Electrostar and Midea water dispenser

YL 1536 S---Fighting model---No cabinet , no fridge Double safety device for preventing overheat Child safety lock for hot water faucet Hot/Cold with single faucet High power stainless steel hot water tank High efficiency compressor cooling

YL 1536 S---Economic one Product Series �品系列 1536 Midea model 美的型号 YL 1536 S Voltage/Frequency�� /�率 220 V-240 V/50~60 Hz Cooling Method 制冷方式 Compressor Heating Method 制�方式 Internal Element Compressor Coil material ��机�圈材� Aluminum Refrigant type and weight 制冷�型号/重量 R 134 a/25 g Sound (d. BA) 噪音 ≤ 55 d. B IP code防水等� IPX 0 Appliance Certficates（ Certificate expiration / date）�气�� (��有效截止日期） Water dispenser color 水机�色 WHITE Carton color �箱�色 Brown FOB BEIJAO QUOTATION ( CBU ) USD 46. 3 Functional description parameters功能描述参数 Heated water temperature -(°C)�水温度 ≥ 85℃ Heated water capacity min at 25 (°C) Ambient 4 L/H (L/hr)制�水能力 Chilled water temperature - nominal - (°C)/ 冷水 ≤ 10℃ 温度 Chilled water capacity min at 25 (°C) Ambient 2 L/H (L/hr)制冷水能力 heating watts (W)加�功率 420 W Cooling watts (W)制冷功率 120 W Water Supply水供� Bottle Water Cooling only : USD 43. 58

YL 1536 S Product Series �品系列 Midea model 美的型号 1536 YL 1536 S Functional description parameters功能描述参数 Flow Rate - Minimum (each faucet) 水��出水最低流量 (L/min) TBC Chilled water 冷水 ≥ 1. 2 L/Min Room Temperature Water 温水　 Hot Water �水 ≥ 1. 2 L/Min Typical Operating Ambient Temperature典型的作�境温度 (°C) 10 -38℃ / (°F) / Chilled water 冷水 Y Ambient water 温水 / Hot Water �水 Y Water Spouts 水嘴数量 2 Water bottle position 水瓶放置位置 Top load Cold water tank material 冷罐材料 SUS 304 Hot water tank material �罐材料 SUS 304 Hot Tank dimension (ID X length) mm �罐尺寸 φ100 *130（1. 02 L） Hot water pipeline �水管路 silicone tube Cold Tank dimension (ID X length) mm冷罐尺寸 φ160 *155（3 L） Cold water pipeline 冷水管路 silicone tube Packaging information包装信息 N. W. （kg） 12 KG G. W. （kg） 13. 5 KG Product Dimensions（mm） 310*320*928 Packing Dimensions（mm） 360*335*985 Loading Capacity 装柜数 20 GP 204 40 GP 420 40 HQ 420

YL 1331 S- top loaded Double safety device for preventing overheat Child safety lock for hot water faucet Hot/Cold/Ambient with three faucets High power stainless steel hot water tank High efficiency compressor cooling 20 L spacious cabinet or fridge option

YL 1331 S---top loaded Product Series �品系列 1331 Midea model 美的型号 YL 1331 S-W(With Cabinet) YL 1331 S-B（With Fridge) Voltage/Frenquency�� /�率 220 V-240 V/50~60 Hz Cooling Method 制冷方式 Compressor Heating Method 制�方式 Internal Element Compressor Coil material �� Aluminum Copper 机�圈材� Refrigant type and weight 制冷 R 134 a/28 g R 134 a/36 g �型号/重量 Appliance Certificates（ GS/CE/CB Certificate expiration date）� 气�� (��有效截止日期） Water dispenser color 水机�色 WHITE or Black Carton color �箱�色 Brown FOB BEIJAO QUOTATION ( USD 53. 5 USD 65 CBU ) Functional description parameters功能描述参数 Heated water temperature -(°C) ≥ 85℃ �水温度 Heated water capacity min at 4 L/H 25 (°C) Ambient (L/hr)制�水能力 Chilled water temperature ≤ 10℃ nominal - (°C)/ 冷水温度 Chilled water capacity min at 25 2 L/H 1 L/H (°C) Ambient (L/hr)制冷水能力 heating watts (W)加�功率 420 W Cooling watts (W)制冷功率 120 W Water Supply水供� Bottle Water

YL 1331 S—top loaded Product Series �品系列 Midea model 美的型号 1331 YL 1331 S-W(With Cabinet) YL 1331 S-B（With Fridge) Functional description parameters功能描述参数 Flow Rate - Minimum (each faucet) 水 TBC ��出水最低流量 (L/min) Chilled water 冷水 ≥ 1. 2 L/Min Room Temperature Water 温水 ≥ 1. 0 L/Min Hot Water �水 ≥ 1. 2 L/Min Typical Operating Ambient Temperature 10 -38℃ 典型的作�境温度 (°C) / (°F) / Operating Humidity 作湿度 ≤ 90% Chilled water 冷水 Y Y Ambient water 温水 Y Y Hot Water �水 Y Y Water Spouts 水嘴数量 3 3 Water bottle position 水瓶放置位置 Top load Cold water tank material 冷罐材料 SUS 304 Hot water tank material �罐材料 SUS 304 Hot Tank dimension (ID X length) mm φ100 *130（1. 02 L） �罐尺寸 Hot water pipeline �水管路 silicone tube Cold Tank dimension (ID X length) mm φ160 *155（3 L）冷罐尺寸 Cold water pipeline 冷水管路 silicone tube Packaging information包装信息 N. W. （kg） 15. 9 KG 18. 1 KG G. W. （kg） 17. 6 KG 20. 5 KG Product Dimensions（mm） 310*362*1000 Packing Dimensions（mm） 358*386*1050 Loading Capacity 装柜数 20 GP 192 40 GP 396 40 HQ 396
