Maxi. Watch Professional System V 4. 0

Maxi. Watch Professional System V 4. 0

Key Feature u. Intelligent Video Surveillance (IVS) u. Failover Agent u. On. Guard (Software

Key Feature u. Intelligent Video Surveillance (IVS) u. Failover Agent u. On. Guard (Software Watchdog) u. IP Bridge u. Stream Profile Enhancement (Low Bitrate support) u 3 rd Party Integration u. Metadata plug-in: access control (Soyal) u. Metadata plug-in: access control (Falco) u. Metadata plug-in: POS (Micros d. Store) u. Metadata: LPR (VIT Company) u. Others u. ONVIF search v 1. 02. 04 u. Vivotek fisheye FE 8171 V u. Virtual joystick PTZ mode for Axis Camera

What is Failover Agent? Maxi. Watch Pro 1 IP Camera Maxi. Watch Pro 2

What is Failover Agent? Maxi. Watch Pro 1 IP Camera Maxi. Watch Pro 2 SD-CCTV Camera Failover Server Maxi. Watch Pro 3 HD-CCTV Camera Liveview / Playback Failover **Failover Server is used when large number of IP video needed to be securely backed up as another copy to a remote location.

Why Failover Agent? Easy to Set Up NVR IP address add on Failover Agent

Why Failover Agent? Easy to Set Up NVR IP address add on Failover Agent Set up by server group not camera channel Cost Saving Failover vs redundant: N to 1 compare to 1 Seamless to get liveview and playback video (AP access) Maxi. Watch remote liveview and remote playback can view original and failover video together

Failover Agent Scenario Project A: 32 ch per server, 3 recording servers, 1 failover

Failover Agent Scenario Project A: 32 ch per server, 3 recording servers, 1 failover server IP Camera Priority 2 Maxi. Watch Pro 1 IP Camera Priority 3 Maxi. Watch Pro 2 Failover Server Maxi. Watch Pro 3 IP Camera Priority 1 Liveview / Playback *Failover License activate on Failover Agent Failover

What Maxi. Watch have with Failover Agent Recording Failover Remote liveview Remote Playback Log

What Maxi. Watch have with Failover Agent Recording Failover Remote liveview Remote Playback Log search

Failover Agent Limitation u. Failover for video data only u. No event, alarm, metadata,

Failover Agent Limitation u. Failover for video data only u. No event, alarm, metadata, I/O box, IVS u. Support IP+ and Video Server (no capture card) u. Support LAN only u. Share same port (NUSP/NUPP) u. Admin only between Maxi. Watch and Failover server u. Failover operation use ID: Admin only u. Keep video in failover server, not collect back to recording server u. Support up to 8 Maxi. Watch Pro to 1 Failover server u. Recommend to use 3 Maxi. Watch Pro to 1 Failover server u. No Web Client u. No MSAD u. No DDNS u. Maxi. Watch Pro and Failover Agent can not install on same server u. One Failover server on one Maxi. Watch Pro group u. N+1 mode: Maxi. Warch Pro (N) have one independent Failover server (+1) u. CMS will support on v 1. 7

Failover Agent on Vertical Market 100 -150 ch middle scale project Government Education Healthcare

Failover Agent on Vertical Market 100 -150 ch middle scale project Government Education Healthcare Homeland security

(Software Watchdog)

(Software Watchdog)

What is On. Guard? u On. Guard is the software to bring Maxi. Watch

What is On. Guard? u On. Guard is the software to bring Maxi. Watch Pro back from the unresponsive state such as a hang and neglects restore to normal operation. u IP+ and capture card support u Maxi. Watch Pro only

What have with On. Guard? When Maxi. Watch Pro no respond, restart Maxi. Watch

What have with On. Guard? When Maxi. Watch Pro no respond, restart Maxi. Watch Pro Keep Maxi. Watch Pro unresponsive log

Why IP Bridge u Playback: Client want to view low quality recording u Can

Why IP Bridge u Playback: Client want to view low quality recording u Can view high & low Recording u Offer more Live Streaming connection

IP Bridge Scenario 1: System Architecture Maxi. Watch Pro 1 Remote Live Remote Playback

IP Bridge Scenario 1: System Architecture Maxi. Watch Pro 1 Remote Live Remote Playback Maxi. Watch Pro 2 Connect to Maxi. Watch Pro 1 by using Devicepack and able to receive video from Maxi. Watch Pro 1 up to 64 CH

IP Bridge Scenario 2: Maxi. Watch Pro 1 u Backup Video u Snapshot and

IP Bridge Scenario 2: Maxi. Watch Pro 1 u Backup Video u Snapshot and Recording u User can view last few minutes before thief destroy Maxi. Watch Pro 1 Maxi. Watch Pro 2 Connect to Maxi. Watch Pro 1 by using Devicepack and able to receive video from Maxi. Watch Pro 1 up to 64 CH

Stream Profile Setting add H. 264 Benefit: Bandwidth saving Scenario: QCIF H. 264 1

Stream Profile Setting add H. 264 Benefit: Bandwidth saving Scenario: QCIF H. 264 1 fps static scenes Stream Profile Format Bitrate (Kbps) High H. 264 Minimum 1 kbps Normal H. 264 Minimum 1 kbps Low H. 264 Minimum 1 kbps Minimum H. 264 Minimum 1 kbps

3 rd Party integration One Platform, Total Management Metadata plug-in: access control (Soyal) Metadata

3 rd Party integration One Platform, Total Management Metadata plug-in: access control (Soyal) Metadata plug-in: access control (Falco) Metadata plug-in: POS (Micros d. Store) Metadata: LPR (VIT Company; specific countries only)

Others u. ONVIF search v 1. 02. 04 u. Vivotek fisheye FE 8171 V

Others u. ONVIF search v 1. 02. 04 u. Vivotek fisheye FE 8171 V support u. Original u. Rectilinear mode u. Full-view panorama mode u. Dual-view panorama mode u. Virtual joystick PTZ mode for Axis Camera

Fisheye de-wrap tool

Fisheye de-wrap tool
