Dew Point David Young Mechanical Engineer TMME 1

Dew Point David Young Mechanical Engineer TMME 1 Intel Confidential Aug 2010

Dew Point temperature when dew forms: the temperature at which the air cannot hold all the moisture in it and dew begins to form. If objects and surfaces have cooled to below freezing point when the moisture in the air begins to condense, frost is formed instead. The dew point temperature is the temperature to which the air must be cooled before dew or frost begins to form. The dew point temperature is also a measure of the amount of water vapor in the current air mass. The higher the dew point, the more water vapor there is in the air. Air holds water in various amounts in the invisible gas state, called water vapor. 2 Intel Confidential

ATM Factory Dew Point 3 Intel Confidential

Dew Point 80° F Dew Point 54° F Dew Point 12° C 40% H. 27° C H@40% & T@80°F - DP=54°F H@60% & T@68°F - DP=54°F H@30% & T@89°F - DP =54°F 4 Intel Confidential

Human Comfort 5 Intel Confidential

Condensation Chart in C 6 Intel Confidential

Condensation Chart in F http: //www. lamtec. com/dew-pointcalculator. htm 7 Intel Confidential

Dew Point Information Dew Point is a better measure of moisture in the air. Good explanation of Dew Point at http: //weathersavvy. com/Q-dew_point 1. html Good explanation of Dew Point at http: //www. shorstmeyer. com/wxfaqs/humidity. html Dew Point Calculator at http: //dpcalc. org/ 8 Intel Confidential

Driving speed and efficiency in everything we do 9 Intel Confidential
