO 9227 M 0 -878 -7035 -003 - 10 X M 6 -675 -7035 -003 - 10 X EVO+ Optimization of coating processes - New EVO+ product line

Experimental part Corrosion resistance after 4 days of Salt Spray Test – ISO 9227 M 0 -878 -7035 -003 - 300 X Optimization of coating processes - New EVO+ product line

Results e discussions Physical-mechanical properties of epoxy-polyesters ID ARTICLES IMPACT RESISTANCE (2. 5 Nm) ADHESION BENDING TEST (5 mm) ASTM D 2794/2004 ISO 2409/2007 ISO 1519/2002 M 0 -878 -7035 -003 OK OK OK M 6 EVO+ M 6 -675 -7035 -003 OK OK OK Optimization of coating processes - New EVO+ product line

Results e discussions Impact resistance M 0 -878 -7035 -003 50 µm 75 µm M 6 -675 -7035 -003 100 µm 50 µm 75 µm 100 µm EVO+ Optimization of coating processes - New EVO+ product line

Results e discussions Physical-mechanical properties of polyesters ID ITEMS IMPACT RESISTANCE (2. 5 Nm) ADHESION BENDING TEST (5 mm) ASTM D 2794/2004 ISO 2409/2007 ISO 1519/2002 P 0 -878 -7035 -001 OK OK OK P 6 EVO+ P 6 -874 -7035 -001 OK OK OK Optimization of coating processes - New EVO+ product line

Results e discussions Impact resistance P 0 -878 -7035 -001 50 µm 75 µm P 6 -874 -7035 -001 100 µm 50 µm 75 µm 100 µm EVO+ Optimization of coating processes - New EVO+ product line

Results e discussions Consumption analysis in accordance with the studies of an important resin producer Energy saving It is estimated a reduction of 5 -10% of the energy costs each 10 ° C decreasing of curing temperature This value is equal to 2 €/hour each 10 ° C decreasing (or 4000 €/year, the value is influenced by the type of oven used) Optimization of production line Increasing of line production speed Increasing of line production capacity Optimization of coating processes - New EVO+ product line

Conclusions • • The aesthetic quality is better even at low thicknesses Possibility to produce EVO+ in all colors The heating gradient sensitivity is less than standard products The EVO+ corrosion resistance is higher than standard products The accelerated weathering test UV-B 313 nm are similar to standard polyesters Decreasing of consumption and environmental impact The productive efficiency is higher than standard products Optimization of coating processes - New EVO+ product line

Special thanks • The lab and the all team of ST Powder Coatings S. p. A. • Grimm Pulverlack Vertriebs Gmb. H • Caleg Gmb. H • Lohmeier Schaltschrank-Systeme Gmb. H & Co. KG Optimization of coating processes - New EVO+ product line

Dr. A. Carlotto – ST Powder Coatings S. p. A. Thank you Optimization of coating processes - New EVO+ product line
